HANDLE HEATED
Parts (29)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 120-0301 | REAR WINDOW GLASS KIT Price: $2,330.78 |
| 1 | 522741901 | HANDLE INSERT Price: $37.99 |
| 2 | 115-7685 | BOLT-STEP Price: $5.36 |
| 2 | 578864601 | THERMOSTAT ASSY Price: $64.99 |
| 3 | 115-5572 | NUT-FLANGE Price: $1.36 |
| 3 | 537210801 | HOLDER Price: $2.99 |
| 4 | 115-5570 | BUSHING-THIN Price: $5.22 |
| 4 | 587056601 | STATOR This part replaces 522611401. Price: $159.99 |
| 5 | 115-7687 | MOUNT-GLASS, BUSHING (HINGE) Price: $20.22 |
| 6 | 115-7688 | LH HINGE ASM Price: $86.41 |
| 6 | 588168602 | FOIL ELEMENT Price: $54.99 |
| 7 | 115-7689 | RH HINGE ASM Price: $152.05 |
| 7 | 575388904 | FRONT HANDLE Price: $109.99 |
| 8 | 115-5597 | HANDLE-LATCH Price: $95.14 |
| 8 | 525798103 | SCREW Price: $2.99 |
| 9 | 115-5599 | PIN-SPLIT Price: $27.75 |
| 9 | 505157403 | COVER Price: $5.99 |
| 10 | 537252501 | HANDLE Price: $5.99 |
| 11 | 510097801 | CONTACT PLATE Price: $4.99 |
| 12 | 525887402 | SCREW CITXPANT Price: $2.99 |
| 13 | 504872402 | FLYWHEEL ASSY This part replaces 504872404. Price: $119.99 |
| 14 | 503220401 | NUT W/ WASHER Price: $3.99 |
| 15 | 503230042 | WASHER Price: $3.99 |
| 16 | 501673501 | SPRING Price: $3.99 |
| 17 | 501673201 | PAWL Price: $6.99 |
| 18 | 501819901 | SCREW M5X14 This part replaces 506006901. Price: $2.99 |
| 19 | 505129705 | ANTIVIBRATION ELEMENT CYLINDER Price: $24.99 |
| 20 | 525798101 | SCREW ITXSCFT PL6X16 T27 10.9 Price: $2.99 |
| 21 | 537088301 | GROMMET Price: $4.99 |
