| Ref | Part Number | Description |
|---|
| 1 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 1 |
579841401 |
KITS.CHASSIS.STAMPED.SERVICE This part replaces 532174619. Price: $379.99 |
| 2 |
3296-357 |
Nut-HFH Price: Call Us |
| 2 |
532176554 |
DRAWBAR, 12GA Price: $37.99 |
| 3 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 4 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 5 |
28-9060 |
PLATE-IDLER Price: $137.75 |
| 6 |
5-1077 |
KEY-SQUARE Price: $6.18 |
| 7 |
99-1297 |
IDLER ARM ASM This part replaces 27-8580. Price: $133.94 |
| 8 |
67-5360 |
DECAL-DANGER Price: $14.99 |
| 9 |
3296-5 |
NUT-HEX Price: $3.09 |
| 9 |
532193641 |
DASH This part replaces 532190251. Price: $47.99 |
| 10 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 10 |
65-5940 |
PULLEY-IDLER Price: $35.61 |
| 11 |
532174996 |
PANEL.DASH.LH.LTX Price: $9.99 |
| 11 |
7-0081 |
WASHER-FLAT Price: $0.89 |
| 12 |
65-5950 |
BUSHING-PULLEY Price: $4.44 |
| 13 |
3211-8 |
SCREW-HH Price: $3.50 |
| 13 |
532181719 |
PANEL DASH RH Price: $8.99 |
| 14 |
27-1160 |
V-BELT Price: $51.80 |
| 14 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 15 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 16 |
32146-20 |
NUT-HEX Price: $3.23 |
| 17 |
532188374 |
HOOD.ELITE.HUSQ-STEEL This part replaces 532189977. Price: $89.99 |
| 17 |
7-4150 |
WASHER Price: $1.19 |
| 18 |
27-0970-03 |
PULLEY ASM This part replaces 27-0970. Price: $51.99 |
| 19 |
253-139 |
SEAL-OIL Price: $12.45 |
| 20 |
46-8530 |
BEARING ASM Price: $93.99 |
| 20 |
532180679 |
PLATE MTG.BATTERY/FUEL TANK Price: $9.99 |
| 21 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 22 |
27-7680-03 |
RING-DECK SUPPORT This part replaces 27-7680. Price: $70.99 |
| 23 |
532124028 |
BUSHING.SNAP.NYL.BLK. Price: $4.99 |
| 23 |
68-8340 |
DECAL-TORQUE Price: $19.99 |
| 24 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 25 |
61-4160 |
HOUSING-SPINDLE Price: $131.00 |
| 26 |
32128-21 |
NUT-HF Price: $0.39 |
| 26 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 27 |
27-0920 |
SHAFT Price: $158.07 |
| 28 |
27-0990-03 |
BLADE-18 INCH This part replaces 27-0990. Price: $18.94 |
| 29 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 30 |
3253-27 |
WASHER-LOCK Price: $2.24 |
| 30 |
532192814 |
FENDER.W/CUPHOLDER.ORANGE This part replaces 532185432. Price: $219.99 |
| 31 |
44-2200 |
SCREW-BLADE Price: $4.04 |
| 31 |
532139976 |
BRACKET.SUPPORT.FENDER Price: $14.99 |
| 32 |
27-0950 |
SPACER Price: $29.99 |
| 33 |
66-1340 |
DECAL-DANGER, THROWN OBJECT Price: $9.07 |
| 34 |
92-8791 |
DISCONTINUED This part replaces 72-9260. Price: Call Us |
| 35 |
40-6400 |
SHAFT-ROLLER Price: $38.99 |
| 36 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 37 |
29-4820 |
ROLLER Price: $14.88 |
| 37 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 38 |
532175710 |
BRACKET.ASM.PIVOT.MOWER.REAR Price: $9.99 |
| 38 |
57-0690 |
PIN-SPECIAL Price: $3.66 |
| 39 |
532407807 |
BRACKET PIVOT This part replaces 532174714. Price: $27.99 |
| 53 |
532188372 |
BRACKET DASH RH Price: $9.99 |
| 55 |
532188373 |
BRACKET DASH LH Price: $7.99 |
| 58 |
532189352 |
AIR DUCT ENGINE Price: $20.99 |
| 60 |
872140606 |
Bolt Rdhd Sqnk 3/8-16 unc x 3/4 Price: $4.99 |
| 64 |
532174997 |
DASH LOWER Price: $24.99 |
| 74 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 90 |
532124346 |
NUT.PUSH.3/16 Price: $6.99 |
| 142 |
532175702 |
PLATE REINFORCEMENT Price: $7.99 |
| 143 |
532186689 |
BRACKET, SWAYBAR CHASSIS Price: $5.99 |
| 144 |
532175582 |
BRKT, FOOT REST Price: $4.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 158 |
532162037 |
BRACKET PARKING BRAKE Price: $3.39 |
| 159 |
532191120 |
CUPHOLDER.RIGHT.GREY This part replaces 532185434. Price: $8.99 |
| 166 |
532189747 |
SCREW.HI-LO#13-16X5/8 This part replaces 532171875. Price: $14.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
| 209 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 212 |
532188267 |
INSERT LENS Price: $8.99 |
| 213 |
532188266 |
SKIRT.SIDE.ELITE.LH This part replaces 532189979. Price: $7.99 |
| 214 |
532188265 |
SKIRT.SIDE.ELITE.RH.GREY This part replaces 532189978. Price: $7.99 |
| 217 |
532179132 |
CONSOLE FUEL WINDOW GRAY This part replaces 532185436. Price: $7.99 |
| 219 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 258 |
532188263 |
LENS ELITE CLEAR RH This part replaces 532189981. Price: $14.99 |
| 259 |
532188264 |
LENS.ELITE.HUSQ.CLEAR.LH This part replaces 532189982. Price: $14.99 |
| 276 |
532189274 |
BUMPER HOOD RH Price: $7.99 |
| 277 |
532189275 |
BUMPER HOOD LH Price: $5.99 |
| 278 |
596321701 |
Screws This part replaces 532189585. Price: $2.99 |
