| Ref | Part Number | Description |
|---|
| 1 |
120-3549-03 |
FRAME Price: $1,588.15 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144925. Price: $149.99 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 2 |
95-8568-03 |
FRAME-LOWER Price: $957.21 |
| 3 |
32144-15 |
SCREW-HHFTF Price: $7.99 |
| 3 |
596582301 |
Washers This part replaces 819091016. Price: $2.99 |
| 4 |
3234-38 |
SCREW-HHF Price: $3.33 |
| 4 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 5 |
32128-49 |
NUT-HHF Price: $1.04 |
| 6 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $2.99 |
| 6 |
99-3375-03 |
STEP Price: $81.69 |
| 7 |
2412-72 |
CLIP-CLOSED, INSULATED Price: $1.90 |
| 8 |
532404349 |
KIT.BOX.BATTERY.REAR.BOOT.POS This part replaces 532156417. Price: $24.99 |
| 8 |
95-8615 |
TUBE-BREATHER Price: $48.92 |
| 9 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 10 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 11 |
104-0468-01 |
COVER-FRAME Price: $26.94 |
| 12 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 13 |
107-7833 |
ROPS ASM Price: $590.55 |
| 14 |
3234-40 |
SCREW-HF Price: $3.38 |
| 15 |
32148-8 |
NUT-CLINCH Price: $2.31 |
| 16 |
115-3417-0P |
BRACKET-BULKHEAD,SCISSOR This part replaces 115-3417-03. Price: $35.82 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN This part replaces 532153664. Price: $19.99 |
| 17 |
104-7050 |
TUBE-MANUAL Price: $8.76 |
| 18 |
2412-133 |
CLAMP-R Price: $3.19 |
| 19 |
32144-70 |
SCREW-HWHTF Price: $1.99 |
| 19 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810090400. Price: $2.99 |
| 20 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 20 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873350400. Price: $2.99 |
| 21 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 21 |
532136850 |
HARNESS LIGHT SOCKET Price: $15.99 |
| 22 |
32148-6 |
NUT-CLINCH Price: $1.24 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
104-4634-03 |
TOOLBOX Price: $153.88 |
| 24 |
104-4633-03 |
COVER-TOOLBOX Price: $85.18 |
| 24 |
532004799 |
BATTERY CABLE This part replaces 532124780. Price: $8.99 |
| 25 |
121-3623 |
DECAL-DANGER This part replaces 104-0484. Price: $10.99 |
| 25 |
532146147 |
CABLE BATTERY Price: $22.99 |
| 26 |
104-5181 |
DECAL-DANGER, CE Price: $22.28 |
| 26 |
532108824 |
FUSE HYT Price: $4.99 |
| 28 |
532004207 |
CABLE T This part replaces 532124773. Price: $4.99 |
| 29 |
532160784 |
PLUNGER SWITCH (COLOR:OLIVE) Price: $17.99 |
| 30 |
532140301 |
SWITCH.IGNITION.4.POSITION Price: $32.99 |
| 31 |
532124211 |
NUT IGNITION Price: $4.99 |
| 32 |
532141226 |
COVER SWITCH KEY Price: $4.99 |
| 33 |
532122147 |
KEY.MOLDED.GENERIC Price: $5.99 |
| 40 |
532160719 |
WIRING HARNESS Price: $117.67 |
| 41 |
596437001 |
Screws This part replaces 871110408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
532146154 |
KIT SOLENOID .95 This part replaces 532145673. Price: $19.99 |
| 44 |
873640400 |
Nut, Keps Blk Hex 1/4-20 UNC Price: $2.99 |
| 46 |
532169642 |
KIT.HOURMETER.SNAP-IN This part replaces 532110940. Price: $109.99 |
| 47 |
817011008 |
Screw 10-24 x 1/2 Black Price: $2.38 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532154959. Price: $24.99 |
| 51 |
532140405 |
FRAME RETAINING RING Price: $3.99 |
| 70 |
532140422 |
HARNESS ENGINE Price: $8.99 |
| 80 |
532146685 |
HARNESS, CLUTCH Price: $11.99 |
| 81 |
532109748 |
RELAY.ASSY.T Price: $19.99 |
