| Ref | Part Number | Description |
|---|
| 2 |
530042088 |
Muffler Spring Price: $1.99 |
| 3 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 3 |
530071391 |
Kit-Spark Arrestor Price: $7.99 |
| 4 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 4 |
8-8150 |
DISCONTINUED Price: Call Us |
| 5 |
503235112 |
Spark Plug This part replaces 952030201. Price: $5.99 |
| 6 |
3219-14 |
NUT-HEX Price: $0.25 |
| 6 |
530012416 |
Cylinder This part replaces 530069757. Price: $17.99 |
| 7 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 7 |
530069616 |
Gasket-Cylind./Carb. This part replaces 530069625. Price: $6.99 |
| 8 |
530069758 |
Kit - Carb. Adaptor Price: $8.99 |
| 8 |
8-8200 |
DISCONTINUED Price: $2.00 |
| 9 |
3217-6 |
NUT-HEX Price: $1.19 |
| 9 |
530016014 |
Screw Price: $1.99 |
| 10 |
2412-31 |
CLAMP-BODEN Price: $1.56 |
| 10 |
530069616 |
Gasket-Cylind./Carb. This part replaces 530069625. Price: $6.99 |
| 11 |
3-8947 |
DISCONTINUED Price: Call Us |
| 12 |
3220-7 |
NUT-JAM Price: $4.09 |
| 12 |
530047914 |
Choke Plate Mounting Price: $3.99 |
| 13 |
3-8928 |
DISCONTINUED Price: Call Us |
| 13 |
530047916 |
Choke Lever Price: $1.99 |
| 14 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 14 |
530015254 |
Washer Price: $1.99 |
| 15 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 15 |
530015849 |
Screw Price: $1.99 |
| 16 |
324-6 |
SCREW-HH Price: $0.81 |
| 16 |
530016141 |
Screw Price: $1.99 |
| 17 |
5-0786 |
KEY Price: $13.87 |
| 17 |
530015957 |
Screw This part replaces 530015966. Price: $1.99 |
| 18 |
3246-4 |
SCREW-SET Price: $0.75 |
| 18 |
530049079 |
Cover-Air Box Price: $2.99 |
| 19 |
321-2 |
SCREW-HH Price: $2.79 |
| 19 |
530047932 |
Foam-Air Filter Price: $1.99 |
| 20 |
530047908 |
Box-Air Price: $3.99 |
| 21 |
321-4 |
SCREW-HH Price: $0.99 |
| 21 |
530015852 |
Spacer-Choke Price: $1.99 |
| 22 |
49-8110 |
HANDLE GRIP This part replaces 235-11. Price: $13.80 |
| 23 |
3218-13 |
NUT-JAM, BRASS Price: $0.88 |
| 23 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 24 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 24 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 25 |
3254-8 |
WASHER-LOCK Price: $0.37 |
| 25 |
530069615 |
Assy-Connecting Rod Price: $14.99 |
| 26 |
5-1671 |
DISCONTINUED Price: Call Us |
| 26 |
530069616 |
Gasket-Cylind./Carb. This part replaces 530069625. Price: $6.99 |
| 27 |
5-1667 |
DISCONTINUED Price: Call Us |
| 27 |
530036145 |
Spacer-Module Price: $1.99 |
| 28 |
3-9351 |
EXT SPRING *R Price: $47.40 |
| 28 |
530055160 |
Ignition Module Price: $34.99 |
| 29 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 29 |
530015954 |
Screw Price: $1.99 |
| 30 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 30 |
530049389 |
Assy-Ground Wire Price: $1.99 |
| 31 |
3-8997 |
DISCONTINUED Price: Call Us |
| 31 |
530049390 |
Assy-Leadwire Price: $0.28 |
| 32 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 32 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 33 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 33 |
530071356 |
Kit-Momentary Switch Price: $4.99 |
| 34 |
323-7 |
SCREW-HH Price: $0.65 |
| 34 |
530027569 |
Handle-Starter Price: $1.99 |
| 35 |
3218-3 |
NUT-JAM Price: $0.25 |
| 35 |
530069232 |
Kit - Rope Price: $3.99 |
| 36 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 36 |
530016080 |
Screw Price: $1.99 |
| 37 |
5-2793 |
DISCONTINUED Price: Call Us |
| 37 |
530027953 |
Coupling-Drive Price: $1.99 |
| 38 |
5-1853 |
DISCONTINUED Price: Call Us |
| 38 |
530023817 |
Spring-Starter Dog Price: $1.99 |
| 39 |
321-6 |
SCREW-HH Price: $0.25 |
| 39 |
530015941 |
Retain. Ring-C'shaft Price: $1.99 |
| 40 |
3296-6 |
NUT-LOCK Price: $1.49 |
| 40 |
530032124 |
Bearing-Outer Price: $4.99 |
| 41 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 41 |
530019179 |
Seal-C'case Price: $2.99 |
| 42 |
5-0701 |
ANCHOR Price: $4.07 |
| 42 |
530015945 |
Retainer Ring-C'case Price: $1.99 |
| 43 |
3-9026 |
DISCONTINUED Price: Call Us |
| 43 |
530032125 |
Bearing-Inner Price: $11.99 |
| 44 |
3-8945 |
DISCONTINUED Price: Call Us |
| 44 |
530049233 |
Shroud Price: $3.33 |
| 45 |
3220-3 |
NUT-HJ Price: $0.28 |
| 45 |
530015880 |
Screw Price: $1.99 |
| 46 |
283-2 |
PIN-CLEVIS Price: $12.99 |
| 46 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 47 |
282-1 |
DISCONTINUED Price: Call Us |
| 47 |
530054536 |
Guard-Muffler Price: $1.99 |
| 48 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 48 |
530036793 |
Isolator-Shroud Price: $5.99 |
| 50 |
5-3840 |
DISCONTINUED Price: Call Us |
| 50 |
530054083 |
Assy-Crankshaft Price: $5.99 |
| 51 |
323-9 |
SCREW-HH Price: $1.29 |
| 51 |
530036792 |
Isolator-Crankcase Price: $4.99 |
| 52 |
321-6 |
SCREW-HH Price: $0.25 |
| 53 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 54 |
2212-16 |
DISCONTINUED Price: Call Us |
| 54 |
545221701 |
FLYWHEEL ASSY This part replaces 530069886. Price: $8.99 |
| 55 |
3-9263 |
DISCONTINUED Price: Call Us |
| 55 |
530015828 |
Washer-Flat Price: $1.99 |
| 56 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 56 |
530015957 |
Screw This part replaces 530015966. Price: $1.99 |
| 57 |
3217-5 |
NUT-HEX Price: $0.25 |
| 57 |
530016226 |
Retainer-Can Price: $1.99 |
| 58 |
3217-7 |
NUT-HEX Price: $0.28 |
| 59 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 59 |
545008011 |
KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 60 |
323-7 |
SCREW-HH Price: $0.65 |
| 60 |
530049468 |
Assy-Fan Housing Price: $17.99 |
| 61 |
2812-4 |
REDUCER-PIPE Price: $9.67 |
| 62 |
324-4 |
SCREW-HH Price: $0.95 |
| 62 |
530014347 |
Assy-Fuel Cap Price: $4.99 |
| 63 |
5-2390 |
DISCONTINUED Price: Call Us |
| 64 |
530095646 |
Assy-Fuel Pickup Price: $2.99 |
| 64 |
6-1626 |
Pulley, Engine Price: Call Us |
| 65 |
5-1628 |
DISCONTINUED Price: Call Us |
| 65 |
530069247 |
Kit-Fuel Line Price: $3.99 |
| 66 |
3-9066 |
DISCONTINUED Price: Call Us |
| 67 |
3-9001 |
DISCONTINUED Price: Call Us |
| 68 |
5-3270 |
DISCONTINUED Price: Call Us |
| 69 |
2811-9 |
FITTING-ELBOW-90 Price: $15.86 |
| 70 |
3290-153 |
DISCONTINUED Price: Call Us |
| 71 |
289-153 |
Nut, Conduit Price: Call Us |
| 72 |
288-3 |
DISCONTINUED Price: Call Us |
| 73 |
5-2665 |
DISCONTINUED Price: Call Us |
| 74 |
3-8946 |
DISCONTINUED Price: Call Us |
| 75 |
221-459 |
Engine (Kohler Model K-321S Type No. 60231D) Price: Call Us |
| 77 |
5-2933 |
DISCONTINUED Price: Call Us |
| 78 |
5-4541 |
DISCONTINUED Price: Call Us |
