| Ref | Part Number | Description |
|---|
| 1 |
304-46 |
DRAINCOCK Price: $7.55 |
| 1 |
539105486 |
WHEEL/TIRE.ASM.24X12-12.SILVER Price: $379.99 |
| 2 |
32104-116 |
SCREW-HWHTF Price: $0.55 |
| 3 |
32128-44 |
NUT Price: $2.69 |
| 4 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 5 |
119-2028 |
RADIATOR AND OIL COOLER ASM Price: $1,787.22 |
| 5 |
525611902 |
FORK.CASTER.ORANGE Price: $219.99 |
| 6 |
121-3556-0P |
SHROUD-FAN, UPPER This part replaces 121-3556-03. Price: $127.39 |
| 6 |
596623501 |
Zerks This part replaces 539101474. Price: $2.99 |
| 7 |
121-3552-0P |
SHROUD-FAN, LOWER This part replaces 121-3552-03. Price: $184.71 |
| 7 |
539105518 |
AXLE SPACER Price: $7.99 |
| 8 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 8 |
510034003 |
Caps This part replaces 510034001. Price: $5.99 |
| 9 |
510034301 |
SEAL, BEARING Price: $4.99 |
| 9 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 10 |
120-3530-0P |
BRACKET-RADIATOR, BOTTOM This part replaces 120-3530-03. Price: $78.45 |
| 10 |
510034401 |
BEARING W/CUP TAPPER ROLLER Price: $17.99 |
| 11 |
594946501 |
GSPW Screws This part replaces 539105517. Price: $5.99 |
| 12 |
522842602 |
Nuts This part replaces 522842601. Price: $3.99 |
| 13 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 13 |
521991102 |
NUT 1/2-13 HEX FLANGE NYLOK CL This part replaces 521991101. Price: $3.99 |
| 14 |
121-3557-0P |
BRACKET-RESEVOIR This part replaces 121-3557-03. Price: $26.66 |
| 14 |
595086801 |
Washers This part replaces 539990250. Price: $2.99 |
| 15 |
574824702 |
Washers This part replaces 574824701. Price: $5.99 |
| 20 |
95-8702-0P |
SHIELD-RADIATOR, LOWER This part replaces 95-8702-03. Price: $47.95 |
| 21 |
99-3497 |
MAGNET Price: $20.22 |
| 23 |
121-3558 |
HOSE-RADIATOR, UPPER Price: $46.41 |
| 24 |
120-3399 |
HOSE-RADIATOR, LOWER Price: $41.62 |
| 25 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 26 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 27 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 28 |
92-7536 |
HOSE-HYD Price: $196.76 |
| 33 |
99-7435 |
RELAY Price: $32.43 |
| 34 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 35 |
109-0274 |
HOSE-FUEL Price: $12.99 |
| 37 |
121-3609 |
TUBE-HYD Price: $143.00 |
| 38 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 40 |
108-0638 |
BOTTLE-OVERFLOW This part replaces 104-9318. Price: $33.20 |
| 41 |
93-6681 |
DECAL-WARNING, FAN Price: $11.51 |
| 42 |
32128-20 |
NUT-HF Price: $0.99 |
| 43 |
120-3529-03 |
BRACKET-RADIATOR, TOP Price: $62.39 |
| 44 |
120-3531-0P |
BRACKET-RADIATOR, LH This part replaces 120-3531-03. Price: $54.92 |
