| Ref | Part Number | Description |
|---|
| 1 |
117-8029-03 |
BAND-TANK Price: $87.15 |
| 1 |
532424071 |
SEAT.TH151.GREY.PREM.HUSQ.MI Price: $349.00 |
| 2 |
110-5082-03 |
BRACKET-ANTI SIPHON Price: $55.49 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $11.99 |
| 3 |
41140 |
ELBOW Price: $11.18 |
| 3 |
532140675 |
STRAP Price: $5.99 |
| 4 |
100-6779 |
COUPLING-FEMALE Price: $58.88 |
| 5 |
41316 |
ADAPTER-QUICK Price: $31.51 |
| 6 |
110-5090 |
GROMMET Price: $7.08 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
110-5088 |
HOSE-FILL Price: $18.92 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
117-7928 |
ADAPTER ASM Price: $36.88 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
130-7096 |
FILTER ASM Price: $109.22 |
| 10 |
121-5003 |
SUCTION TUBE ASM Price: $197.40 |
| 10 |
596768801 |
KIT.PLATE.SEAT This part replaces 532196977. Price: $49.99 |
| 11 |
117-7996 |
FORK Price: $9.74 |
| 12 |
100-8635 |
FORK Price: $4.91 |
| 13 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 14 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 15 |
120-0649 |
BOLT-TAP HH Price: $12.44 |
| 16 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 17 |
119-5019 |
STOP-LID Price: $29.34 |
| 18 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 19 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 20 |
131-3316 |
DECAL-TANK Price: $37.16 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
120-0622 |
DECAL-WARNING Price: $9.31 |
| 23 |
42452 |
CAP-PROTECTIVE Price: $1.13 |
| 24 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 25 |
100-6991 |
ELEMENT-FILTER, GREEN Price: $63.09 |
| 25 |
100-6992 |
ELEMENT-FILTER, RED Price: $64.02 |
| 25 |
100-8642 |
SCREEN-SUCTION Price: $64.17 |
| 26 |
100-8641 |
VANE-SCREEN Price: $32.05 |
| 27 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 28 |
119-9419 |
BASKET-FILTER Price: $119.92 |
| 29 |
2412-130 |
CLAMP-HOSE Price: $2.57 |
| 30 |
130-7139 |
SHIELD-HEAT TAPE, FRONT Price: $47.05 |
| 31 |
130-7140 |
SHIELD-HEAT TAPE, BOTTOM Price: $114.99 |
| 32 |
130-7141 |
SHIELD-HEAT TAPE, SUMP Price: $26.13 |
| 33 |
131-3298 |
SHIELD-HEAT TAPE, SUMP, FRONT Price: $27.50 |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 40 |
595088102 |
Handles This part replaces 532197661. Price: $4.99 |
| 43 |
874760612 |
BOLT Price: $3.99 |
| 44 |
583789501 |
WASHER.13/32x2 3/8x12GA This part replaces 819133812. Price: $4.99 |
