| Ref | Part Number | Description |
|---|
| 1 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 3 |
136-3375 |
NO.1 LIFTARM ASM This part replaces 108-4032. Price: $856.35 |
| 4 |
131-4201 |
PIN-PIVOT This part replaces 104-5525. Price: $20.50 |
| 5 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 6 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 7 |
328-7 |
SCREW-HH Price: $4.00 |
| 8 |
127-6429 |
LIFT CYLINDER ASM This part replaces 107-1979. Price: $710.40 |
| 9 |
127-6427 |
LIFT CYLINDER ASM This part replaces 107-1980. Price: $652.96 |
| 10 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 11 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 12 |
140-6431 |
PIVOT PIN ASM This part replaces 95-7158. Price: $37.92 |
| 13 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 14 |
125-1906 |
PIN-CYLINDER This part replaces 105-9889. Price: $27.84 |
| 15 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 16 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 17 |
105-3987-03 |
PLATE-SKID Price: $42.52 |
| 18 |
136-3377 |
NO.4 LIFTARM ASM This part replaces 108-4033. Price: $866.36 |
| 19 |
323-6 |
SCREW-HH Price: $0.66 |
| 20 |
108-4023 |
SHAFT-CARRIER, PIVOT Price: $62.44 |
| 21 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 22 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 23 |
104-1450 |
BOLT-CARR Price: $0.25 |
| 24 |
104-5585 |
BRACKET-SWITCH Price: $21.55 |
| 25 |
106-9288 |
SENSOR-PROXIMITY, FERROUS Price: $126.57 |
| 26 |
100-4872 |
PLATE-SWITCH, NEUTRAL Price: $11.84 |
| 27 |
32149-7 |
NUT-KEPS Price: $0.27 |
| 28 |
104-5689-03 |
BRACKET-SUPPORT, BUMPER Price: $62.97 |
| 29 |
87-3470 |
BUMPER Price: $18.89 |
| 31 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 32 |
105-9831-03 |
BRACKET-BUMPER, NO. 1 Price: $26.24 |
| 33 |
104-5680-03 |
FRAME-CARRIER, FRONT Price: $1,713.36 |
| 35 |
136-3510 |
CARRIER FRAME ASM This part replaces 104-5656. Price: $664.28 |
| 36 |
112-9900-03 |
GUARD-FOOT Price: $82.81 |
| 37 |
3234-18 |
SCREW-HHF Price: $0.87 |
| 38 |
93-8806 |
WASHER-HARDENED Price: $1.62 |
| 39 |
105-9822 |
SPACER Price: $3.16 |
| 40 |
105-9823 |
BUSHING-CARRIER Price: $5.52 |
| 41 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 42 |
323-11 |
SCREW-HH Price: $1.08 |
| 44 |
321-15 |
SCREW-HH Price: $0.61 |
| 45 |
32128-33 |
NUT-HF Price: $0.25 |
| 46 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 47 |
323-7 |
SCREW-HH Price: $0.65 |
| 48 |
136-3379 |
NO.5 LIFTARM ASM This part replaces 108-4034. Price: $894.10 |
