| Ref | Part Number | Description |
|---|
| 2 |
353-481 |
LIFT CHECK ASM Price: $338.44 |
| 2 |
539112170 |
MANDREL.DECK.ASSEMBLY Price: $69.99 |
| 3 |
237-54 |
O-RING Price: $1.97 |
| 3 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 4 |
353-306 |
WASHER-BACKUP Price: $9.12 |
| 4 |
532174375 |
PULLEY.DRIVEN.DECK.48' Price: $34.99 |
| 5 |
353-305 |
O-RING Price: $10.91 |
| 5 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 6 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 7 |
353-302 |
O-RING Price: $10.13 |
| 7 |
539110732 |
DISCHARGE CHUTE 48" Price: $44.99 |
| 8 |
353-303 |
WASHER-BACKUP Price: $9.06 |
| 8 |
596646001 |
Springs This part replaces 539110735. Price: $3.99 |
| 9 |
595935501 |
Pins This part replaces 539110736. Price: $2.99 |
| 10 |
353-853 |
BOLT Price: $39.87 |
| 10 |
539113425 |
BLADE, 16-1/4" Price: $19.99 |
| 11 |
353-668 |
PLATE-COVER Price: $508.66 |
| 11 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 12 |
539113427 |
CONFINEMENT PLATE 48" BLK Price: $32.99 |
| 13 |
353-550 |
PLUG-HYD, HH Price: $10.71 |
| 13 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 14 |
353-848 |
O-RING Price: $0.89 |
| 14 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 15 |
353-957 |
CUP-SEAL Price: $16.26 |
| 15 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 16 |
353-958 |
WASHER Price: $13.57 |
| 17 |
532196104 |
PULLEY.IDLER.MWR.STATI.LH Price: $37.99 |
| 18 |
574827102 |
ARM, IDLER, BLK Price: $27.99 |
| 18 |
92-2547 |
SEAL-RETAINER Price: $15.10 |
| 19 |
353-733 |
SPACER-BONNET Price: $41.01 |
| 19 |
532177968 |
PULLEY.IDLER.FLAT Price: $27.99 |
| 20 |
353-417 |
COLLAR-STOP Price: $10.31 |
| 20 |
589766102 |
Pulleys This part replaces 539132728. Price: $27.99 |
| 21 |
353-831 |
SPRING Price: $13.22 |
| 21 |
575224501 |
BUSHING, IDLER Price: $27.99 |
| 22 |
353-529 |
PLATE-RETAINER, SEAL Price: $15.07 |
| 22 |
532133957 |
WHEEL GAGE DONUT Price: $11.99 |
| 23 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 23 |
92-3148 |
SPRING-TRACTION Price: $13.84 |
| 24 |
353-808 |
COLLAR-SPRING Price: $27.44 |
| 24 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 25 |
353-830 |
O-RING Price: $1.41 |
| 25 |
575224702 |
SHIELD.BELT.LH.ORANGE Price: $29.99 |
| 26 |
94-4248 |
COLLAR-SPOOL This part replaces 353-829. Price: $58.22 |
| 27 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 27 |
68-4240 |
BONNET ASSEMBLY This part replaces 354-26. Price: $42.76 |
| 28 |
354-28 |
SCREW-HS Price: $8.35 |
| 28 |
539108271 |
HCS 3/8-16 X 3-1/2 GR5 ZD Price: $4.99 |
| 29 |
353-851 |
BODY-RELIEF Price: $180.95 |
| 29 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 30 |
353-392 |
RING-PISTON Price: $13.94 |
| 30 |
596433701 |
GSPW Washers This part replaces 819141614. Price: $2.99 |
| 31 |
353-531 |
POPPET AND RING ASM Price: $229.51 |
| 31 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 32 |
353-328 |
SHIM (.040) Price: $3.53 |
| 32 |
539990923 |
RHSNB 3/8-16X1-3/4 Price: $2.99 |
| 33 |
353-329 |
SHIM (.020) Price: $2.10 |
| 33 |
596437601 |
Washers This part replaces 539104864. Price: $2.99 |
| 34 |
353-330 |
SHIM (.010) Price: $3.60 |
| 34 |
532178515 |
WASHER Price: $5.99 |
| 35 |
353-398 |
SPRING Price: $30.09 |
| 35 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 36 |
353-334 |
CAP-RELIEF Price: $55.48 |
| 36 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 37 |
52-5900 |
SCREW Price: $26.40 |
| 37 |
596241101 |
Bolts This part replaces 539113621. Price: $2.99 |
| 38 |
353-847 |
BONNET Price: $129.59 |
| 38 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 39 |
353-849 |
SLEEVE Price: $46.19 |
| 39 |
596230801 |
Nuts This part replaces 539200282. Price: $2.99 |
| 40 |
353-846 |
SPUD Price: $118.09 |
| 40 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 41 |
353-845 |
SLEEVE-DETENT Price: $79.50 |
| 41 |
594092501 |
Rods This part replaces 532179127. Price: $5.99 |
| 42 |
353-730 |
SPRING Price: $18.22 |
| 42 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 43 |
353-731 |
BALL Price: $12.95 |
| 43 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 44 |
353-398 |
SPRING This part replaces 353-855. Price: $30.09 |
| 44 |
575967202 |
SHIELD, BELT, RH 48 ORG Price: $34.99 |
| 45 |
3274-52 |
SCREW-HSH Price: $3.19 |
| 45 |
596580801 |
Bolts This part replaces 874780516. Price: $2.99 |
| 46 |
353-575 |
BOOT Price: $58.68 |
| 46 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810030500. Price: $2.99 |
| 47 |
93-3651 |
RETAINER-BOOT This part replaces 353-559. Price: $31.38 |
| 50 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 51 |
52-5860 |
COLLAR-SPOOL Price: $13.37 |
| 51 |
596437001 |
Screws This part replaces 817490408. Price: $2.99 |
| 52 |
354-122 |
DISC-SEAL Price: $6.92 |
| 52 |
596435201 |
Bolts This part replaces 874780740. Price: $2.99 |
| 53 |
574845602 |
BELT, 135" EL Price: $79.99 |
| 54 |
353-953 |
PLUG ASM Price: $182.79 |
| 54 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 55 |
353-844 |
PLUG Price: $75.53 |
| 55 |
596240801 |
GSPW Bolts This part replaces 539115574. Price: $3.99 |
| 56 |
353-850 |
O-RING Price: $1.17 |
| 56 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 57 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 57 |
596645601 |
Springs This part replaces 539106850. Price: $8.99 |
| 58 |
3274-84 |
SCREW-HSH Price: $2.51 |
| 58 |
532110485 |
BEARING Price: $11.99 |
| 59 |
38-0410 |
NUT-HEX Price: $5.77 |
| 60 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 60 |
83-1890 |
SWITCH-BALL Price: $63.08 |
| 61 |
354-129 |
ANTICAVITATION CHECK ASM This part replaces 353-483. Price: $152.63 |
| 61 |
596274401 |
Rods This part replaces 532400337. Price: $9.99 |
| 62 |
353-484 |
RETURN-BALL, CHECK Price: $139.05 |
| 62 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 63 |
353-737 |
BALL-CHECK Price: $14.19 |
| 64 |
92-2546 |
WIPER-SEAL Price: $4.56 |
