| Ref | Part Number | Description |
|---|
| 1 |
115-8047-01 |
NO. 3 LIFT ARM ASM This part replaces 92-9291-01. Price: $1,059.77 |
| 1 |
137176X505 |
HANDLE BRKT Price: Call Us |
| 2 |
68-6480 |
BUSHING-FLANGE Price: $3.19 |
| 2 |
72140512 |
BOLT Price: Call Us |
| 3 |
325-17 |
SCREW-HH Price: $2.90 |
| 3 |
73680500 |
SUB= 73690500 Price: Call Us |
| 4 |
19111116 |
WASHER Price: Call Us |
| 4 |
323-7 |
SCREW-HH Price: $0.65 |
| 5 |
151473 |
HANDLE LH Price: Call Us |
| 6 |
52-6180 |
SPACER Price: $1.65 |
| 6 |
9266R |
SUB= 624A78 Price: Call Us |
| 7 |
60-3250 |
WASHER Price: $5.21 |
| 7 |
74760524 |
BOLT.HEX.5/16-1.5 Price: Call Us |
| 8 |
3069J |
SUB= 164937 Price: Call Us |
| 8 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 9 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 9 |
8206H |
GRIP T Price: Call Us |
| 10 |
92-9246-03 |
A-FRAME Price: $525.35 |
| 11 |
3067J |
SUB= 100382K Price: Call Us |
| 11 |
325-7 |
SCREW-HH Price: $1.53 |
| 12 |
115-8046-01 |
NO. 2 LIFT ARM ASM This part replaces 92-9290-01. Price: $933.22 |
| 12 |
3070J |
SPRING EXT TI Price: Call Us |
| 13 |
19121414 |
WASHER Price: Call Us |
| 14 |
60-1280 |
PIN Price: $3.53 |
| 14 |
74760516 |
SUB= 77394 Price: Call Us |
| 15 |
58-4380 |
PIN Price: $25.11 |
| 15 |
74760512 |
BOLT Price: Call Us |
| 16 |
10040500 |
LOCKWASHER Price: Call Us |
| 17 |
115-8017 |
REEL MOTOR KIT This part replaces 93-1412. Price: $1,999.51 |
| 17 |
73220500 |
NUT.HEX.5/16-18 Price: Call Us |
| 18 |
3246-17 |
SETSCREW-HSH Price: $0.47 |
| 18 |
98000129 |
NUT Price: Call Us |
| 19 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 19 |
72140506 |
BOLT Price: Call Us |
| 20 |
323-14 |
SCREW-HH Price: $1.34 |
| 20 |
9209R550 |
PANEL.HANDLE.TILL Price: Call Us |
| 21 |
324-6 |
SCREW-HH Price: $0.81 |
| 22 |
151474 |
HANDLE RH Price: Call Us |
| 26 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 31 |
115-8011 |
CYLINDER-HYD This part replaces 104-5225. Price: $784.12 |
| 32 |
93-7331 |
DECAL-WARNING Price: $10.35 |
| 34 |
325-34 |
SCREW-HH Price: $2.37 |
| 37 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 39 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
