| Ref | Part Number | Description |
|---|
| a |
None |
Choke Shaft |
| aa |
None |
Oil Block |
| b |
None |
Choke Shaft Fiber O-Ring |
| bb |
None |
Idle Speed Adjusting Screw |
| c |
None |
Choke Return Spring |
| cc |
736P05037 |
FIBER WASHER Price: $0.12 |
| d |
None |
Flat Steel Washer |
| dd |
None |
Nylon/Plastic O-Ring |
| e |
None |
Choke Plate |
| ee |
None |
Sheetmetal Housing |
| f |
None |
Carburetor Body |
| ff |
None |
Throttle Plate |
| g |
711-06036 |
HINGE FLOAT PIN Price: $0.60 |
| gg |
None |
Throttle Shaft |
| h |
751P14036A |
NEEDLE VALVE Price: $5.16 |
| hh |
None |
Idle Jet O-Ring |
| i |
732P05251A |
NEEDLE VALVE SPRING This part replaces 732P05251. Price: $1.70 |
| ii |
None |
Idle Jet Assembly |
| j |
None |
Float |
| jj |
None |
Idle Jet Rivet |
| k |
951-11970 |
FUEL BOWL GASKET Price: $5.95 |
| l |
None |
Square-Ring |
| m |
None |
Idle Mixture Screw |
| n |
736-04629 |
WASHER Price: $3.56 |
| o |
None |
Screw M3×5 |
| p |
951-14972 |
CARBURETOR SOLENOID VALVE ASM Price: $40.38 |
| q |
None |
Solenoid Valve Washer |
| r |
951-12772 |
SEAT/FUEL BOWL BOLT O-RING Price: $3.63 |
| s |
None |
Fuel Bowl Bolt |
| t |
910-06752 |
DRAIN BOLT Price: $4.45 |
| u |
951-11349A |
FUEL DRAIN PLUG GASKET This part replaces 951-11349. Price: $3.66 |
| v |
None |
Fuel Bowl |
| w |
None |
Main Jet |
| x |
None |
Emulsion Tube |
| y |
None |
Screw M3×5 |
| z |
736-04638A |
LOCK WASHER This part replaces 736-04638. Price: $2.88 |
| 1 |
710-04919 |
BOLT M6-1 x 25 GR8.8 Price: $3.86 |
| 2 |
951-14914 |
VALVE COVER Price: $24.77 |
| 3 |
951-14913 |
VALVE COVER GASKET Price: $12.13 |
| 4 |
651P05491 |
ROCKER ARM (EXHAUST) Price: $12.09 |
| 5 |
651P05490 |
ROCKER ARM (INTAKE) Price: $11.76 |
| 6 |
911-06414 |
ROCKER ARM SHAFT Price: $5.04 |
| 7 |
915-05035 |
CAMSHAFT PIN Price: $6.79 |
| 8 |
951-14909 |
EXHAUST VALVE Price: $23.50 |
| 9 |
710-06291 |
BOLT M10-1.25 x 70 Price: $4.31 |
| 10 |
931-10868 |
SHROUD Price: $6.86 |
| 11 |
710-04915 |
BOLT M6-1 x 12 GR8.8 Price: $3.82 |
| 12 |
951-14912A |
VALVE CAP This part replaces 951-14912. Price: $3.03 |
| 13 |
951-14911A |
VALVE SPRING SEAT This part replaces 951-14911. Price: $4.64 |
| 14 |
951-14910 |
VALVE SPRING Price: $8.85 |
| 15 |
951-11964A |
INTAKE VALVE SEAL This part replaces 951-11964. Price: $9.96 |
| 16 |
951-14908 |
INTAKE VALVE Price: $23.50 |
| 17 |
710-05305 |
HOOK BOLT Price: $3.56 |
| 18 |
910-06299 |
STUD Price: $4.09 |
| 19 |
921-04744 |
EXHAUST GASKET Price: $6.13 |
| 20 |
907-06281 |
SHROUD - LEFT SIDE Price: $23.70 |
| 21 |
951-14915 |
INTAKE PIPE RING Price: $4.31 |
| 22 |
931-10879 |
INTAKE PIPE Price: $21.69 |
| 23 |
710-06292 |
BOLT M6 x 22 Price: $4.40 |
| 24 |
710-06319 |
STUD M6-1.00 x 92 Price: $5.48 |
| 25 |
951-14947 |
INTAKE GASKET Price: $7.16 |
| 26 |
951-05560 |
CARBURETOR ASSEMBLY HY-8X90 Price: $162.96 |
| 27 |
921-04745 |
AIR FLTER GASKET Price: $6.13 |
| 28 |
931-05262 |
INTAKE MANIFOLD Price: $18.07 |
| 29 |
712-05015 |
HEX NUT Price: $5.78 |
| 30 |
937-05066 |
AIR FILTER W/PREFILTER Price: $21.19 |
| 31 |
951-05492A |
AIR FILTER COVER Price: $29.29 |
| 32 |
710-06447 |
SELF TAPPING SCREW 4.8 x 16 Price: $4.45 |
| 33 |
715-04122 |
DOWEL PIN Price: $3.52 |
| 34 |
951-14898 |
SINGLE PUSH ROD Price: $19.91 |
| 35 |
951-15614 |
TAPPET Price: $5.95 |
| 36 |
951-10292A |
SPARK PLUG (F6RTC/RN11YC/BPR6ES) This part replaces 951-10292. Price: $6.35 |
| 37 |
710-06290 |
BOLT M5-.8 x 10 Price: $4.31 |
| 38 |
936-05113 |
FLAT WASHER: 5.3 x 10 x 1 Price: $5.10 |
| 39 |
918-07090 |
CYLINDER HEAD Price: $255.83 |
| 40 |
921-04743 |
CYLINDER HEAD GASKET Price: $14.47 |
| 41 |
951-05248 |
PISTON RING SET Price: $25.28 |
| 42 |
951-14905 |
PISTON Price: $48.83 |
| 43 |
911-06415 |
PISTON PIN Price: $8.96 |
| 44 |
951-11953A |
PISTON PIN SNAP RING This part replaces 951-11953. Price: $3.42 |
| 45 |
951-14902 |
CONNECTING ROD ASSEMBLY Price: $66.75 |
| 46 |
951-14073 |
CLAMP Price: $3.56 |
| 47 |
710-04916 |
BOLT M6-1 x 14 GR8.8 Price: $3.86 |
| 48 |
951-15920 |
REGULATOR ASSEMBLY Price: $120.63 |
| 49 |
915-05026 |
DOWEL PIN Price: $4.40 |
| 50 |
925-06300 |
ELECTRIC STARTER Price: $258.26 |
| 51 |
710-06286 |
BOLT M8-1.25 x 80 Price: $4.40 |
| 52 |
712-04276A |
ACORN NUT M6-1 This part replaces 712-04276. Price: $5.38 |
| 53 |
931-10337 |
SHROUD SCREEN COVER Price: $22.39 |
| 54 |
750-05320 |
SHROUD SPACER Price: $3.56 |
| 54 |
931-10876 |
ENGINE SHROUD Price: $52.10 |
| 55 |
710-05303 |
BOLT 5.5 x 25 Price: $3.56 |
| 56 |
951-12205 |
DEBRIS SHIELD Price: $9.07 |
| 57 |
910-06310 |
STUD Price: $6.37 |
| 58 |
912-05102 |
NUT M20 x 1.5 Price: $7.35 |
| 59 |
936-05110 |
WASHER 20.5 x 5 x 40 Price: $5.34 |
| 60 |
951-14889 |
VANE PLATE Price: $8.85 |
| 61 |
931-10866 |
COOLING FAN Price: $43.41 |
| 62 |
951-15766 |
Flywheel Price: $198.18 |
| 63 |
710-06448 |
BOLT M5 x 28 Price: $3.32 |
| 64 |
951-15859 |
CHARGING COIL Price: $94.77 |
| 65 |
710-04943 |
BOLT-M6-1 x 28 GR8.8 Price: $3.76 |
| 66 |
994-00128 |
IGNITION COIL ASSEMBLY Price: $79.31 |
| 67 |
951-14921 |
WIRE PLATE Price: $4.31 |
| 68 |
951-14922 |
BREATHER SCREEN Price: $4.31 |
| 69 |
937-05067 |
OIL SEAL 38 x 58 x 8 Price: $13.55 |
| 70 |
907-06254 |
BREATHER COVER Price: $7.20 |
| 71 |
921-04738 |
BREATHER COVER GASKET Price: $5.06 |
| 72 |
732-04718 |
BREATHER VALVE SPRING Price: $3.78 |
| 73 |
951-11614 |
BREATHER VALVE Price: $3.53 |
| 74 |
907-06255 |
BRACKET Price: $4.09 |
| 75 |
None |
CRANKCASE |
| 76 |
911-06416 |
GOVERNOR GEAR SHAFT Price: $4.31 |
| 77 |
936-05114 |
WASHER 8 x 0.8 x 16 Price: $4.40 |
| 78 |
951-12388 |
GOVERNOR SEAL Price: $3.69 |
| 79 |
714-04077 |
GOVERNOR SHAFT CLIP Price: $5.30 |
| 80 |
951-14918A |
CHOKE LINKAGE Price: $6.13 |
| 81 |
951-14919A |
GOVERNOR LEVER Price: $4.99 |
| 82 |
951-05249A |
THROTTLE BRACKET ASSEMBLY This part replaces 951-05249. Price: $34.50 |
| 83 |
723-04071A |
FUEL LINE SUPPORT CLAMP This part replaces 723-04071. Price: $2.77 |
| 84 |
751P22453 |
FUEL PUMP This part replaces 951-15872. Price: $28.47 |
| 85 |
710-05003A |
BOLT M6-1 x 18 This part replaces 710-05003. Price: $3.11 |
| 86 |
951-11700A |
CARBURETOR HOSE CLAMP This part replaces 951-11700. Price: $3.60 |
| 87 |
951-16488 |
BREATHER HOSE Price: $7.10 |
| 88 |
735-04129-9 |
FUEL HOSE (6.3 x 12.5 x 100) Price: $13.61 |
| 89 |
951-14091 |
PLUG Price: $4.09 |
| 90 |
951-14073 |
CLAMP Price: $3.56 |
| 91 |
735-04129-34 |
FUEL HOSE (6.3 x 12.5 x 180) Not Available Price: |
| 92 |
932-05291 |
GOVERNOR SPRING Price: $6.13 |
| 93 |
951-12231 |
THROTTLE LINKAGE SPRING Price: $3.68 |
| 94 |
951-14917 |
THROTTLE LINKAGE Price: $6.24 |
| 95 |
907-06280 |
SHROUD - RIGHT Price: $10.34 |
| 96 |
925-06302 |
GROUND WIRE CONNECTION Price: $4.60 |
| 97 |
921-04741 |
CRANKCASE COVER GASKET Price: $14.26 |
| 98 |
715-04096A |
DOWEL PIN 9 X 14 This part replaces 715-04096. Price: $3.66 |
| 99 |
715-04096A |
DOWEL PIN 9 X 14 This part replaces 715-04092. Price: $3.66 |
| 100 |
951-14916 |
VENTING HOSE Price: $4.31 |
| 101 |
951-05245 |
CRANKSHAFT ASSEMBLY Price: $253.31 |
| 102 |
751P10307A |
WOODRUFF KEY This part replaces 951-10307. Price: $2.01 |
| 103 |
936-05111 |
WASHER 38.3 x 54 x 1 Price: $4.40 |
| 104 |
917-05292A |
BALANCE SHAFT (LH) Price: $71.01 |
| 105 |
917-05293A |
BALANCE SHAFT (RH) Price: $71.01 |
| 106 |
936-05112 |
WASHER 17.2 x 26 x 1 Price: $4.40 |
| 107 |
951-05246 |
GOVERNOR GEAR ASSEMBLY Price: $30.73 |
| 108 |
919-05216 |
CAMSHAFT Price: $70.24 |
| 109 |
931-10867 |
FILTER COVER Price: $4.31 |
| 110 |
937-05069 |
BREATHER FILTER SCREEN Price: $4.20 |
| 111 |
951-14895 |
PRESSURE RELEASE COVER Price: $4.69 |
| 112 |
932-05290 |
PRESSURE RELEASE SPRING Price: $4.40 |
| 113 |
951-15588 |
OIL PUMP STEEL BALL Price: $3.50 |
| 114 |
951-12690 |
ENGINE OIL FILTER Price: $15.89 |
| 115 |
951-12253 |
SCREW JOINT OIL FILTER ADAPTER Price: $6.87 |
| 116 |
710-05313 |
BOLT M8 x 15 Price: $3.56 |
| 117 |
736-04560 |
OIL DRAIN PLUG WASHER Price: $3.68 |
| 118 |
951-05247 |
OIL PUMP ASSEMBLY Price: $51.44 |
| 119 |
921-04742 |
GASKET Price: $6.13 |
| 120 |
710-06289 |
BOLT M8 x 45 Price: $3.89 |
| 121 |
951-14896 |
OIL SEPARATOR Price: $4.69 |
| 122 |
710-05293 |
SCREW M6-1 x 16 Price: $4.37 |
| 123 |
710-06287 |
BOLT M6-1 x 45 CL5.8 Price: $4.40 |
| 124 |
924-05033A |
DIPSTICK ASSEMBLY This part replaces 924-05033. Price: $23.50 |
| 125 |
921-04739 |
O-RING Price: $4.31 |
| 126 |
921-04740 |
O-RING Price: $4.31 |
| 127 |
951-15515 |
CRANKCASE COVER W/GOVERNOR Price: $186.30 |
| 128 |
951-11644 |
ENGINE PLUG 3/8 NPT Price: $8.96 |
| 952Z8X90ZUA |
COMPLETE |
ENGINE 547cc Not Available This part replaces 752Z8X90ZUA. Price: 952Z8X90ZUA |
