| Ref | Part Number | Description |
|---|
| 1 |
3245-1 |
SCREW-SET, HSH Price: $0.54 |
| 1 |
575608801 |
PLATE, ENGINE W/DECALS This part replaces 574846302. Price: $179.99 |
| 1 |
DD-T4625-31203 |
CYL ASSEMBLY-HYD STEERI Not Available Price: |
| 2 |
115-3273 |
KIT-SERVICE, CYLINDER This part replaces 83-2340. Price: $679.02 |
| 2 |
574846402 |
PLATE, IDLER, BLK Price: $79.99 |
| 2 |
DD-T4625-31183 |
STEERING CYLINDER SUPPORT PIN Not Available This part replaces DD-T4625-31181. Price: |
| 3 |
574870901 |
BELT, HYDRO, 3400 Price: $34.99 |
| 3 |
DD-05511-50335 |
COTTER PIN Not Available Price: |
| 4 |
574811001 |
PULLEY, V, 1.125 BORE Price: $39.99 |
| 4 |
DD-T4520-43941 |
BOLT-AXLE CASE Not Available Price: |
| 5 |
596739801 |
PULLEYS This part replaces 539976688. Price: $29.99 |
| 5 |
83-2350 |
DISCONTINUED Price: Call Us |
| 5 |
DD-02076-50140 |
HEX NUT Not Available Price: |
| 6 |
596481401 |
Pulleys This part replaces 539107620. Price: $22.99 |
| 6 |
DD-T4625-31172 |
BRACKET-STEERING CYL MOUNTING Not Available Price: |
| 7 |
510041603 |
ARM, IDLER, STEEL, W/BGS Price: $49.99 |
| 8 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 Price: $17.99 |
| 9 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 Price: $19.99 |
| 9 |
83-2360 |
ROD ASM Price: $800.51 |
| 9 |
DD-T4625-31151 |
SPACER-SUPPORT PIN Not Available Price: |
| 10 |
510206301 |
PIVOT, BEARING Price: $3.99 |
| 10 |
DD-T4625-31162 |
PIN-CYLINDER SUPPO Not Available Price: |
| 11 |
525435601 |
PIVOT, IDLER Price: $5.99 |
| 11 |
DD-01120-50814 |
HEX BOLT Not Available Price: |
| 12 |
574607001 |
CLUTCH 200 FT LB Price: $379.99 |
| 12 |
83-2370 |
BARREL ASM Price: $649.63 |
| 12 |
DD-T4625-31131 |
ROD ASSEMBLY-TIE Not Available Price: |
| 13 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 13 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 13 |
DD-06613-20010 |
GREASE FITTING Not Available Price: |
| 14 |
510254402 |
Springs This part replaces 510254401. Price: $5.99 |
| 14 |
DD-04512-50120 |
LOCK WASHER Not Available Price: |
| 15 |
596394601 |
Shields This part replaces 539114662. Price: $2.99 |
| 15 |
DD-01173-51240 |
BOLT Not Available Price: |
| 16 |
510254502 |
SHIELD DUST This part replaces 510254501. Price: $3.99 |
| 16 |
DD-T4520-63771 |
NUT-SUPPORT PIN Not Available Price: |
| 17 |
539912757 |
KEY, 1/4 SQ X 1 1/4 Price: $3.99 |
| 17 |
DD-T4625-31451 |
SPACER-SUPPORT PIN Not Available Price: |
| 18 |
575229902 |
BRKT, MUFFLER, BLK Price: $29.99 |
| 19 |
539131604 |
MUFFLER ASM TWIN Price: $39.99 |
| 19 |
DD-T4625-31191 |
END ASSEMBLY-TIE ROD (LH) Not Available Price: |
| 20 |
539101714 |
SOLENOID Price: $22.99 |
| 20 |
DD-T4620-31051 |
Tie Rod End Ass'y (RH) Price: Call Us |
| 21 |
575017305 |
STOP CLUTCH STOP This part replaces 575017302. Price: $12.99 |
| 21 |
DD-T4625-63701 |
NUT-TIE ROD (LH) Not Available Price: |
| 22 |
539102759 |
INSULATOR Price: $3.99 |
| 22 |
DD-T4520-63701 |
NUT-TIE ROD (RH) Not Available Price: |
| 23 |
584825501 |
HOSE.ASSEMBLY.OIL.DRAIN Price: $27.99 |
| 23 |
DD-T2630-31331 |
COVER-CYLINDER (LH) Not Available Price: |
| 24 |
539102757 |
CABLE POSITIVE Price: $7.99 |
| 24 |
DD-T2630-31341 |
COVER-CYLINDER (RH) Not Available Price: |
| 25 |
539101363 |
CLAMP Price: $2.99 |
| 25 |
DD-01025-50614 |
HEX BOLT Not Available Price: |
| 26 |
596582701 |
Screws This part replaces 539990302. Price: $2.99 |
| 26 |
DD-01173-51445 |
HEX BOLT Not Available Price: |
| 27 |
525866201 |
HHFS 3/8-16 X 2.0 GD 5 Price: $3.99 |
| 28 |
525464701 |
HHFS 5/16-18 X 3/4 Price: $2.99 |
| 29 |
817120616 |
SCREW 3/8-16X1 This part replaces 532120616. Price: $4.99 |
| 30 |
596437001 |
Screws This part replaces 539990071. Price: $2.99 |
| 31 |
581332806 |
Bolts This part replaces 581332802. Price: $6.99 |
| 32 |
539103433 |
HCS 1/2C X 3 1/4 Price: $5.99 |
| 33 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 34 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 35 |
539100413 |
RHSNB 3/8-16 X 1-1/4 Price: $2.99 |
| 36 |
596435701 |
Bolts This part replaces 539107271. Price: $2.99 |
| 37 |
596581801 |
Bolts This part replaces 539130235. Price: $2.99 |
| 38 |
539107475 |
BOLT 5/16-18 X 3/4 Price: $4.99 |
| 39 |
521991102 |
NUT 1/2-13 HEX FLANGE NYLOK CL This part replaces 521991101. Price: $3.99 |
| 40 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539108120. Price: $1.99 |
| 41 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 42 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 43 |
596230801 |
Nuts This part replaces 539200282. Price: $2.99 |
| 44 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 45 |
596917301 |
Washers This part replaces 539111897. Price: $4.99 |
| 46 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 47 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 48 |
539990053 |
WASHER 1/4 INT TOOTH Price: $2.99 |
| 49 |
595316401 |
Washers This part replaces 539109554. Price: $2.99 |
| 50 |
596581701 |
Washers This part replaces 539115528. Price: $2.99 |
| 51 |
539109562 |
WASHER 3/8 X 3/4 X .187 TK Price: $3.99 |
