| Ref | Part Number | Description |
|---|
| 1 |
423302 |
Screen, Catcher Hood Price: Call Us |
| 2 |
04090-02 |
Pop Rivet, 3/16 x .652 Price: Call Us |
| 3 |
04041-19 |
Flatwasher, 3/16-.196 x .469 x .048 Price: Call Us |
| 4 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 5 |
04041-07 |
Flatwasher, 3/8-.391 x .938 x .105 Price: Call Us |
| 7 |
04001-161 |
Bolt, Hex Head 3/8-16 x 2-3/4" Price: Call Us |
| 8 |
423258 |
Hinge, Upper LH Price: Call Us |
| 9 |
04021-09 |
Nut, Elastic Stop 3/8-16 Price: Call Us |
| 10 |
423670 |
Spacer, Hitch Price: Call Us |
| 11 |
04001-46 |
Bolt, Hex Head 3/8-16 x 2-1/4" Price: Call Us |
| 12 |
04003-04 |
Bolt, Carriage 5/16-18 x 1.00" Price: Call Us |
| 13 |
04001-20 |
Bolt, Hex Head 3/8-16 x 1-1/2" B&S 32BV Price: Call Us |
| 14 |
04001-135 |
Bolt, Hex Head 3/8-16 x 1-3/4" Grade 8 Price: Call Us |
| 15 |
423690 |
Support Bracket, Catcher Price: Call Us |
| 16 |
04019-04 |
Nut, Serrated Flange 3/8-16 Price: Call Us |
| 17 |
04019-03 |
Nut, Hex Serrated Flange 5/16-18 Price: Call Us |
| 18 |
43546 |
Bushing, Hopper Pivot Price: Call Us |
| 19 |
482304 |
Spring, Hood Hinge Price: Call Us |
| 20 |
423436 |
Hinge, Lower LH Price: Call Us |
| 21 |
43212 |
Spacer, Deck Assist Price: Call Us |
| 22 |
04021-05 |
Locknut, 3/8-16 Price: Call Us |
| 23 |
43277 |
Spacer Price: Call Us |
| 24 |
423259 |
Hinge, Upper RH Price: Call Us |
| 25 |
423261 |
Hinge, Lower RH Price: Call Us |
| 26 |
48135-14 |
Hose, 8" Dia. x 60.5" Price: Call Us |
| 27 |
48136-02 |
Clamp, 8-5/8" Max Dia. Price: Call Us |
| 28 |
482422 |
Tube, Filler GC-STT Price: Call Us |
| 29 |
482421 |
Elbow, GC-STT Price: Call Us |
| 30 |
04001-10 |
Bolt, Hex Head 5/16-18 x 1-1/4" Price: Call Us |
| 31 |
04021-10 |
Nut, Elastic Stop 5/16-18 Price: Call Us |
| 32 |
04040-15 |
Flatwasher, 5/16-.375 x .875 x .083 Price: Call Us |
| 33 |
04041-11 |
Flatwasher, 3/8- .406 x 1-1/2" x .179 Price: Call Us |
| 34 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 35 |
04001-51 |
Bolt, Hex Head 3/8-16 x 3-3/4" Price: Call Us |
| 36 |
423828 |
Tube, Upright Price: Call Us |
| 37 |
04001-19 |
Bolt, Hex Head 3/8-16 x 1" Price: Call Us |
| 38 |
451596 |
Frame Weldment Price: Call Us |
| 39 |
04001-31 |
Bolt, Hex Head 3/8-16 x 2-1/2" Price: Call Us |
| 40 |
482409 |
Latch Price: Call Us |
| 41 |
04010-25 |
Screw, #10-32 x 3/4" Price: Call Us |
| 42 |
04021-01 |
Nut, Elastic Stop #10-32 Price: Call Us |
| 43 |
04001-08 |
Bolt, Hex Head 5/16-18 x 3/4" Price: Call Us |
| 44 |
04090-03 |
Rivet, 3/16 x .402 POP Price: Call Us |
| 45 |
451026 |
Support Weldment, Front Weights Price: Call Us |
| 46 |
422586 |
Clamp, Bar Price: Call Us |
| 47 |
04067-06 |
Pin, 1/2 x 6-1/4" Price: Call Us |
| 48 |
481737 |
Lanyard, Weight Pin Price: Call Us |
| 49 |
461097 |
Weight Assembly Price: Call Us |
| 50 |
451512 |
Hitch Bracket Weldment Price: Call Us |
| 51 |
451674 |
Support Weldment, Bag Frame Price: Call Us |
| 52 |
423435 |
Heat Shield Price: Call Us |
