| Ref | Part Number | Description |
|---|
| 1 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 1 |
159944X428 |
Wheel Steering Price: Call Us |
| 2 |
165854 |
Axle Asm Cast Iron LT Price: Call Us |
| 2 |
42-6080 |
SHIM-AXLE Price: $29.45 |
| 3 |
169840 |
Spindle Asm LH Price: Call Us |
| 3 |
66-6480 |
WASHER Price: $1.29 |
| 4 |
169839 |
Spindle Asm RH Price: Call Us |
| 4 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 5 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 5 |
6266H |
Bearing Race Thrust Harden Price: Call Us |
| 6 |
108-0640-03 |
DISCONTINUED Price: Call Us |
| 6 |
121748X |
Washer 25/32 X 1-5/8 X 16 Ga Price: Call Us |
| 7 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 8 |
12000029 |
Ring Klip #t5304-75 Price: Call Us |
| 8 |
75-6850 |
DISCONTINUED Price: Call Us |
| 9 |
27-3710 |
DIPSTICK Price: $24.62 |
| 10 |
169832 |
Link Drag Price: Call Us |
| 10 |
85-4330 |
COVER-GEAR Price: $9.42 |
| 11 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 11 |
237-181 |
O-RING Price: $2.48 |
| 12 |
3218-1 |
NUT-JAM Price: $1.29 |
| 13 |
136518 |
Spacer Brg Axle Front Price: Call Us |
| 13 |
85-4350 |
SENSOR-GEARTOOTH Price: $310.23 |
| 15 |
145212 |
Nut Hex Flange Lock Price: Call Us |
| 15 |
32108-9 |
SCREW-FH Price: $2.55 |
| 16 |
106-9206 |
DECAL-TORQUE, WHEEL Price: $10.62 |
| 17 |
156546 |
Shaft Asm Strg Price: Call Us |
| 17 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 18 |
321-2 |
SCREW-HH Price: $2.79 |
| 18 |
57079 |
Washer Thrust 515x 750x 033 Price: Call Us |
| 19 |
160395 |
Support Shaft Price: Call Us |
| 19 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 20 |
85-4340 |
PLATE-MOUNTING, SENSOR Price: $52.00 |
| 21 |
32144-112 |
SCREW-HWH Price: $0.99 |
| 22 |
165857 |
Screw Hex Wsh Hd Torx Price: Call Us |
| 22 |
92-5797 |
GASKET-AXLE Price: $8.68 |
| 23 |
165851 |
Shaft Asm Pittman Price: Call Us |
| 24 |
324-7 |
SCREW-HH Price: $1.79 |
| 25 |
154406 |
Bracket Steering Price: Call Us |
| 27 |
136874 |
Gear Sector Price: Call Us |
| 29 |
17060612 |
Screw 3/8-16 x .75 Price: Call Us |
| 32 |
171888 |
Rod Tie Price: Call Us |
| 33 |
19111216 |
Washer 11/32 x 3/4 x 16 Ga Price: Call Us |
| 34 |
10040500 |
Washer Lock Hvy Hlcl Spr 5/16 Price: Call Us |
| 35 |
73540500 |
Crownlock Nut 5/16-24 Unf Price: Call Us |
| 36 |
155099 |
Bushing Strg Price: Call Us |
| 37 |
152927 |
Screw Price: Call Us |
| 38 |
159946X428 |
Insert Cap Strg Wh Price: Call Us |
| 39 |
19132411 |
Washer 13/32 X 1-1/2 X 11 Ga Price: Call Us |
| 40 |
7810H |
Lock nut Price: Call Us |
| 41 |
159945 |
Adaptor Wheel Strg Price: Call Us |
| 42 |
145054X428 |
Boot Steering Dash Price: Call Us |
| 43 |
121749X |
Washer 25/32 X 1 1/4 X 16 Ga Price: Call Us |
| 44 |
153720 |
Extension Steering Shaft LR/LT Price: Call Us |
| 46 |
121232X |
Cap Spindle Fr Top Blk Price: Call Us |
| 47 |
6855M |
Fitting Grease Price: Call Us |
| 51 |
73800500 |
Nut Lock Hex w/Ins 5/16-18 Price: Call Us |
| 54 |
74780520 |
Bolt Fin Hex 5/16-18 Unc x 1-1/4 Price: Call Us |
| 62 |
167902 |
Kit, Steering Assembly Svc Price: Call Us |
| 63 |
74780616 |
Bolt Fin Hex 3/8-16unc x 1 Gr. 5 Price: Call Us |
| 65 |
160367 |
Spacer Brace Axle Price: Call Us |
| 66 |
154404 |
Bearing Arm Pittman Price: Call Us |
| 67 |
72140618 |
Bolt Rdhd Sq 3/8-16 Unc x 2-3/4 Price: Call Us |
| 68 |
169827 |
Axle, Brace Price: Call Us |
| 79 |
19132012 |
Washer 13/32 x 1-1/4 x 12 Ga. Price: Call Us |
| 80 |
74950612 |
Bolt Hex Nylon 3/8-16 x 3/4 Price: Call Us |
| 82 |
169835 |
Bracket Susp Chassis Front Price: Call Us |
