| Ref | Part Number | Description |
|---|
| 1 |
131-0285-03 |
STIFFENER-CHANNEL Price: $64.47 |
| 2 |
117-0701 |
HYDRAULIC CYLINDER ASM Price: $984.97 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
131-0275-03 |
PLATE-MOUNT Price: $135.25 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
112-7884 |
PIN-PIVOT Price: $20.16 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
110-5053 |
SCREW-HHF Price: $0.88 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
130-8201-03 |
MOUNT-VALVE Price: $42.89 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
136-2400 |
ON-OFF BOOM LIFT VALVE ASM This part replaces 117-0702. Price: $1,383.95 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532182493. Price: $17.99 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 11 |
59-7410 |
FITTING-DIAGNOSTIC Price: $36.39 |
| 12 |
354-79 |
CAP-DUST Price: $7.81 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 13 |
322-14 |
SCREW-HH Price: $1.01 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
110-5067 |
SCREW-CARR Price: $2.17 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 15 |
99-5107 |
NUT-LOCK Price: $1.77 |
| 16 |
131-0276 |
HOSE ASM Price: $67.56 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
