| Ref | Part Number | Description |
|---|
| 1 |
92-6564 |
DECAL-4 MATIC Price: $41.48 |
| 2 |
84-1450 |
PANEL-GAUGES, CONSOLE Price: $78.90 |
| 3 |
218-446 |
NUT-HEX Price: $6.09 |
| 4 |
218-447 |
WASHER-LOCK Price: $3.79 |
| 5 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 6 |
3254-20 |
WASHER-LOCK, INT Price: $1.29 |
| 7 |
3218-19 |
NUT-HJ Price: $0.54 |
| 8 |
93-7483 |
LAMP-CLUSTER Price: $97.05 |
| 9 |
76-9060 |
GAUGE-TEMPERATURE Price: $110.89 |
| 10 |
66-2940 |
GAUGE-FUEL Price: $178.34 |
| 11 |
93-7484 |
CLUSTER-LAMP Price: $121.39 |
| 12 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 14 |
3254-1 |
WASHER-LOCK, INT Price: $0.49 |
| 15 |
3217-26 |
NUT-HEX Price: $0.25 |
| 17 |
138-1911 |
PTO SWITCH KIT This part replaces 85-4980. Price: $320.00 |
| 18 |
32128-33 |
NUT-HF Price: $0.25 |
| 19 |
3274-31 |
SCREW-HSBH This part replaces 3274-68. Price: $0.89 |
| 20 |
27-2360 |
SWITCH Price: $46.56 |
| 21 |
82-3750-03 |
COVER-CONSOLE Price: $183.31 |
| 22 |
3250-36 |
SCREW-PPH Price: $2.41 |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 24 |
32151-72 |
RING-RETAINING Price: $1.59 |
| 501456501 |
501456501 |
SEALING RING Price: $7.99 |
| 501477902 |
501477902 |
GROMMET Price: $4.99 |
| 501478101 |
501478101 |
SLEEVE Price: $2.67 |
| 501545901 |
501545901 |
Price: $24.83 |
| 501663901 |
501663901 |
Price: $13.40 |
| 501663903 |
501663903 |
Price: $22.87 |
| 501797102 |
501797102 |
GASKET Price: $4.99 |
| 501797802 |
501797802 |
CHOKE CONTROL Price: $6.99 |
| 501862001 |
501862002 |
SPACER This part replaces 501862001. Price: $22.99 |
| 501862502 |
501862502 |
GASKET Price: $4.99 |
| 503208006 |
503208006 |
STUD 5X22 Price: $3.99 |
| 503532701 |
503281611 |
CARB. HDA-144-1 WALBRO This part replaces 503532701. Price: $99.99 |
| 732211401 |
732211401 |
LOCKNUT M5 Price: $2.99 |
| 735114650 |
735114650 |
SPRING WASHER 5.3X10 Price: $3.99 |
