| Ref | Part Number | Description |
|---|
| 1 |
144927 |
Battery Price: Call Us |
| 2 |
74760412 |
Bolt Hex Head 1/4-20 x 3/4 Price: Call Us |
| 8 |
7603J |
Tray, Battery Price: Call Us |
| 10 |
115-4105 |
GEAR CASE ASM This part replaces 107-9068. Price: $560.23 |
| 10 |
145211 |
Bolt Btr Frt 1/4-20 X 7.5 zinc Price: Call Us |
| 11 |
150109 |
Holdown Battery Front Mount Price: Call Us |
| 12 |
145769 |
Nut Push Nylon 1/4" Price: Call Us |
| 16 |
176138 |
Switch Interlock Push-In Price: Call Us |
| 20 |
127-0425 |
PLUG This part replaces 98-9598. Price: $4.34 |
| 21 |
175688 |
Harness Headlight w/Bulbs Price: Call Us |
| 22 |
4152J |
Bulb Light Price: Call Us |
| 24 |
4206J |
Cable, Battery Price: Call Us |
| 25 |
146149 |
Cable, Battery Price: Call Us |
| 25 |
98-7487 |
PLUG Price: $3.18 |
| 26 |
108824X |
Fuse Price: Call Us |
| 27 |
73510400 |
Nut Keps Hex 1/4-20 Unc Price: Call Us |
| 28 |
170697 |
Cable, Ground Price: Call Us |
| 29 |
160784 |
Switch, Plunger Price: Call Us |
| 30 |
175566 |
Switch, Ign Price: Call Us |
| 30 |
98-7562 |
WASHER-PLAIN Price: $0.36 |
| 33 |
140401 |
Key Price: Call Us |
| 40 |
170238 |
Harness, Ignition Price: Call Us |
| 40 |
98-9388 |
JOINT-PIPE Price: $31.66 |
| 41 |
17720408 |
Screw 1/4-20 x 1/2 Price: Call Us |
| 42 |
131563 |
Cover, Terminal Red Price: Call Us |
| 43 |
178861 |
Solenoid Price: Call Us |
| 45 |
122822X |
Ammeter Price: Call Us |
| 46 |
169635 |
Hourmeter Snap-In Price: Call Us |
| 50 |
174653 |
Switch, PTO Price: Call Us |
| 50 |
98-9544 |
SPRING Price: $0.94 |
| 60 |
98-9543 |
SEAT-VALVE Price: $26.61 |
| 70 |
98-9380 |
BALL Price: $0.84 |
| 79 |
175242 |
Socket, Light Bulb Price: Call Us |
| 80 |
98-9540 |
OIL PUMP ROTOR ASM Price: $271.67 |
| 81 |
109748X |
Relay Asm. Price: Call Us |
| 85 |
107-9069 |
COVER-PUMP, OIL Price: $27.77 |
| 90 |
107-9071 |
SCREW Price: $0.36 |
| 100 |
107-9072 |
PIN-STRAIGHT Price: $0.28 |
| 110 |
98-9633 |
GASKET-CASE, GEAR Price: $30.19 |
| 120 |
100-1765 |
BOLT This part replaces 107-9073. Price: $1.59 |
| 130 |
105-3797 |
BOLT Price: $1.40 |
| 140 |
98-9356 |
BOLT Price: $2.06 |
| 150 |
107-9074 |
BOLT Price: $1.43 |
| 160 |
99-3510 |
BOLT This part replaces 98-9586. Price: $0.80 |
| 170 |
105-3709 |
STUD Price: $1.13 |
| 180 |
98-7572 |
NUT Price: $0.32 |
| 190 |
98-7699 |
WASHER-SPRING Price: $0.44 |
| 200 |
119-8038 |
SEAL-OIL This part replaces 98-9482. Price: $40.16 |
| 210 |
105-3710 |
STUD Price: $1.16 |
| 220 |
99-3515 |
PLUG-GEARCASE This part replaces 98-9641. Price: $9.00 |
