| Ref | Part Number | Description |
|---|
| 1 |
137-6113 |
LONG REAR ROLLER ASM (3IN DIA)(22IN) This part replaces 114-5415. Price: $383.80 |
| 1 |
530038581 |
Throttle Hsg. (Right) Price: $2.99 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
530016349 |
Screw-Throttle Hsg. Price: $1.99 |
| 3 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 3 |
530038682 |
Trigger Price: $1.99 |
| 4 |
530071548 |
Assy-Throttle Cable Price: $3.99 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 5 |
530095391 |
Flex-Drive Shaft Price: $11.99 |
| 6 |
3230-26 |
SCREW-CARR Price: $3.99 |
| 6 |
530016284 |
Locknut-Gear Box Price: $1.99 |
| 7 |
114-5400 |
PLASTIC WIEHLE ROLLER ASM Price: $477.85 |
| 7 |
530016225 |
Wingnut-Gear Box Price: $1.99 |
| 8 |
530092062 |
Washer Price: $1.99 |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 9 |
530052286 |
Line Limiter Price: $1.54 |
| 10 |
322-16 |
SCREW-HH Price: $3.39 |
| 10 |
530015880 |
Screw-Line Limiter Price: $1.99 |
| 11 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 12 |
140-5690 |
BRACKET-RM FRONT HOC This part replaces 125-2796. Price: $20.85 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
952711548 |
Accy-Spool w/Line Price: $6.95 |
| 14 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 14 |
530401957 |
Clip-Retainer Price: $1.99 |
| 15 |
107-4026 |
SCREW-HH Price: $5.28 |
| 15 |
530053241 |
Spring Price: $1.99 |
| 16 |
530071306 |
Kit-Hub Ass'y Price: $8.99 |
| 16 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 17 |
530016202 |
Screw Price: $1.99 |
| 18 |
530095638 |
Assy-Gear Box Price: $34.99 |
| 19 |
530016224 |
Screw Price: $1.99 |
| 20 |
530016312 |
Screw Price: $1.99 |
| 21 |
530071303 |
Assy-Drive Shaft Hsg. Price: $14.92 |
| 23 |
530091373 |
Nut This part replaces 530016118. Price: $1.99 |
| 24 |
530094742 |
Clamp Handle Price: $2.99 |
| 25 |
530015820 |
Bolt Handle Price: $1.99 |
| 26 |
530038708 |
Assist Handle Price: $1.32 |
| 27 |
530038580 |
Throttle Hsg. (Left) Price: $2.99 |
