| Ref | Part Number | Description |
|---|
| 1 |
47_584_02 |
Module-Ignition Price: Call Us |
| 2 |
X-25-79 |
Washer Price: Call Us |
| 3 |
X-156-1 |
Screw Price: Call Us |
| 4 |
237878 |
Stator Price: Call Us |
| 5 |
X-67-51 |
Screw Price: Call Us |
| 6 |
X-67-59 |
Screw-Hex Hd Price: Call Us |
| 7 |
X-728-1 |
Clip Price: Call Us |
| 8 |
235_173 |
Clip Price: Call Us |
| 9 |
X-132-6 |
Screw Price: Call Us |
| 10 |
41_155_03 |
Connector Price: Call Us |
| 11 |
235041-5 |
Plug-Spark Price: Call Us |
| 11 |
601000073 |
SCREW, 5/16-18X .75 HHC Price: $2.99 |
| 12 |
25_755_03 |
Kit-Rectifier/Regulator (Incl. Ref. #2) Price: Call Us |
| 12 |
601000023 |
WASHER, HVSPTLK .328X.60X Price: $2.99 |
| 13 |
X-132-5 |
Screw Price: Call Us |
| 14 |
236602 |
Connector Price: Call Us |
| 15 |
210281 |
Clip-Cable Price: Call Us |
| 20 |
601002156 |
BRACKET, IDLER ARM Price: $8.99 |
| 21 |
601001329 |
BOLT Price: $3.99 |
| 27 |
601002060 |
SPRING, IDLER Price: $37.99 |
| 29 |
601000059 |
NUT, 5/16-18 REGHEXCTRLK Price: $5.99 |
| 30 |
601002157 |
MP SUPPORT, ENGINE Price: $5.99 |
| 31 |
601001640 |
SCREW 5/16-18X.50 Price: $3.99 |
| 32 |
601000059 |
NUT, 5/16-18 REGHEXCTRLK Price: $5.99 |
| 45 |
601001333 |
IDLER PULLEY Price: $32.99 |
| 46 |
601000551 |
BOLT, 3/8-16X1.50 CARR Price: $3.99 |
| 47 |
601001335 |
NUT Price: $3.99 |
| 60 |
601001757 |
CABLE, DRIVE CONTROL Price: $43.03 |
| 64 |
601001758 |
SCREW, 1/4-20 X 1.50 Price: $2.90 |
| 65 |
601000018 |
WASHER, FLAT .281X .63X. Price: $1.99 |
| 66 |
601002318 |
RP NUT Price: $9.99 |
| 67 |
601001759 |
COVER, CABLE SPRING Price: $2.92 |
| 70 |
601002158 |
PULLEY, 10-RIB POLY-V Price: $16.99 |
| 73 |
601002080 |
BOLT, SHOULDER Price: $3.99 |
| 74 |
601003081 |
BELT, 10 RIB POLY-V Price: Call Us |
| 75 |
601400059 |
GUIDE, BELT 21 STEEL This part replaces 601002082. Price: $5.99 |
| 78 |
601002159 |
WASHER, FLAT Price: $1.99 |
