| Ref | Part Number | Description |
|---|
| 1 |
None |
Drive, Right Angle |
| 1 |
108-1412 |
TURBO CHARGER ASM This part replaces 99-8332. Price: $3,754.74 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144927. Price: $149.99 |
| 2 |
105-3768 |
GASKET This part replaces 99-8333. Price: $31.56 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 2 |
TC-770026A |
HOUSING,RI Not Available Price: |
| 3 |
99-8334 |
BOLT Price: $0.69 |
| 3 |
TC-778046 |
GEAR Not Available Price: |
| 4 |
99-8335 |
FLANGE-MUFFLER Price: $305.34 |
| 4 |
TC-776188 |
SHAFT Not Available Price: |
| 5 |
99-8336 |
BOLT Price: $3.41 |
| 5 |
TC-776187 |
SHAFT,OUTP Not Available Price: |
| 6 |
100-2562 |
BOLT This part replaces 98-7610. Price: $2.79 |
| 6 |
TC-772035 |
COVER Not Available Price: |
| 7 |
98-7534 |
NUT Price: $0.48 |
| 7 |
TC-788028 |
GASKET-COVER PLATE Not Available Price: |
| 8 |
3253-4 |
WASHER-LOCK This part replaces 99-8339. Price: $0.25 |
| 8 |
532186491 |
BOX.BATTERY.MOUNT.FRONT.LT Price: $14.99 |
| 8 |
TC-780034 |
Bearing Assy, Ball Price: $75.80 |
| 9 |
105-3767 |
GASKET This part replaces 99-8340. Price: $29.57 |
| 9 |
TC-780024 |
Bearing Assy, Ball Price: $76.27 |
| 10 |
716-3014 |
RING, EXTERNAL RET Not Available Price: |
| 10 |
99-8342 |
STUD This part replaces 99-8341. Price: $0.84 |
| 11 |
716-3001 |
Ring, Snap Price: $3.96 |
| 11 |
99-8342 |
STUD Price: $0.84 |
| 12 |
TC-788029 |
OIL SEAL Not Available Price: |
| 13 |
TC-788030B |
GASKET-END CAP Not Available This part replaces TC-788030. Price: |
| 14 |
TC-792025 |
Screw, 10-24 X 1/2 Rd Hd Self-Tapping Not Available Price: |
| 15 |
TC-786029 |
CAP ASSEMBLY-SEAL & END Not Available Price: |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 16 |
TC-788031 |
Seal, Oil Price: $19.57 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $24.99 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 24 |
585555601 |
CABLE.FRBATT.W/WIRE.8GA.8 This part replaces 532400253. Price: $7.99 |
| 25 |
585555501 |
CABLE.STARTER.8GA.17.5 This part replaces 532412895. Price: $7.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 33 |
532140401 |
KEY MLD GEN DELTA Price: $5.99 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 40 |
532194276 |
HARNESS-CHASSIS SUB Price: $27.99 |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. This part replaces 532401763. Price: $19.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532174651. Price: $24.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 59 |
596941001 |
Outlets This part replaces 532400303. Price: $11.99 |
| 71 |
532401104 |
HARNESS.IGN.DASH.HUQ/P Price: $59.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 90 |
532400724 |
COVER.TERMINAL.BATTERY Price: $3.99 |
| 91 |
532190270 |
STRAP.BATTERY.MOUNT.FRONT(2 2) Price: $7.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 100 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 101 |
532198317 |
PIGTAIL.MATNLK.NEW.HAR Price: $6.99 |
| 102 |
532404454 |
HARNESS PIGTAIL PCH TEX ROS Price: $14.99 |
| 103 |
532407962 |
HARNESS PIGTAIL 12V OUTLET Price: $8.99 |
