| Ref | Part Number | Description |
|---|
| 0 |
632129B |
CARBURETOR This part replaces 632129. Price: $76.06 |
| 1 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 1 |
530071459 |
Air Dam (kit) Price: $4.99 |
| 1 |
632130 |
SHAFT & LEV Price: $5.16 |
| 2 |
115-9830 |
SCREW-HSBH Price: $0.42 |
| 2 |
530071458 |
Gasket-Adapter (kit) Price: $5.99 |
| 3 |
120-6655 |
COVER-COLUMN Price: $103.73 |
| 3 |
530035502 |
Carburetor Adaptor Price: $1.24 |
| 4 |
120-0336 |
MOUNT-BRACKET, COLUMN Price: $70.33 |
| 4 |
530016309 |
Screw Price: $1.99 |
| 5 |
120-0314 |
HARNESS-WIRE, LIGHT KIT Price: $1,330.43 |
| 5 |
530071458 |
Gasket-Carburetor (kit) Price: $5.99 |
| 6 |
120-0334 |
SWITCH-ROCKER Price: $65.05 |
| 6 |
530071465 |
Kit-Carb Ass'y. (C1Q-W11) Price: $19.40 |
| 6 |
631036 |
SHUTTER Price: $1.20 |
| 7 |
119-7769 |
SWITCH-ROCKER, ON/NONE/ON Price: $62.03 |
| 7 |
530055103 |
Air Box Price: $1.80 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 8 |
530016340 |
Screw-Carb. Price: $1.99 |
| 9 |
530049383 |
Filter-Air Price: $1.99 |
| 9 |
701493 |
NUT-SPEED Price: $4.49 |
| 10 |
120-3953 |
SWITCH-PADDLE, ON/OFF/ON Price: $64.08 |
| 10 |
530055104 |
Cover-Air Filter Price: $2.99 |
| 10 |
631888 |
SHAFT & LEV Price: $5.16 |
| 11 |
120-0363-03 |
BRACKET-COLUMN Price: $67.56 |
| 11 |
530016354 |
Screw-Air Box Cover Price: $3.33 |
| 12 |
104-6957 |
DECAL-HORN Price: $15.75 |
| 12 |
530016349 |
Screw Price: $1.99 |
| 13 |
112-3313 |
NUT-WEATHERPROOF Price: $5.23 |
| 13 |
530055722 |
Assy-Muffler Cover Price: $3.24 |
| 14 |
31837 |
SHUTTER Price: $1.18 |
| 14 |
32128-17 |
NUT-LOCK, FLANGE Price: $0.25 |
| 14 |
530095469 |
Handle Price: $7.99 |
| 15 |
119-9880 |
MODULE-FLASHER Price: $128.00 |
| 15 |
530015886 |
Screw Price: $1.99 |
| 15 |
630735 |
SPRING Price: $1.25 |
| 16 |
112-3324 |
SWITCH-HORN Price: $39.90 |
| 16 |
530049323 |
Isolator Price: $2.99 |
| 16 |
632164 |
FUEL FITTING This part replaces 631803. Price: $5.95 |
| 17 |
32180-033 |
GROMMET Price: $17.75 |
| 17 |
530071459 |
Foam 25.4mm (kit) Price: $4.99 |
| 18 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 18 |
530016324 |
Clamp-Blower Tube Price: $4.99 |
| 19 |
530016322 |
Knob-Tube Clamp Price: $1.99 |
| 19 |
631201 |
CHECK VALVE Price: $15.40 |
| 20 |
530055146 |
Housing-Right Price: $22.99 |
| 20 |
632102 |
ADJ SCREW Price: $2.60 |
| 21 |
530402044 |
Spring-Cover Latch Price: $3.99 |
| 21 |
630738 |
SPRING Price: $1.25 |
| 22 |
530049617 |
Guide-Starter Rope Price: $1.99 |
| 22 |
630739 |
WASHER Price: $1.25 |
| 23 |
530055145 |
Housing-Left Price: $22.99 |
| 23 |
630740 |
O RING Price: $1.49 |
| 24 |
530016207 |
Nut Price: $1.99 |
| 25 |
530036792 |
Isolator-Crankcase Price: $4.99 |
| 26 |
545058007 |
Assy-Fuel Tank This part replaces 530049491. Price: $22.99 |
| 27 |
530049527 |
Gasket-Fuel Tank Price: $1.99 |
| 28 |
530057973 |
Assy - Fuel Cap w/retainer This part replaces 530049386. Price: $7.99 |
| 29 |
530049656 |
Grommet-Shroud Price: $1.99 |
| 30 |
530069247 |
Kit-Line Carb/Purge Price: $3.99 |
| 31 |
530069216 |
Kit-Line Tank/Purge Price: $3.99 |
| 32 |
530095646 |
Assy-Fuel Pick-up Price: $2.99 |
| 33 |
530071459 |
Grommet-Fuel line (kit Price: $4.99 |
| 34 |
530095593 |
Tube - Blower BV - 2000 Price: $11.99 |
| 34 |
530095597 |
Tube - Blower BV - 1850 Price: $11.99 |
| 41 |
630740 |
O RING Price: $1.49 |
| 42 |
630739 |
WASHER Price: $1.25 |
| 43 |
630738 |
SPRING Price: $1.25 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
632554 |
WELCH PLUG This part replaces 630746. Price: $1.17 |
| 50 |
630978 |
DIAPHRAGM Price: $4.49 |
| 51 |
630750A |
GASKET Price: $3.00 |
| 52 |
631653 |
COVER Price: $7.61 |
| 53 |
650545 |
SCREW Price: $1.20 |
| 55 |
630932A |
INLET NEEDLE Price: $4.39 |
| 56 |
630742 |
GASKET Price: $1.25 |
| 57 |
631049 |
SPRING Price: $1.20 |
