| Ref | Part Number | Description |
|---|
| 1 |
251-347 |
BEARING-BALL Price: $9.69 |
| 1 |
532406623 |
SEAT.TP150.BLK.PPRO.KB/SL Price: $169.99 |
| 2 |
119-4092 |
ROLLER TUBE ASM Price: $172.76 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $5.99 |
| 3 |
532140675 |
STRAP Price: $3.99 |
| 4 |
108-3151 |
NUT-LOCK, BEARING Price: $21.90 |
| 5 |
147-1347 |
SHAFT-ROLLER (21IN) This part replaces 119-4090. Price: $70.81 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
106-6941 |
SEAL Price: $5.74 |
| 6 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK Price: $2.99 |
| 8 |
532171877 |
BOLT, 5/16-18 X 1 3/4 Price: $3.99 |
| 10 |
532441805 |
PAN.ASM.SEAT.SHORT.SLD.ADJ.TEX Price: $29.99 |
| 12 |
532199370 |
BRKT.MNT.OPC.SW.SEAT. Price: $2.99 |
| 13 |
532121248 |
BUSHING Price: $3.99 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $3.99 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 17 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 532123976. Price: $2.99 |
| 19 |
532199372 |
KNOB.SEAT.ADJ. Price: $4.99 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER Price: $1.99 |
| 37 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.99 |
