| Ref | Part Number | Description |
|---|
| 1 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 2 |
3274-69 |
SCREW-HSBH Price: $0.43 |
| 3 |
107-2554 |
DECAL-PANEL, CONTROL This part replaces 93-8061. Price: $41.00 |
| 4 |
83-2030 |
PLATE-FILLER Price: $19.19 |
| 5 |
120-2244 |
HOURMETER This part replaces 66-2950. Price: $48.06 |
| 6 |
98-2160 |
VOLTMETER Price: $100.25 |
| 7 |
321-4 |
SCREW-HH Price: $0.99 |
| 8 |
80-9330 |
AUDIO ALARM ASM Price: $137.61 |
| 9 |
83-1530 |
BRACKET-SUPPORT, BUZZER Price: $13.54 |
| 10 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 11 |
70-1480 |
RELAY Price: $105.19 |
| 12 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 13 |
83-1660 |
SWITCH-3 POSITION Price: $98.62 |
| 14 |
83-2280 |
TIMER-DELAY Price: $126.04 |
| 15 |
586929102 |
FRAME.GBAG.AWD.21.BLACK Price: $17.99 |
| 16 |
83-0040 |
CONTROL-CHOKE Price: $36.29 |
| 17 |
3296-27 |
NUT-LOCK, NI Price: $0.27 |
| 17 |
532181698 |
SCREW, PHILLIPS HEAD 10 X 5/8 Price: $3.99 |
| 18 |
587421101 |
CABLE.DRIVE.21EFF.BS.AWD Price: $32.99 |
| 18 |
83-0030 |
CONTROL-THROTTLE Price: $39.07 |
| 19 |
104-2541 |
SWITCH ASM This part replaces 88-9830. Price: $36.70 |
| 19 |
582261901 |
CHUTE.DISCHARGE.21EFF.HW Price: $17.99 |
| 20 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 21 |
3273-26 |
SCREW-HSH Price: $0.41 |
| 23 |
32104-95 |
SCREW-HWH Price: $0.41 |
| 24 |
104-2058 |
HARNESS-WIRE, MAIN Price: $665.11 |
