| Ref | Part Number | Description |
|---|
| 1 |
98-9575 |
WATER PUMP ASM Price: $347.70 |
| 2 |
587820301 |
KIT.MANDREL.GREASEABLE.TALL This part replaces 539112057. Price: $49.99 |
| 2 |
98-9582 |
FLANGE-PUMP, WATER Price: $39.58 |
| 3 |
703-1623 |
BRACKET-TRANS.DUMP VALVE Not Available Price: |
| 3 |
98-9583 |
BEARING Price: $110.11 |
| 4 |
100-1932 |
PIPE-RETURN, WATER This part replaces 98-9577. Price: $8.45 |
| 4 |
532173436 |
PULLEY MANDREL This part replaces 539112171. Price: $14.99 |
| 4 |
703-1624 |
TRANSMISSION BRACKET Not Available Price: |
| 5 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 539107520. Price: $3.99 |
| 5 |
710-3195 |
Screw, Hex Cap, 5/16-18 X 4.5 Lg GR5 Price: $6.38 |
| 5 |
98-9576 |
MECHANICAL SEAL ASM Price: $27.04 |
| 6 |
532133957 |
WHEEL GAGE DONUT This part replaces 539107610. Price: $11.99 |
| 6 |
936-0119 |
Washer, Lock, 5/16 This part replaces 736-0119. Price: $4.29 |
| 6 |
98-9581 |
IMPELLER-PUMP, WATER Price: $38.74 |
| 7 |
532187257 |
DEFLECTOR.BLACK.54" This part replaces 539112054. Price: $64.99 |
| 7 |
712-3010 |
HEX NUT 5/16-18 This part replaces 7123010. Price: $3.89 |
| 7 |
98-9632 |
GASKET-PUMP, WATER Price: $7.25 |
| 8 |
596134801 |
Nuts This part replaces 539107590. Price: $1.00 |
| 8 |
703-1636 |
BRACKET, TORQUE Not Available Price: |
| 8 |
98-9353 |
BOLT Price: $0.76 |
| 9 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 539107630. Price: $3.99 |
| 9 |
710-0216 |
Bolt, 3/8 X 3/4 Type 5 This part replaces 710-3000. Price: $3.93 |
| 9 |
98-9357 |
BOLT Price: $2.46 |
| 10 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 10 |
726-3008 |
Clip, Cable Price: $4.26 |
| 10 |
98-9717 |
CLAMP Price: $8.41 |
| 11 |
531168601 |
SERVICE KIT BAFFLE.RIGHT.54" This part replaces 539112059. Price: $12.99 |
| 11 |
736-0169 |
Washer, Lock, 3/8 Price: $3.33 |
| 11 |
98-9574 |
PIPE-WATER Price: $17.67 |
| 12 |
531168801 |
SERVICE KIT BAFFLE BAFFLE CENT This part replaces 539112062. Price: $19.99 |
| 12 |
712-3017 |
HEX NUT 3/8-16 GR5 Price: $3.90 |
| 13 |
531168701 |
SERVICE KIT BAFFLE.LEFT.54" BA This part replaces 539112060. Price: $19.99 |
| 13 |
710-3193 |
U-BOLT 5/16-18X1.75 Not Available Price: |
| 14 |
532188187 |
COVER.MANDREL.RH.DECK.54" Price: $27.99 |
| 14 |
736-0242 |
Washer, Bell, .345 X .88 X .060 Thk Price: $3.75 |
| 15 |
532187297 |
COVER.MANDREL.LH.DECK.54" Price: $27.99 |
| 15 |
712-3009 |
Nut, Hex Center Lock, 5/16-18 GR5 Price: $5.99 |
| 16 |
596790301 |
Bushings This part replaces 539112076. Price: $5.99 |
| 16 |
703-1629 |
ASSEMBLY-DUMP VALVE Not Available Price: |
| 17 |
539107609 |
TORSION SPRING Price: $4.99 |
| 17 |
703-0310 |
DUMP LEVER Not Available Price: |
| 18 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 18 |
715-3008 |
SPRING PIN1/8X 3/4 HVY Not Available Price: |
| 19 |
594092501 |
Rods This part replaces 539107613. Price: $5.99 |
| 19 |
732-3054 |
COMPRESSION SPRING Not Available Price: |
| 20 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 20 |
714-0104 |
Pin, Internal Cotter Price: $3.90 |
| 21 |
589766102 |
Pulleys This part replaces 539132728. Price: $27.99 |
| 21 |
720-3017 |
Knob, Ball, 1/4-20 Trd Price: $12.87 |
| 22 |
539112198 |
IDLER ARM Price: $27.99 |
| 23 |
532110452 |
NUT PUSH M This part replaces 539107626. Price: $2.99 |
| 24 |
539103256 |
SPRING Price: $9.99 |
| 25 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 26 |
596671401 |
Bolts This part replaces 539100472. Price: $3.99 |
| 27 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 539990799. Price: $2.99 |
| 28 |
532137729 |
SCREW.1/4-20X5/8 This part replaces 539107631. Price: $3.99 |
| 29 |
539990588 |
HCS 3/8C X 2 Price: $3.99 |
| 30 |
596434404 |
Bolts This part replaces 539107608. Price: $4.99 |
| 31 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 32 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 33 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 34 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 35 |
595297001 |
Rods This part replaces 539110462. Price: $4.99 |
| 36 |
532105304 |
CAP-SLEEVE LT This part replaces 539107627. Price: $3.99 |
| 37 |
596564401 |
Bolts This part replaces 539990563. Price: $3.99 |
| 38 |
596582601 |
Nuts This part replaces 539990196. Price: $2.99 |
| 39 |
539131857 |
PITCH, ADJUST, RT Price: $29.99 |
| 40 |
539131858 |
PITCH, ADJUST, LT Price: $34.99 |
| 41 |
596565501 |
Nuts This part replaces 539131859. Price: $9.99 |
| 42 |
596437101 |
Screws This part replaces 539108396. Price: $2.99 |
| 43 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 44 |
539108461 |
BOLT 1/4-20 X 1/2 HWST Price: $2.99 |
| 45 |
577503601 |
BELT.DECK.EL=152.9 Price: $109.99 |
| 46 |
539112050 |
BEARING, BALL Price: $5.99 |
| 47 |
596583101 |
Screws This part replaces 539990582. Price: $3.99 |
| 48 |
539103427 |
PIVOT BUSHING Price: $7.99 |
| 49 |
596437501 |
Washers This part replaces 539102243. Price: $8.99 |
| 51 |
595316401 |
Washers This part replaces 539990550. Price: $2.99 |
| 52 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 53 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 54 |
597023501 |
MANDRELS This part replaces 539112056. Price: $24.99 |
