| Ref | Part Number | Description |
|---|
| 1 |
66-0120 |
KNOB Price: $5.53 |
| 2 |
54-1451 |
CONTROL-CHOKE,THROTTLE Price: $63.22 |
| 3 |
33113-020 |
SCREW-HH Price: $0.26 |
| 4 |
33093-00 |
WASHER-FLAT Price: $0.70 |
| 6 |
113050 |
COVER-PTO SWITCH Price: $47.16 |
| 7 |
33023-00 |
NUT-LOCK Price: $0.25 |
| 8 |
104-2541 |
SWITCH ASM This part replaces 88-9830. Price: $36.70 |
| 9 |
98-5320 |
DECAL - IGNITION Price: Call Us |
| 10 |
3254-5 |
WASHER-LOCK Price: $0.49 |
| 11 |
218-461 |
NUT-HH Price: $2.50 |
| 12 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 13 |
98-5319 |
DECAL - CONTROL PANEL Price: $45.51 |
| 14 |
98-5633 |
PLATE VALVE Price: Call Us |
| 15 |
98-5346 |
DECAL - LIFT OPERATION Price: Call Us |
| 17 |
116716 |
Switch-Clutch (Incl. Ref. #5, 18 19) Price: $55.58 |
| 18 |
218-498 |
NUT-LOCK This part replaces 105805. Price: $0.68 |
| 19 |
102950 |
TAB-WASHER Price: $1.63 |
| 20 |
98-5305 |
CONTROL ASM - THROTTLE Price: Call Us |
| 503235108 |
503235111 |
SPARK PLUG M14X1.25 NGK BPMR7A This part replaces 503235108. Price: $4.99 |
| 503255601 |
577572401 |
NEEDLE BEARING PISTON PIN 12X1 This part replaces 503255601. Price: $11.99 |
| 503289014 |
503289014 |
PISTON RING Price: $12.99 |
| 503552201 |
503552201 |
CYLINDER PLUG Price: $6.99 |
| 503916501 |
503916502 |
HEAT DEFLECTOR This part replaces 503916501. Price: $8.99 |
| 503916601 |
503916601 |
GASKET Price: $4.99 |
| 503966601 |
503966601 |
GASKET Price: $7.99 |
| 537022601 |
537022601 |
SUPPORT Price: $6.99 |
| 537096101 |
537096101 |
SLEEVE Price: $5.99 |
| 537113203 |
537427803 |
HOSE COMPLETE This part replaces 537113203. Price: $19.99 |
| 537126803 |
537126805 |
DECOMPRESSION VALVE This part replaces 537126803. Price: $22.99 |
| 537180001 |
537180001 |
PROTECTIVE CAP Price: $3.99 |
| 537219602 |
537219602 |
PISTON ASSY Price: $99.99 |
| 537222901 |
537222901 |
SCREW Price: $2.99 |
| 537244501 |
537244501 |
HOSE CLIP Price: $4.99 |
| 537248502 |
537248504 |
CYLINDER This part replaces 537248502. Price: $229.99 |
| 725533355 |
725533355 |
SCREW MC6S 5X25 Price: $3.99 |
