| Ref | Part Number | Description |
|---|
| 1 |
5-1382 |
FRONT ROLLER ASM Price: $311.40 |
| 2 |
32151-13 |
RING-RETAINING Price: $4.39 |
| 2 |
484610 |
Hose, Oil Drain, Kohler - ECV860 Price: Call Us |
| 3 |
251-205 |
BEARING-BALL Price: $40.83 |
| 3 |
486470 |
Muffler, 21 HP BV Price: Call Us |
| 4 |
237-68 |
O-RING Price: $3.22 |
| 4 |
462999 |
Wheel Hub Assy., SVRII Price: Call Us |
| 5 |
48572-02 |
TUBE UNION, 3/4-16 JIC TO 7/8-14 "O" RING Price: Call Us |
| 5 |
5-1384 |
HOUSING-BEARING Price: $84.20 |
| 6 |
285-17 |
PLUG-PIPE This part replaces 285-10. Price: $2.59 |
| 6 |
482639 |
Wheel Motor, Parker Price: Call Us |
| 7 |
253-118 |
SEAL-OIL Price: $18.29 |
| 7 |
428334 |
Spacer, Wheel Motor Price: Call Us |
| 8 |
11-3050 |
SLEEVE Price: $53.95 |
| 8 |
486483 |
Hose Assy, 17.50" Price: Call Us |
| 9 |
3245-35 |
SCREW-SET, HSH Price: $0.41 |
| 9 |
486484 |
Hose Assy, 16.25 Price: Call Us |
| 10 |
237-69 |
O-RING Price: $5.72 |
| 10 |
486654 |
Tube Assy, 1/2" LH Upper Price: Call Us |
| 11 |
486655 |
Tube Assy, 1/2" RH Upper Price: Call Us |
| 11 |
94-2958 |
STUD/BALL This part replaces 2411-7. Price: $6.70 |
| 12 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 12 |
486656 |
Tube Assy, 1/2" LH Lower Price: Call Us |
| 13 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 13 |
486657 |
Tube Assy, 1/2" RH Lower Price: Call Us |
| 14 |
48350-02 |
Elbow, 90 Degree 3/4-16 JIC x 3/4-16 O-Ring Price: Call Us |
| 15 |
486444 |
Pump, LH Price: Call Us |
| 16 |
486445 |
Pump, RH Price: Call Us |
| 17 |
482266-01 |
Elbow, 90 Degree - 9/16" O-Ring x 3/8" Hose Price: Call Us |
| 18 |
48811 |
Hose, 3/8" ID - 10-1/4" Long (Order By The Inch) Price: Call Us |
| 19 |
48136-13 |
Clamp, .69" Max. / .25" Min. Dia. Price: Call Us |
| 20 |
48351 |
Hose Assembly, 1/2" ID (Oil Reservoir to Filter Base) Price: Call Us |
| 21 |
48136-05 |
Clamp, Cable 3/4" I.D. Price: Call Us |
| 22 |
482574 |
Fitting, 90 Degree - 1/2" Hose Price: Call Us |
| 23 |
482573 |
Bushing, 0.78" Dia. Viton Price: Call Us |
| 24 |
463046 |
Hyd. Tank Assy Price: Call Us |
| 25 |
481507 |
Insert, Filler Neck Price: Call Us |
| 26 |
481164 |
CAP, HYDRAULIC TANK Price: Call Us |
| 27 |
428473 |
Mounting Bracket, Oil Reservoir Price: Call Us |
| 28 |
482417 |
Filter Head Assembly Price: Call Us |
| 29 |
482477 |
Tee, 3/8" O-Ring x JIC x 1/2" Hose Price: Call Us |
| 30 |
48462-01 |
OIL FILTER, SPECIAL Price: Call Us |
| 31 |
423279 |
Plate Weldment, Motor Backing Price: Call Us |
| 32 |
04001-194 |
Bolt, Hex Head 1/2-13 x 4-1/4" Price: Call Us |
| 33 |
48224 |
BEARINGS, BALL, NEUTRAL RETURN Price: Call Us |
| 34 |
43683 |
Pivot, Idler Price: Call Us |
| 35 |
463355 |
Idler Arm Assembly Price: Call Us |
| 36 |
04043-04 |
Flatwasher, 3/8 (.391 x .938 x .105 HD) Grade 8 Price: Call Us |
| 37 |
04201-57 |
Bolt, Hex Head 3/8- 16 x 3.50 - Stainless Steel Price: Call Us |
| 38 |
04317-03 |
Nut, Flange Elastic Stop 3/8 - 16 - Stainless Steel Price: Call Us |
| 39 |
486045 |
Pulley, 3-1/2" Dia. Price: Call Us |
| 40 |
04063-14 |
KEY, 5 MM X 5 MM X 25 MM Price: Call Us |
| 41 |
482649 |
Pulley, 5.45 OD - Tapered Bore" Price: Call Us |
| 42 |
486399 |
Wheel Assembly, 20 x 12 - 10 Price: Call Us |
| 43 |
482085 |
Hub, Tapered, 15mm Bore Price: Call Us |
| 44 |
04001-172 |
Bolt, Hex Head 1/4-20 x 1" Grade 8 Black Price: Call Us |
| 45 |
04201-30 |
Bolt, Hex Head 3/8 - 16 x 1.50 - Stainless Steel Price: Call Us |
| 46 |
427828 |
Plate, Speed Sensor Price: Call Us |
| 47 |
04021-19 |
Locknut, Hex 1/2-13 Center Lock Price: Call Us |
| 48 |
04063-08 |
Key, 1/4 x 1/4 x 2.0" Price: Call Us |
| 49 |
486567 |
Pulley 5.45 OD x 1.125 Bore Price: Call Us |
| 50 |
04201-33 |
Bolt, Hex Head 3/8-16 x 2-1/4" - Stainless Steel Price: Call Us |
| 51 |
486111 |
Belt, Pump Drive Price: Call Us |
| 52 |
482572 |
Elbow, 90 Degree, 9/16-18 JIC x 9/16 O-Ring Price: Call Us |
| 53 |
428105 |
Plate, Hub Magnet Holder Price: Call Us |
| 54 |
482571 |
Bushing, 0.56" Dia. Viton Price: Call Us |
| 55 |
04201-16 |
Bolt, Hex 5/16 - 18 x .75 - Stainless Steel Price: Call Us |
| 56 |
04230-03 |
Washer, Lock 5/16 Spring - Stainless Steel Price: Call Us |
| 57 |
04061-06 |
Pin, Cotter 9/16" x 1-1/2" Price: Call Us |
| 58 |
48680 |
Nut, Hex Castle 1.0-20 UNEF Price: Call Us |
| 59 |
04028-02 |
Wheel Nut, 1/2-20 x 13/16 Price: Call Us |
| 60 |
04230-05 |
Bolt, Hex Head 7/16-20 x 1.25" Price: Call Us |
| 61 |
04317-03 |
Nut, Flange Elastic Stop 3/8 - 16 - Stainless Steel Price: Call Us |
| 62 |
04041-28 |
Flatwasher, 7/16-.469 x 1.75 x .25 (48, 52) Price: Call Us |
| 63 |
04220-04 |
Nut, 3/8 - 16 - Stainless Steel Price: Call Us |
