| Ref | Part Number | Description |
|---|
| 1 |
127-8461 |
NO. 1 LIFT ARM ASM Price: $464.34 |
| 2 |
127-8470 |
NO. 5 LIFT ARM ASM Price: $500.66 |
| 3 |
127-8468 |
NO. 4 LIFT ARM ASM Price: $498.72 |
| 4 |
127-8524 |
PIN-LIFT ARM Price: $144.33 |
| 5 |
121-7855 |
BUMPER-RECESSED Price: $10.34 |
| 6 |
3234-27 |
SCREW-HHF Price: $5.97 |
| 12 |
163-3530 |
CYLINDER-HYDRAULIC This part replaces 119-6988. Price: $515.30 |
| 14 |
92-1298 |
PIN-LYNCH Price: $2.27 |
| 15 |
104-0046 |
PIN-SLIDE, CYLINDER Price: $10.19 |
| 16 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 17 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 18 |
163-3533 |
CYLINDER-HYDRAULIC This part replaces 127-8539. Price: $572.39 |
| 19 |
120-2183 |
WASHER-THRUST Price: $2.99 |
| 20 |
120-9962 |
HOOP-CHAIN Price: $20.74 |
| 21 |
63-8410 |
WASHER Price: $1.76 |
| 22 |
323-7 |
SCREW-HH Price: $0.65 |
| 23 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 24 |
84-2450 |
CHAIN-STRAIGHT, 4-LINK Price: $7.74 |
| 25 |
140-6244 |
PIVOT YOKE ASM This part replaces 127-8477. Price: $369.38 |
| 27 |
323-6 |
SCREW-HH Price: $0.66 |
| 28 |
107-4027 |
CAP Price: $12.59 |
| 29 |
107-7400 |
PIN-LYNCH Price: $9.56 |
| 36 |
127-8540 |
PIN-CYLINDER Price: $52.79 |
| 37 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 38 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 39 |
139-5995 |
GUIDE-HOSE, RH This part replaces 119-3920. Price: $32.43 |
| 40 |
139-5996 |
HOSE GUIDE ASM-LH This part replaces 119-3921. Price: $32.43 |
