| Ref | Part Number | Description |
|---|
| 1 |
162-0313 |
GEARBOX, ME622 Price: $169.59 |
| 2 |
162-0008-03 |
BRACKET, E-GEARBOX [BLACK Price: Call Us |
| 3 |
134-8226-03 |
REAR FRAME, 56 (PRO) Price: $94.11 |
| 4 |
134-5253 |
SHAFT-ROLLER, PRO Price: $58.05 |
| 5 |
134-2924 |
CAM-DRIVE Price: $6.22 |
| 6 |
134-2034 |
KEY-DRIVE Price: $2.23 |
| 7 |
134-2635 |
BUSH, REAR ROLLER Price: $9.68 |
| 8 |
340129 |
BUSHING-ROLLER, OILITE Price: $8.28 |
| 9 |
480097 |
WASHER Price: $1.41 |
| 10 |
134-0314 |
SPACER-ROLLER Price: $2.71 |
| 11 |
134-3806 |
SPROCKET Price: $6.30 |
| 12 |
134-5261 |
CHAIN(46 PITCHES 3/8") Price: $20.99 |
| 13 |
134-4620 |
CHAIN COVER ASM Price: $18.59 |
| 14 |
134-0393 |
MOUNT-BEARING, FRAME (REAR) Price: $7.43 |
| 15 |
134-3805 |
SPROCKET, 10T Price: $9.95 |
| 16 |
111-8705 |
LEVER - HOC Price: $3.83 |
| 17 |
480134 |
KNOB HOC Price: $1.79 |
| 18 |
134-0358 |
HOC TOWER ASSEMBLY Price: $14.51 |
| 19 |
134-0361 |
PLATE-HOC Price: $5.64 |
| 20 |
134-0362 |
ADJUSTER-HOC Price: $17.09 |
| 21 |
111-4586 |
SCREW-HSH Price: $1.40 |
| 23 |
133-2639 |
WHEEL Price: $37.21 |
| 24 |
119-4042 |
NUT-HF, NI Price: $0.69 |
| 25 |
134-0365 |
CONNECTING ROD ASSEMBLY Price: $9.84 |
| 26 |
410069 |
BEARING FRONT AXLE Price: $1.40 |
| 27 |
134-2889 |
BEARING, BALL 12MM Price: $9.19 |
| 28 |
111-8670 |
AXLE- SUPPORT, REAR Price: $2.02 |
| 29 |
09263 |
WASHER 1/4 X 7/8 X .08" THK Price: $1.34 |
| 30 |
134-2254 |
SPRING LOAD LEVER Price: $1.59 |
| 31 |
134-2287 |
SPRING COUNTER BALANCE Price: $10.46 |
| 32 |
134-2299 |
SCREW-HWH Price: $0.48 |
| 33 |
480132 |
SPRING TORSION HOL Price: $0.95 |
| 34 |
04020 |
SPRING GRIP FIX EXT 5/16" Price: $1.34 |
| 35 |
09687 |
SCREW 06*20 PT PAN FLANGE Price: $1.39 |
| 36 |
09363 |
SETSCREW M6 X 20 Price: $1.31 |
| 37 |
09472 |
WASHER-PLAIN Price: $1.25 |
| 38 |
09544 |
NUT M6 NYL INS GD 8 Price: $1.34 |
| 39 |
09575 |
SCREW TAPTITE M6*20 WASHER Price: $1.39 |
| 40 |
134-8302 |
CAP-ROLLER, END Price: $6.67 |
| 41 |
134-0315-03 |
ROLLER SHELL ASSEMBLY Price: $31.83 |
| 43 |
134-2620 |
DECAL-HOC Price: $4.65 |
| 44 |
134-0254 |
CIRCLIP EXTERNAL HD Price: $0.50 |
| 45 |
111-8216 |
THRUST WASHER Price: $0.94 |
| 46 |
0201086 |
WASHER STARLOCK 5/16 Price: $1.39 |
| 47 |
09365 |
SCREW M6 X 16 TAPTITE HEX HD Price: $1.40 |
| 48 |
134-1734 |
BEARING SUPPORT PLATE Price: $2.81 |
| 49 |
09545 |
SCREW M6 X 12 C/SK POZI TAP Price: $1.39 |
| 50 |
134-6225-03 |
BACK PLATE, TENSIONER Price: $1.78 |
| 51 |
134-6226 |
PULLEY, TENSIONER Price: $5.55 |
| 52 |
ZCS1F035U |
SOC.HD.CAP SCW. M6*35 This part replaces 111-0118. Price: $1.03 |
| 53 |
09438 |
NUT M6 X 1.5 PLAIN Price: $1.39 |
| 54 |
111-7679 |
WASHER-PLAIN Price: $0.31 |
| 55 |
134-6999 |
SCREW-HH LOCK Price: $0.32 |
| 56 |
134-8145 |
COVER, BEARING Price: $1.02 |
| 57 |
111-9903 |
SCREW Price: Call Us |
| 58 |
134-0126 |
O-RING Price: Call Us |
| 59 |
09479 |
WASHER M10 X 21 X 1.45 THK (P) Price: $1.39 |
| 60 |
162-0090 |
BUSH, E-GEARBOX BRACKET Price: Call Us |
| 61 |
134-8306 |
SCREW-PLASTIC,PHT Price: Call Us |
| 62 |
134-4513 |
RETAINING COLLAR, DRIVE SHAFT Price: $0.76 |
