| Ref | Part Number | Description |
|---|
| 1 |
127-3011 |
STUD Price: $8.87 |
| 2 |
125-7120 |
ALTERNATOR-12V Price: $755.08 |
| 2 |
532422027 |
SHAFT.ASM.CROSS.LIFT This part replaces 532195223. Price: $69.99 |
| 3 |
127-3190 |
NUT Price: $4.86 |
| 3 |
594018001 |
Levers This part replaces 532195231. Price: $17.99 |
| 4 |
127-2951 |
ROTOR ASM Price: $326.08 |
| 5 |
127-2983 |
BEARING-BALL Price: $23.48 |
| 6 |
127-2962 |
COVER Price: Call Us |
| 7 |
127-2952 |
FRAME ASM Price: Call Us |
| 8 |
127-2958 |
BEARING-BALL Price: $25.78 |
| 9 |
127-2959 |
PLATE-RETAINER Price: Call Us |
| 10 |
127-2960 |
SCREW Price: Call Us |
| 10 |
532196314 |
SPRING.TORSION.LIFT.HANDLE Price: $3.99 |
| 11 |
127-2961 |
STUD Price: Call Us |
| 12 |
127-2953 |
FRAME ASM Price: $57.52 |
| 13 |
127-2954 |
PULLEY Price: $69.59 |
| 14 |
127-2955 |
NUT Price: Call Us |
| 15 |
127-2957 |
COLLAR Price: $16.32 |
| 16 |
127-3002 |
REGULATOR ASM Price: $643.65 |
| 17 |
127-2963 |
HOLDER Price: $253.39 |
| 18 |
127-2993 |
HOLDER Price: $95.21 |
| 19 |
127-2956 |
BRUSH ASM Price: $8.83 |
| 20 |
127-2964 |
SPRING Price: $3.16 |
| 21 |
127-2965 |
SCREW Price: Call Us |
| 22 |
127-2966 |
SCREW Price: Call Us |
| 23 |
127-2999 |
COVER Price: $22.03 |
| 24 |
127-2967 |
BOLT Price: $9.43 |
| 25 |
127-2968 |
SCREW Price: $4.72 |
| 26 |
127-2969 |
BOLT Price: Call Us |
| 27 |
127-2970 |
BUSHING-INSULATION Price: Call Us |
| 28 |
127-2971 |
NUT Price: Call Us |
| 29 |
127-2972 |
WASHER Price: Call Us |
| 30 |
125-7230 |
NUT Price: $2.81 |
| 31 |
125-6947 |
SPACER Price: $21.65 |
| 32 |
127-2977 |
ADJUSTER Price: $113.82 |
| 33 |
125-7134 |
BOLT Price: $25.74 |
| 87 |
532194209 |
PIN.COTTER.7/16.BOW TI. Price: $2.99 |
| 88 |
532410710 |
SPRING.LIFT.ASSIST This part replaces 532195303. Price: $9.99 |
| 89 |
819191912 |
WASHER.CLEAR.ZINC Price: $2.99 |
| 90 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 91 |
589464807 |
Links This part replaces 532195181. Price: $14.99 |
| 97 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 98 |
581506903 |
Links This part replaces 532195270. Price: $9.99 |
| 100 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
