| Ref | Part Number | Description |
|---|
| 1 |
138-6908 |
ENGINE-KUBOTA, D1105 Price: $8,176.79 |
| 2 |
121-9076 |
MOUNT-ENGINE Price: $37.76 |
| 2 |
532133957 |
WHEEL GAGE DONUT This part replaces 539107610. Price: $11.99 |
| 3 |
539108366 |
HCS 1/2-13 X 4 GR 5 ZD Price: $5.99 |
| 3 |
93-5265 |
MOUNT-ENGINE Price: $100.22 |
| 4 |
32128-20 |
NUT-HF Price: $0.99 |
| 4 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 5 |
323-11 |
SCREW-HH Price: $1.08 |
| 5 |
539990258 |
NUT HEX 1/2 Price: $3.99 |
| 6 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 6 |
966956101 |
KIT HSG ASM 52/61 This part replaces 539131383. Price: $129.99 |
| 7 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 7 |
598490501 |
Nuts This part replaces 539130653. Price: $7.99 |
| 8 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 8 |
539112125 |
PULLEY, 61 Price: $29.99 |
| 9 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 9 |
80-8560 |
WASHER-HARDENED Price: $5.70 |
| 10 |
42-9370 |
SCREW-HH Price: $2.42 |
| 10 |
539101733 |
BLADE OEM 21" (61" DECK) Price: $18.99 |
| 11 |
539103299 |
HCS 5/8F X 1 1/4 Price: $5.99 |
| 11 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 12 |
539990333 |
LOCKWASHER 5/8 Price: $2.99 |
| 12 |
95-8812 |
SCREW-HH Price: $1.22 |
| 13 |
539130917 |
PIVOT BRACKET - CHUTE Price: $129.99 |
| 13 |
99-3618-03 |
MOUNT-ENGINE, FRONT Price: $55.21 |
| 14 |
539130901 |
CHUTE, RUBBER DISCHARGE 52/61" Price: $79.99 |
| 14 |
95-8937-0P |
MOUNT-ENGINE, LH This part replaces 95-8937-03. Price: $29.15 |
| 15 |
100-4838-0P |
MOUNT-ENGINE This part replaces 100-4838-03. Price: $210.01 |
| 15 |
592964402 |
BRACKET.REINF.CHUTE.52/61.EDIP This part replaces 539130920. Price: $22.99 |
| 16 |
596671401 |
Bolts This part replaces 539100472. Price: $3.99 |
| 16 |
63-7790 |
SCREW-CAP Price: $1.46 |
| 17 |
596030801 |
Bolts This part replaces 539102933. Price: $3.99 |
| 17 |
99-3626 |
PULLEY-3V Price: $272.61 |
| 18 |
56-2140 |
SCREW-HH Price: $4.17 |
| 18 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 19 |
115-3487-0P |
BRACKET-MOUNT, FUEL FILTER This part replaces 115-3487-03. Price: $74.06 |
| 19 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 20 |
539102612 |
SCREW 3/8C X 2 3/4 HEX CAP Price: $4.99 |
| 20 |
98-9311 |
SWIVEL-THROTTLE Price: $28.41 |
| 21 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 21 |
539103295 |
IDLER BUSHING Price: $12.99 |
| 22 |
539103257 |
IDLER PULLEY Price: $49.99 |
| 22 |
81-1690 |
CLAMP-CABLE Price: $2.24 |
| 23 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 24 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 24 |
510254502 |
SHIELD DUST This part replaces 510254501. Price: $3.99 |
| 25 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 25 |
539108450 |
TOP DUST CAP Price: $4.99 |
| 26 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 26 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 27 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 27 |
539976941 |
HCS 3/8C X 1 1/4 GR5 Price: $3.99 |
| 28 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 28 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 29 |
3256-78 |
WASHER-FLAT Price: $1.21 |
| 29 |
539105192 |
DECK SPRING Price: $13.99 |
| 30 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 31 |
48-7890 |
NUT-HEX Price: $0.25 |
| 32 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 32 |
99-3441 |
HARNESS-WIRE, FUSIBLE LINK Price: $146.90 |
| 33 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 33 |
539105465 |
MAIN BAFFLE - 61" BLK Price: $159.99 |
| 34 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 34 |
539105461 |
CENTER BAFFLE - 61 Price: $79.99 |
| 35 |
595901601 |
GSPW Bolts This part replaces 539990316. Price: $2.99 |
| 35 |
95-8736 |
SPACER Price: $7.94 |
| 36 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 36 |
594722002 |
LIFT This part replaces 539102641. Price: $4.99 |
| 37 |
119-4478 |
SENDER-TEMPERATURE Price: $80.84 |
| 37 |
596438501 |
Bolts This part replaces 539108073. Price: $2.99 |
| 38 |
112-9919 |
STOP-CABLE, THROTTLE Price: $3.18 |
| 38 |
596577901 |
Nuts This part replaces 539102582. Price: $2.99 |
| 39 |
110-9009-0P |
BRACKET-CABLE, THROTTLE This part replaces 110-9009-03. Price: $13.98 |
| 39 |
596437601 |
Washers This part replaces 539104864. Price: $2.99 |
| 40 |
33104-016 |
SCREW-HHF Price: $0.97 |
| 40 |
595901901 |
Nuts This part replaces 539119124. Price: $2.99 |
| 41 |
510201301 |
BELT, DECK 61 Price: $119.99 |
| 42 |
539108754 |
SHAFT SEAL Price: $6.99 |
| 43 |
539108449 |
BOTTOM DUST CAP Price: $3.99 |
| 45 |
596623501 |
Zerks This part replaces 539101474. Price: $2.99 |
| 46 |
539130391 |
ARM-IDLER W/BRG Price: $37.99 |
| 47 |
596581801 |
Bolts This part replaces 539130235. Price: $2.99 |
| 48 |
539107042 |
HCS 3/8-16 X 1-1/2 Price: $2.99 |
| 49 |
596433501 |
NUT NUT.3/8-16.HEX.JAM.Z 3/8-1 This part replaces 539109332. Price: $2.99 |
| 50 |
539130242 |
BUSHING, IDLER Price: $2.99 |
| 51 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 539990122. Price: $2.99 |
| 52 |
539101341 |
HCS 3/8C X 3 Price: $4.99 |
| 53 |
510206301 |
PIVOT, BEARING Price: $3.99 |
| 54 |
539114823 |
CAP, VINYL Price: $2.99 |
| 55 |
522023401 |
WASHER, 3/8 THICK Price: $2.99 |
