| Ref | Part Number | Description |
|---|
| 2 |
753-05797 |
LOCKOUT LEVER Not Available Price: |
| 3 |
753-04043 |
TORSION SPRING Not Available Price: |
| 4 |
753-05793 |
LOCKOUT HDW Not Available Price: |
| 5 |
753-05795 |
Tensioner Cable Assembly Price: $27.59 |
| 6 |
791-182405 |
Switch Price: $9.29 |
| 7 |
753-05789 |
Throttle Assembly Price: $28.84 |
| 8 |
753-05794 |
THROTTLE HOUSING HDW Not Available Price: |
| 9 |
753-05524 |
Starter Rope Guide Assembly Price: $6.01 |
| 11 |
753-05526 |
MIDDLE HDL HDW Not Available Price: |
| 12 |
749-04361 |
HANDLE Not Available This part replaces 753-05557. Price: |
| 13 |
710-0599 |
SCREW 1/4-20 X.500 This part replaces 753-05528. Price: $3.86 |
| 14 |
753-05539 |
EDGER FRAME Not Available Price: |
| 15 |
712-04065 |
NUT This part replaces 753-05525. Price: $3.68 |
| 16 |
734-04261 |
Wheel This part replaces 753-05530. Price: $18.51 |
| 17 |
938-0373 |
Shoulder Bolt, .496 x 1.525:3/8-16 This part replaces 753-05529. Price: $8.45 |
| 18 |
750-04783 |
Spacer This part replaces 753-05556. Price: $3.36 |
| 19 |
710-1206 |
SCREW 1/4-20 x 2.375 This part replaces 753-05538. Price: $6.20 |
| 20 |
687-02051 |
Height Lever Assembly (Incl. Ref. #58-59) This part replaces 753-05531. Price: $8.27 |
| 21 |
736-0741 |
Bell Washer.760 ID x 1.25 OD This part replaces 753-05532. Price: $3.99 |
| 22 |
738-1172 |
Shoulder Screw,.750 x.500 This part replaces 753-05534. Price: $5.01 |
| 23 |
712-04135 |
Nut This part replaces 753-05535. Price: $5.59 |
| 24 |
736-0314 |
Thrust Washer .382 ID x .684 OD This part replaces 753-05533. Price: $6.01 |
| 25 |
987-02094 |
Pivot Arm This part replaces 753-05536. Price: $25.54 |
| 26 |
741-0751 |
Height Adjustment Bearing This part replaces 753-05537. Price: $7.50 |
| 27 |
710-1206 |
SCREW 1/4-20 x 2.375 This part replaces 753-05538. Price: $6.20 |
| 28 |
753-05559 |
SPINDLE SPACER Not Available Price: |
| 29 |
710-0599 |
SCREW 1/4-20 X.500 This part replaces 753-05528. Price: $3.86 |
| 30 |
787-01502 |
Belt Retainer Not Available This part replaces 753-05553. Price: |
| 31 |
753-05540 |
Idler Pulley Assembly Price: $33.52 |
| 32 |
738-0930 |
SHOULDER SCREW .560X.165: 5/16-18 This part replaces 753-05541. Price: $6.07 |
| 33 |
754-04149 |
Belt This part replaces 753-05560. Price: $26.86 |
| 34 |
710-3015 |
Hex Cap Screw, 1/4-20 x .75 This part replaces 753-05554. Price: $3.65 |
| 35 |
753-05555 |
Washer Price: $3.63 |
| 36 |
756-04087B |
Pulley This part replaces 753-05542. Price: $11.10 |
| 37 |
753-05543 |
Blade Spindle Price: $18.96 |
| 38 |
753-05544 |
SPINDLE PLATE Not Available Price: |
| 39 |
941-0524A |
Bearing, Ball, .625 x 40 x 12 This part replaces 753-05550. Price: $20.36 |
| 40 |
718-04012 |
Bearing Cup This part replaces 753-05545. Price: $19.55 |
| 41 |
736-04088 |
Flat Washer .635x1.24x.181 This part replaces 753-05546. Price: $3.90 |
| 42 |
731P05064 |
EDGER BLADE GUARD (W/LABEL) This part replaces 753-05547. Price: $23.87 |
| 43 |
738-0706D |
Screw This part replaces 753-05548. Price: $3.89 |
| 44 |
787-01503-0637 |
BLADE (POWDER BLACK) This part replaces 753-05562. Price: $20.96 |
| 45 |
753-05549 |
Nut Price: $6.50 |
| 46 |
710-04194 |
Cover Screw This part replaces 753-04595. Price: $3.66 |
