| Ref | Part Number | Description |
|---|
| 1 |
93-5539 |
HOSE-PEUGEOT Price: $12.79 |
| 2 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
2412-111 |
CLAMP Price: $4.39 |
| 5 |
33103-020 |
SCREW-HHF Price: $2.16 |
| 6 |
33023-00 |
NUT-LOCK Price: $0.25 |
| 7 |
33105-020 |
SCREW-HHF Price: $0.54 |
| 8 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 9 |
93-5197 |
SPACER-IDLER Price: $10.86 |
| 10 |
66-5310-03 |
V PULLEY-IDLER This part replaces 93-5194. Price: $75.13 |
| 11 |
33005-00 |
NUT-HF Price: $0.68 |
| 11 |
532179335 |
CLUTCH MZ ZTR GT.48/54"1.125" Price: $299.99 |
| 12 |
532194343 |
PULLEY ENGINE Price: $39.99 |
| 12 |
93-5504-03 |
LEVER This part replaces 93-5504. Price: $11.57 |
| 13 |
93-5166 |
DISCONTINUED Price: Call Us |
| 14 |
33104-020 |
SCREW-HHF Price: $2.07 |
| 15 |
33125-045 |
SCREW-CARR Price: $2.37 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 16 |
93-5096-03 |
BRACKET-DEGASSER This part replaces 93-5096. Price: $38.69 |
| 17 |
33104-020 |
SCREW-HHF Price: $2.07 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532430217. Price: $14.99 |
| 20 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $24.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532178151 |
GASKET Price: $4.99 |
| 70 |
583955601 |
TUBE.EXHAUST.LH.FR961/FR730 This part replaces 532424765. Price: $24.99 |
| 71 |
583955701 |
TUBE.EXHAUST.RH.FR961/FR730 This part replaces 532424766. Price: $24.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 87 |
532198239 |
BOLT.5/16-18UNCX1.W/SEMS.BLK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
