| Ref | Part Number | Description |
|---|
| A |
530026753 |
Decal - Bar Clamp Price: $3.33 |
| 1 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 1 |
530023663 |
Bumper - Bar Clamp Price: $3.33 |
| 2 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 2 |
530024059 |
Spacer Price: $3.33 |
| 3 |
5-4042 |
DISCONTINUED Price: Call Us |
| 3 |
530015574 |
Washer - Sprocket Shroud Price: $3.33 |
| 4 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 4 |
530048082 |
Drum & Pulley Ass'y. Price: $3.33 |
| 5 |
5-4045 |
PIVOT BRKT WA *R Price: $27.35 |
| 5 |
530032085 |
Inner Race - Clutch Drum Price: Call Us |
| 6 |
5-4033 |
DISCONTINUED Price: Call Us |
| 6 |
530032084 |
Bearing - Clutch Price: $3.99 |
| 7 |
5-4041 |
DISCONTINUED Price: Call Us |
| 7 |
530015575 |
Washer - Thrust Price: $3.33 |
| 8 |
253-122 |
SEAL-OIL Price: $6.83 |
| 8 |
530015617 |
Bolt - Blade Shaft Lock - 1/2 - 20 x 1 Price: $3.33 |
| 9 |
5-4035 |
DISCONTINUED Price: Call Us |
| 9 |
530062156 |
Collar - Outer Price: $3.33 |
| 10 |
254-79 |
BEARING-ROLLER, CUP Price: $6.39 |
| 10 |
530062155 |
Collar - Inner Price: $3.33 |
| 11 |
254-78 |
BEARING-CONE Price: $12.22 |
| 11 |
530062152 |
Blade Guard Price: $3.33 |
| 12 |
253-117 |
SEAL-OIL Price: $5.72 |
| 12 |
530015577 |
Washer - Clutch Shoe Price: $3.33 |
| 13 |
5-4038 |
WEAR SLEEVE Price: $16.36 |
| 13 |
530023675 |
Spring - Clutch Shoe Price: $0.28 |
| 14 |
32121-2 |
PIN-ROLL, SLOTTED Price: $0.25 |
| 14 |
530023469 |
Shoe - Clutch Price: $2.88 |
| 15 |
5-4040 |
DISCONTINUED Price: Call Us |
| 15 |
530022281 |
Drive Plate - Clutch Price: $3.33 |
| 16 |
5-4034 |
DISCONTINUED Price: Call Us |
| 16 |
530015616 |
Bolt - 5/16 - 18 x 2 - Blade Guard Price: $3.33 |
| 17 |
3296-15 |
NUT-LOCK, NI Price: $1.75 |
| 17 |
530062170 |
Adjusting Bracket Price: $3.33 |
| 18 |
5-4048 |
DISCONTINUED Price: Call Us |
| 18 |
530015117 |
Bolt - 1/4 - 20 x 5/8 Price: $3.33 |
| 19 |
323-7 |
SCREW-HH Price: $0.65 |
| 19 |
530015537 |
Nut - Bar Mounting (Incl. Washer) Price: $1.99 |
| 20 |
530011917 |
Bar - Clamp Price: $49.99 |
| 21 |
530001642 |
Lockwasher - 1/4 Price: $1.99 |
| 22 |
530015459 |
Screw - Arm Bar - 1/4 x 20 Price: $1.99 |
| 23 |
530062153 |
Arm Bar Price: $3.33 |
| 24 |
530062150 |
Pulley - Blade Shaft Price: $3.33 |
| 25 |
530015618 |
Bolt - Blade Guard - 5/16-18 x 1-1/2 Price: $3.33 |
| 26 |
530092322 |
Lockwasher - 5/16 Price: $1.99 |
| 28 |
530025241 |
Handlebar Brace Price: $3.33 |
| 29 |
530023682 |
Lead - Ground Wire Price: $3.33 |
| 30 |
530001677 |
Lockwasher - 1/4 Price: $0.04 |
| 31 |
530015459 |
Screw - 1/4 - 20 x 3/4 - Hex Hd. Price: $1.99 |
| 32 |
530022265 |
Handlebar Ass'y. (Wraparound) Price: $3.33 |
| 33 |
530012109 |
Adaptor - Handlebar Price: $3.33 |
| 34 |
530012124 |
Foot Support Price: $3.33 |
| 35 |
530015159 |
Washer - Conical Price: $3.33 |
| 36 |
530015471 |
Screw - Socket Head Price: $3.33 |
| 37 |
530015620 |
Washer - Blade Shaft Price: $3.33 |
| 38 |
952062142 |
V - Belt Price: $3.33 |
| 39 |
530015619 |
Locknut - 1/2 - 20 Price: $3.33 |
| 40 |
530015239 |
Screw This part replaces 530015141. Price: $1.99 |
| 41 |
530062169 |
Belt Guard Price: $3.33 |
| 42 |
530015127 |
Washer - Ramp Conical Price: $1.99 |
| 43 |
530062145 |
Knob Price: $3.33 |
| 44 |
952062007 |
Blade 14" Metal Cutting (Not furnished w/unit) Price: Call Us |
| 44 |
952062171 |
Blade 14" Masonry Cutting (Not furnished w/unit) Price: Call Us |
| 45 |
530062157 |
Key - Collar-Inner Price: $3.33 |
| 46 |
530062158 |
Key - Collar-Inner Pulley Price: $1.99 |
| 47 |
952069212 |
Water Kit Price: Call Us |
