| Ref | Part Number | Description |
|---|
| 1 |
72-9390 |
BELT-SEAT Price: $140.77 |
| 2 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 4 |
3212-4 |
SCREW-HH Price: $2.73 |
| 5 |
325-14 |
SCREW-HH Price: $2.64 |
| 6 |
92-5518-03 |
DISCONTINUED This part replaces 92-5518. Price: Call Us |
| 7 |
325-5 |
SCREW-HH Price: $1.20 |
| 8 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 9 |
92-5515 |
MOUNT-STRAP, TETHER Price: $28.92 |
| 10 |
324-4 |
SCREW-HH Price: $0.95 |
| 11 |
32128-23 |
NUT-HF Price: $1.51 |
| 11 |
532414336 |
KIT.SVC.CLUTCH.ELECTRIC. This part replaces 532400008. Price: $329.99 |
| 12 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 13 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 14 |
322-14 |
SCREW-HH Price: $1.01 |
| 15 |
599306004 |
FUEL TANK, 3GAL, 2.25"NECK, 20 This part replaces 532438080. Price: $199.99 |
| 15 |
92-5517-03 |
LEFT MOUNT ASM This part replaces 92-5517. Price: $156.29 |
| 16 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 17 |
325-9 |
SCREW-HH Price: $1.87 |
| 18 |
3217-9 |
NUT-HH Price: $0.37 |
| 18 |
532439208 |
CAP.ASM.FL.RITCH.3"E10.SYM.498 Price: $37.99 |
| 19 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 20 |
532423502 |
CONTROL.TH/CK.COBRA.B&S.TWN.BK Price: $24.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
532131780 |
Kit Spark Arrestor 1 25 Price: Call Us |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN This part replaces 532159955. Price: $27.99 |
| 71 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK This part replaces 532160589. Price: $22.99 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
