| Ref | Part Number | Description |
|---|
| 1 |
52-9260 |
SCREW-SET Price: $8.09 |
| 2 |
712-04065 |
Nut, Hx. Insert Flange Lck, 3/8-16 GRF This part replaces 00012173. Price: $3.68 |
| 3 |
01000338 |
HHCS:1/4-20: .620:GR5:STD Price: $3.63 |
| 3 |
52-9230 |
RING-RETAINING Price: $26.68 |
| 4 |
01000861 |
WHEEL PIVOT BRACKET Not Available Price: |
| 4 |
52-9240 |
BUSHING Price: $65.67 |
| 5 |
710-0599 |
Hex Wash. Hd. Self-Tap Scr. 1/4-20 x .50" Lg. This part replaces 01000865. Price: $3.86 |
| 6 |
732-0864 |
LEVER SPRING Not Available This part replaces 01000871. Price: |
| 7 |
59-6730 |
RACE Price: $10.63 |
| 7 |
736-0133 |
Washer, Flat, .406 X 1.25 X .100 Thk This part replaces 01000872. Price: $4.67 |
| 8 |
59-6740 |
BEARING Price: $28.82 |
| 8 |
736-0160 |
Flat Washer .536 ID x .93 OD This part replaces 01000873. Price: $3.90 |
| 9 |
736-0232 |
Washer, .530 X .780 X .013 Wave This part replaces 01000874. Price: $4.02 |
| 10 |
01002829 |
HANDLE-HEI Not Available Price: |
| 11 |
01002832 |
HEIGHT LEVEL BRACKET Not Available Price: |
| 11 |
59-6820 |
CENTERING SPRING KIT Price: $50.64 |
| 12 |
710-0653 |
Hex Wash. Hd. Self-Tap Scr. 1/4-20 x .38" Lg. This part replaces 01000925. Price: $3.78 |
| 13 |
01002838 |
FRONT ADJUST BRACKET Not Available Price: |
| 14 |
01002839 |
FRONT ADJUST BRACKET Not Available Price: |
| 14 |
92-9732 |
PLATE-WEAR Price: $101.64 |
| 15 |
52-9320 |
DRIVE Price: $141.01 |
| 16 |
76-6300 |
GEROTOR ASM Price: $478.69 |
| 16 |
912-3027 |
Nut, Hex Flange Lock 1/4-20 This part replaces 01002766. Price: $3.85 |
| 17 |
76-6320 |
SPACER Price: $9.40 |
| 18 |
92-9730 |
CAP-END Price: $167.54 |
| 19 |
92-9736 |
SCREW-CAP Price: $4.82 |
| 20 |
59-6830 |
CENTERING PIN KIT Price: $3.98 |
| 21 |
52-9290 |
RETAINER-CHECKBALL Price: $15.41 |
| 22 |
52-9280 |
CHECKBALL Price: $7.01 |
| 24 |
52-9270 |
SEAT-CHECKBALL Price: $35.12 |
