| Ref | Part Number | Description |
|---|
| 1 |
233-21 |
KNOB Price: $12.99 |
| 1 |
583338301 |
KIT.SVC.WELDMNT.42"199911X431 This part replaces 532199911. Price: $229.99 |
| 2 |
21-8640 |
LATCH-LEVER, VALVE Price: $33.47 |
| 3 |
321-4 |
SCREW-HH Price: $0.99 |
| 4 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 5 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 6 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 6 |
532195186 |
ARM.SUSPENSION.MOWER.R Price: $8.99 |
| 7 |
111332 |
SWITCH This part replaces 21-8590. Price: $10.99 |
| 7 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 8 |
237-78 |
O-RING Price: $3.85 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $5.99 |
| 9 |
283-17 |
PIN-CLEVIS Price: $4.89 |
| 10 |
32121-73 |
PIN-ROLL Price: $0.22 |
| 11 |
103-1802 |
FITTING-ELBOW, 90 DEG This part replaces 353-374. Price: $22.99 |
| 12 |
3296-8 |
NUT-HEX Price: $1.29 |
| 13 |
21-9010 |
LEVER-VALVE, PIVOT MOUNT Price: $28.78 |
| 13 |
587253301 |
MANDREL.NONGREASEABLE.TALL This part replaces 532192872. Price: $32.99 |
| 14 |
237-42 |
O-RING Price: $2.78 |
| 14 |
532187281 |
HOUSING.MANDREL.4PT. Price: $22.99 |
| 15 |
21-3550 |
DISCONTINUED Price: Call Us |
| 15 |
532110485 |
BEARING Price: $7.99 |
| 16 |
353-507 |
DISCONTINUED Price: Call Us |
| 17 |
237-79 |
O-RING Price: $5.46 |
| 18 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 19 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $4.99 |
| 20 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 20 |
532159770 |
BAFFLE.VORTEX Price: $12.99 |
| 21 |
323-7 |
SCREW-HH Price: $0.65 |
| 21 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 22 |
21-1770 |
DISCONTINUED Price: Call Us |
| 23 |
3217-6 |
NUT-HEX Price: $1.19 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $3.99 |
| 24 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $2.99 |
| 25 |
21-1740 |
DISCONTINUED Price: Call Us |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $5.99 |
| 26 |
322-7 |
SCREW-HH Price: $0.89 |
| 26 |
532110452 |
NUT PUSH M Price: $1.99 |
| 27 |
353-432 |
Fitting 90? Female Swivel Price: Call Us |
| 27 |
532403004 |
SHIELD.DEFLECTOR.MOWER.42"BLAC Price: $27.99 |
| 28 |
237-79 |
O-RING Price: $5.46 |
| 29 |
353-466 |
DISCONTINUED Price: Call Us |
| 29 |
532131491 |
ROD.HINGE Price: $1.99 |
| 30 |
353-509 |
DISCONTINUED Price: $1.87 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $1.99 |
| 31 |
21-0090 |
DISCONTINUED Price: Call Us |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $1.99 |
| 32 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 32 |
532195945 |
PULLEY.MANDREL.5.438.P This part replaces 532197473. Price: $7.99 |
| 33 |
322-3 |
SCREW-HH Price: $0.79 |
| 33 |
532400234 |
NUT.FLANGE.LOCK.TOP Price: $3.99 |
| 34 |
21-0270 |
DISCONTINUED Price: Call Us |
| 34 |
872110612 |
BOLT.3/8-16X1.50 Price: $3.99 |
| 35 |
21-0280 |
DISCONTINUE Price: Call Us |
| 36 |
3217-7 |
NUT-HEX Price: $0.28 |
| 36 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $14.99 |
| 37 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 37 |
819131316 |
WASHER Price: $2.99 |
| 38 |
21-0120 |
DISCONTINUED Price: Call Us |
| 38 |
532432520 |
KEEPER.BELT.MANDREL.PULLEY Price: $5.99 |
| 39 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 40 |
21-0290 |
DISCONTINUED Price: Call Us |
| 40 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.99 |
| 41 |
323-11 |
SCREW-HH Price: $1.08 |
| 42 |
323-14 |
SCREW-HH Price: $1.34 |
| 42 |
532198410 |
SPRING.TORSION.BRAKE Price: $2.99 |
| 43 |
21-2430 |
DISCONTINUED Price: Call Us |
| 43 |
532197256 |
SRPING.TORSION.RETAINE Price: $2.99 |
| 44 |
321-5 |
SCREW-HH Price: $0.22 |
| 45 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 46 |
322-4 |
SCREW-HH Price: $0.35 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $2.99 |
| 47 |
21-1800 |
DISCONTINUED Price: Call Us |
| 47 |
532197250 |
BRKT.CLUTCH.CABLE Price: $2.99 |
| 48 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 49 |
20-0700 |
DISCONTINUED Price: $2.00 |
| 50 |
353-368 |
DISCONTINUED Price: Call Us |
| 51 |
353-435 |
DISCONTINUED Price: Call Us |
| 52 |
21-2110 |
DISCONTINUED Price: Call Us |
| 53 |
353-506 |
STRAIGHT ADAPTER Price: $22.13 |
| 54 |
21-3540 |
Tube Hydro Axle to Filter Price: Call Us |
| 55 |
256-237 |
BUSHING Price: $14.99 |
| 55 |
532437110 |
IDLER.ARM.42" Price: $4.99 |
| 56 |
21-1530 |
DISCONTINUED Price: Call Us |
| 56 |
532199092 |
SPACER.RETAINER Price: $3.99 |
| 57 |
323-4 |
SCREW-HH Price: $1.02 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 58 |
321-24 |
SCREW-HH This part replaces 321-23. Price: $2.31 |
| 59 |
21-8570 |
DISCONTINUED Price: Call Us |
| 59 |
532141043 |
GUARD, BELT Price: $3.99 |
| 60 |
21-8580 |
DISCONTINUED Price: Call Us |
| 60 |
532197402 |
ARM BRAKE MOWER This part replaces 532197261. Price: $11.99 |
| 61 |
5-6560 |
DISCONTINUED Price: Call Us |
| 62 |
109-0282 |
HOSE-FUEL This part replaces 21-2480. Price: $7.39 |
| 62 |
872110616 |
BOLT Price: $3.99 |
| 63 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 63 |
532199478 |
ARM.BRAKE.ZINC This part replaces 532199477. Price: $12.99 |
| 64 |
304-75 |
CONNECTOR-HOSE Price: $8.29 |
| 64 |
532199918 |
LINKAGE.BRAKE.ASM.ZINC This part replaces 532199790. Price: $12.99 |
| 65 |
304-97 |
DISCONTINUED Price: Call Us |
| 66 |
21-0390 |
DISCONTINUED Price: Call Us |
| 67 |
121-9070 |
VALVE ASM This part replaces 21-8550. Price: $458.43 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $7.99 |
| 68 |
304-73 |
FITTING-STRAIGHT Price: $12.59 |
| 68 |
532429636 |
BELT.DECK.DRIVE.42" Price: $32.99 |
| 69 |
21-4940 |
FITTING ASM Price: $79.78 |
| 69 |
872140505 |
BOLT Price: $2.99 |
| 70 |
353-375 |
FITTING-ELBOW, 90 Price: $42.42 |
| 70 |
532198332 |
CLUTCH.ASM.MANUAL.LT.TEX Price: $54.99 |
| 71 |
353-512 |
PLUG Price: $15.26 |
| 113 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $3.99 |
| 122 |
532197258 |
KEEPER BELT ENGINE LH Price: $9.99 |
| 123 |
532197259 |
KEEPER BELT RH Price: $9.99 |
| 144 |
532199204 |
KEEPER.BELT.MOWER Price: $3.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $14.99 |
| 147 |
532401971 |
RETURN SPRING Price: $3.99 |
| 152 |
532435111 |
CABLE.CLUTCH.MANUAL. Price: $19.99 |
| 188 |
532195161 |
STUD.FASTNER.W/ANTI-ROTATE Price: $3.99 |
| 189 |
583612701 |
NUT HEX,LOCK,FLAN This part replaces 873900500. Price: $3.99 |
| 192 |
532197260 |
BRKT.BRAKE.STAND.LH. Price: $8.99 |
| 195 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $2.99 |
| 532134149 |
BLADE.42".MULCH |
Price: $12.99 532134149 |
| 532139775 |
BLADE.42"MULCH.PREMIUM |
Price: $12.99 532139775 |
| 532422719 |
BLADE.42SP"3N1 |
This part replaces 532424752. Price: $12.99 532422719 |
| 587253301 |
MANDREL.NONGREASEABLE.TALL |
This part replaces 532192870. Price: $32.99 587253301 |
