| Ref | Part Number | Description |
|---|
| 1 |
532400108 |
NEEDS DESCRIPTION Price: Call Us |
| 2 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 3 |
532165569 |
BRACKET Price: $23.99 |
| 4 |
532165558 |
BRACKET Price: $14.76 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 6 |
532165557 |
BAR.SWAY.92.CRD Price: $6.99 |
| 8 |
583116901 |
BOLT.3/8-24X1.25 GR8 This part replaces 532181712. Price: $5.99 |
| 9 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 10 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 10 |
98-9620 |
OVERFLOW PIPE ASM Price: $44.29 |
| 11 |
532186385 |
NEEDS DESCRIPTION Price: Call Us |
| 13 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $29.99 |
| 14 |
532128774 |
HOUSING.MANDREL.VENTED (MACHD) Price: $29.99 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
532186386 |
NEEDS DESCRIPTION Price: Call Us |
| 17 |
595901101 |
Bolts This part replaces 872140610. Price: $3.99 |
| 18 |
596136001 |
Bolts This part replaces 872110606. Price: $3.99 |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $4.99 |
| 20 |
583117001 |
BOLT.3/8-24X1.25GR8. LHTHRD This part replaces 532181713. Price: $3.99 |
| 20 |
98-9431 |
SCREW-BLEEDER, AIR Price: $15.04 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
532199590 |
NEEDS DESCRIPTION Price: Call Us |
| 23 |
532165446 |
BRACKET Price: $5.99 |
| 24 |
532165242 |
BRACKET Price: $12.99 |
| 25 |
532165244 |
BRACKET Price: $22.99 |
| 26 |
583259301 |
BRACE.SUSP.FRONT.CRD/36.2006 This part replaces 532400110. Price: $29.99 |
| 27 |
532165568 |
BRACKET Price: $22.99 |
| 28 |
532165567 |
BRACKET Price: $17.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 30 |
98-7654 |
GASKET Price: $8.84 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
532173435 |
MANDREL.PULLEY.38.BRIGHT.ZINC This part replaces 532153532. Price: $19.99 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 34 |
532400107 |
NEEDS DESCRIPTION Price: Call Us |
| 35 |
532400106 |
NEEDS DESCRIPTION Price: Call Us |
| 36 |
593787801 |
PULLEYS This part replaces 532146763. Price: $27.99 |
| 40 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 40 |
98-9420 |
OVERFLOW PIPE ASM Price: $3.91 |
| 41 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 44 |
532175538 |
NEEDS DESCRIPTION Price: Call Us |
| 45 |
112-0182 |
PIPE-OVERFLOW Price: $3.78 |
| 45 |
532175539 |
COVER.MANDREL.RH.CRD Price: $17.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 50 |
98-7671 |
CLIP-PIPE Price: $2.39 |
| 55 |
583252901 |
ARM.IDLER.92.CRD./2006 This part replaces 532199498. Price: $22.99 |
| 56 |
532165723 |
SPACER.RETAINER.MOWER Price: $5.99 |
| 60 |
115-3018 |
NOZZLE HOLDER KIT Price: $440.14 |
| 61 |
583252601 |
SPRING.TENSION.92.CRD.2006 This part replaces 532199486. Price: $8.99 |
| 65 |
121-2411 |
NUT Price: $6.48 |
| 68 |
532402008 |
BELT.DRIVE.92CM.CRD.2006 Price: $69.99 |
| 69 |
532165482 |
SHAFT.ASM.W/LWR.BRG.RH.THREAD Price: $59.99 |
| 70 |
98-7676 |
GASKET Price: $2.73 |
| 80 |
98-7677 |
SEAL-HEAT Price: $10.17 |
| 84 |
597024901 |
Keepers This part replaces 532156085. Price: $3.99 |
| 90 |
98-9622 |
PIPE-INJECTION Price: $74.03 |
| 100 |
98-9654 |
PIPE-INJECTION Price: $76.86 |
| 110 |
98-9655 |
PIPE-INJECTION Price: $82.26 |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 119 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 120 |
98-7682 |
CLAMP-PIPE Price: $6.37 |
| 124 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 130 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 130 |
98-7683 |
CLAMP-PIPE Price: $3.66 |
| 131 |
532165661 |
CHUTE BAGGER Price: $79.99 |
| 140 |
98-7684 |
SCREW (W/WASHER) Price: $0.44 |
| 150 |
130-1411 |
PLUG-GLOW Price: $66.46 |
| 160 |
98-9631 |
CORD-PLUG, GLOW Price: $12.41 |
| 254 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 295 |
532412171 |
NEEDS DESCRIPTION Price: Call Us |
| 296 |
872110407 |
BOLT.CARRIAGE.1/4-20 X 7/8 This part replaces 872140406. Price: $3.99 |
