| Ref | Part Number | Description |
|---|
| 1 |
131-1235 |
RIGHT DECK ASM Price: $2,726.27 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144925. Price: $149.99 |
| 2 |
112-1479 |
SKID-BUMPER, DECK Price: $95.09 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
3296-45 |
NUT-HEX Price: $3.79 |
| 3 |
596582301 |
Washers This part replaces 819091016. Price: $2.99 |
| 4 |
131-1231-01 |
PLATE-STIFFENER Price: $95.51 |
| 4 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 5 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 6 |
132-9421 |
PULLEY-IDLER, FLAT Price: $41.10 |
| 6 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $2.99 |
| 7 |
100-3102 |
WASHER-FLAT Price: $3.70 |
| 8 |
108-8076 |
V-BELT, DECK Price: $29.86 |
| 8 |
532404349 |
KIT.BOX.BATTERY.REAR.BOOT.POS This part replaces 532156417. Price: $24.99 |
| 9 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 10 |
139-1039 |
LOW DRIVEN SPINDLE ASM This part replaces 119-4776. Price: $589.65 |
| 11 |
32108-103 |
SCREW-FH Price: $0.68 |
| 12 |
69-9290 |
PAD-BUMPER Price: $9.52 |
| 13 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 14 |
104-2250-01 |
SKID-SIDE Price: $116.02 |
| 15 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 16 |
131-1243 |
PLATE-SPINDLE Price: $62.97 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN This part replaces 532153664. Price: $19.99 |
| 17 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 18 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 19 |
132-6150-01 |
BRACKET-CASTER Price: $155.45 |
| 20 |
100-5623 |
DECAL-HOC Price: $20.17 |
| 20 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873350400. Price: $2.99 |
| 21 |
120-5587 |
PIN-CLEVIS Price: $10.38 |
| 21 |
532136850 |
HARNESS LIGHT SOCKET Price: $15.99 |
| 22 |
104-7524 |
SHIM Price: $5.30 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
132-6157-01 |
BRACKET-FORK Price: $59.18 |
| 24 |
3231-33 |
SCREW-CARR Price: $4.29 |
| 24 |
532004799 |
BATTERY CABLE This part replaces 532124780. Price: $8.99 |
| 25 |
3233-2 |
SCREW-CARR Price: $1.49 |
| 25 |
532146147 |
CABLE BATTERY Price: $22.99 |
| 26 |
106-2047 |
ROD-TENSION Price: $9.83 |
| 26 |
532108824 |
FUSE HYT Price: $4.99 |
| 27 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 28 |
104-0858 |
BOLT-SHOULDER Price: $4.69 |
| 28 |
532004207 |
CABLE T This part replaces 532124773. Price: $4.99 |
| 29 |
532160784 |
PLUNGER SWITCH (COLOR:OLIVE) Price: $17.99 |
| 29 |
920242 |
WASHER-FLAT This part replaces 9202424. Price: $5.19 |
| 30 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 30 |
532140301 |
SWITCH.IGNITION.4.POSITION Price: $32.99 |
| 31 |
325-7 |
SCREW-HH Price: $1.53 |
| 31 |
532124211 |
NUT IGNITION Price: $4.99 |
| 32 |
32120-72 |
RING-SNAP Price: $2.09 |
| 32 |
532141226 |
COVER SWITCH KEY Price: $4.99 |
| 33 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 33 |
532122147 |
KEY.MOLDED.GENERIC Price: $5.99 |
| 34 |
110-6128 |
IDLER ARM ASM Price: Call Us |
| 35 |
32128-14 |
NUT-HF Price: $0.41 |
| 36 |
68-0090 |
SCREW-ADJUSTING Price: $7.49 |
| 37 |
139-1728 |
BOLT-HH FT This part replaces 9114524. Price: $1.29 |
| 38 |
107938 |
SPRING-EXTENSION Price: $9.99 |
| 39 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 40 |
532160720 |
HARNESS.IGNITION Price: $119.99 |
| 40 |
9136144 |
SCREW-HWHTF Price: $6.29 |
| 41 |
596437001 |
Screws This part replaces 871110408. Price: $2.99 |
| 41 |
70-1160 |
WASHER Price: $3.59 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
532146154 |
KIT SOLENOID .95 This part replaces 532145673. Price: $19.99 |
| 44 |
873640400 |
Nut, Keps Blk Hex 1/4-20 UNC Price: $2.99 |
| 48 |
532140844 |
ADAPTER.AMMETER Price: $4.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532154959. Price: $24.99 |
| 51 |
532140405 |
FRAME RETAINING RING Price: $3.99 |
| 52 |
532141940 |
WIRE PROTECTION LOOP Price: $4.99 |
| 70 |
532140422 |
HARNESS ENGINE Price: $8.99 |
| 80 |
532146685 |
HARNESS, CLUTCH Price: $11.99 |
| 81 |
532109748 |
RELAY.ASSY.T Price: $19.99 |
