| Ref | Part Number | Description |
|---|
| 2 |
462946 |
Hydro Tank Assy., SVRII Price: Call Us |
| 3 |
481507 |
Insert, Filler Neck Price: Call Us |
| 4 |
481164 |
CAP, HYDRAULIC TANK Price: Call Us |
| 5 |
482571 |
Bushing, 0.56" Dia. Viton Price: Call Us |
| 6 |
482572 |
Elbow, 90 Degree, 9/16-18 JIC x 9/16 O-Ring Price: Call Us |
| 7 |
482573 |
Bushing, 0.78" Dia. Viton Price: Call Us |
| 8 |
482574 |
Fitting, 90 Degree - 1/2" Hose Price: Call Us |
| 9 |
427280 |
Bracket, Hydro Tank Mounting Price: Call Us |
| 10 |
04001-08 |
BOLT, SERRATED FLANGE HEX HEAD 5/16-18 X 3/4" Price: Call Us |
| 11 |
04030-03 |
Lockwasher, 5/16 (.317 x .586 x .078) Helical Spring Price: Call Us |
| 12 |
48136-13 |
Clamp, .69" Max. / .25" Min. Dia. Price: Call Us |
| 13 |
48811 |
Hose, 3/8" ID - 10-1/4" Long (Order By The Inch) Price: Call Us |
| 14 |
48136-05 |
Clamp, Cable 3/4" I.D. Price: Call Us |
| 15 |
48351 |
Hose Assembly, 1/2" ID (Oil Reservoir to Filter Base) Price: Call Us |
| 16 |
482266-01 |
Elbow, 90 Degree - 9/16" O-Ring x 3/8" Hose Price: Call Us |
| 17 |
486812 |
Pump, LH - SVRII Price: Call Us |
| 18 |
486813 |
Pump, RH - SVRII Price: Call Us |
| 19 |
485830 |
Union, O-Ring to JIC Price: Call Us |
| 20 |
481203-02 |
Elbow, 1/2 JIC Female to 1/2 JIC Male Price: Call Us |
| 21 |
485847 |
Tee, 3/4" O-Ring Price: Call Us |
| 22 |
485870 |
Drain, Hose Assembly Price: Call Us |
| 23 |
48771-02 |
Plug, JIC 3/4-16 UNF Price: Call Us |
| 24 |
482417 |
Filter Head Assembly Price: Call Us |
| 25 |
04001-20 |
Bolt, Hex Head 3/8-16 x 1-1/2" B&S 32BV Price: Call Us |
| 26 |
48462-01 |
OIL FILTER, SPECIAL Price: Call Us |
| 27 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 28 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 29 |
04001-52 |
Bolt, Hex Hd. 1/2-13 x 2-1/2" (lower) Price: Call Us |
| 30 |
423279 |
Plate Weldment, Motor Backing Price: Call Us |
| 31 |
485602 |
Hose Assembly Price: Call Us |
| 32 |
486832 |
Hose Assy., 18-1/2" Price: Call Us |
| 33 |
48572-02 |
TUBE UNION, 3/4-16 JIC TO 7/8-14 "O" RING Price: Call Us |
| 34 |
482639 |
Wheel Motor, Parker Price: Call Us |
| 35 |
04021-19 |
Locknut, Hex 1/2-13 Center Lock Price: Call Us |
| 36 |
462999 |
Wheel Hub Assy., SVRII Price: Call Us |
| 37 |
485952 |
Wheel Assembly, 24 x 12-12 (SPZ61) Price: Call Us |
| 38 |
04061-06 |
Pin, Cotter 9/16" x 1-1/2" Price: Call Us |
| 39 |
04028-02 |
Wheel Nut, 1/2-20 x 13/16 Price: Call Us |
| 40 |
04102-03 |
Bolt, Hex Head 7/16-20 x 2-1/4" w/Patch (Kawasaki) Price: Call Us |
| 41 |
04030-05 |
Lockwasher, 7/16” Spring Price: Call Us |
| 42 |
04041-28 |
Flatwasher, 7/16-.469 x 1.75 x .25 (48, 52) Price: Call Us |
| 43 |
462339 |
Clutch w/Tag GT3.5--FE05 (61) Price: Call Us |
| 44 |
04063-28 |
Key, 1/4 x 1/4 x 3-1/2" Price: Call Us |
| 45 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 46 |
452923 |
ANTI-ROTATION WLMT, SVRII Price: Call Us |
| 47 |
04001-136 |
Bolt, Hex Head 3/8-16 x 1-1/2" Grade 8 Black Price: Call Us |
| 48 |
04001-54 |
Bolt, Hex Head 3/8-16 x 3" - 52" Price: Call Us |
| 49 |
483112 |
Spring, Transmission Drive Price: Call Us |
| 50 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 51 |
04001-172 |
Bolt, Hex Head 1/4-20 x 1" Grade 8 Black Price: Call Us |
| 52 |
482085 |
Hub, Tapered, 15mm Bore Price: Call Us |
| 53 |
04063-14 |
KEY, 5 MM X 5 MM X 25 MM Price: Call Us |
| 54 |
486322 |
Belt, Pump Drive (37BV-EFI) Price: Call Us |
| 55 |
48224 |
BEARINGS, BALL, NEUTRAL RETURN Price: Call Us |
| 56 |
463158 |
Idler Arm Assy. Price: Call Us |
| 57 |
43683 |
Pivot, Idler Price: Call Us |
| 58 |
04001-62 |
Capscrew, Hex Head 3/8-16 x 3.25" Price: Call Us |
| 59 |
04043-04 |
Flatwasher, 3/8 (.391 x .938 x .105 HD) Grade 8 Price: Call Us |
| 60 |
483802 |
Pulley, 4-3/4" OD - 1.125 Bore Price: Call Us |
| 61 |
483213 |
Pulley, Idler 4-1/2" Price: Call Us |
| 62 |
482649 |
Pulley, 5.45 OD - Tapered Bore" Price: Call Us |
| 63 |
04001-46 |
Bolt, Hex Head 3/8-16 x 2-1/4" - 61" Price: Call Us |
| 64 |
04001-20 |
Bolt, Hex Head 3/8-16 x 1-1/2" B&S 32BV Price: Call Us |
| 65 |
04134-03 |
Nut, Flanged Top Lock 3/8-16 Price: Call Us |
| 66 |
484509 |
Hose Assy., 15-1/4" Price: Call Us |
| 67 |
04119-02 |
Bolt, Hex Head M8 - 1.25 x 20 Price: Call Us |
| 68 |
04121-01 |
Nut, M6-1.0 Hex Flange Price: Call Us |
| 69 |
486868 |
Muffler, Vanguard 37 EFI - SVRII Price: Call Us |
| 70 |
428403 |
Heatshield, Muffler- SVRII Price: Call Us |
| 71 |
04001-18 |
Bolt, Hex Head, 3/8-16 x 3/4" Price: Call Us |
| 72 |
485564 |
Fan Cover, Pump Price: Call Us |
| 73 |
483017 |
Oil Drain, 35BV & 37BV-EFI - Briggs & Stratton Price: Call Us |
| 74 |
48680 |
Nut, Hex Castle 1.0-20 UNEF Price: Call Us |
| 75 |
04001-09 |
Bolt, Heax Head 5/16-18 x 1" (48V / 52V) Price: Call Us |
| 76 |
04040-15 |
Flatwasher, 5/16-.375 x .875 x .083 (35BV & 37BV-EFI) Price: Call Us |
| 77 |
04117-01 |
Nut, Flange Head Elastic Stop 5/16-18 Price: Call Us |
| 78 |
428248 |
Bracket, Muffler Mount Price: Call Us |
| 79 |
485792 |
Hose Assy., 27-1/2" Price: Call Us |
| 80 |
48572-04 |
Union, 3/4"-16 JIC x 3/4"-16 O-Ring Price: Call Us |
| 81 |
486837 |
Tube Assy. Price: Call Us |
| 82 |
04001-136 |
Bolt, Hex Head 3/8-16 x 1-1/2" Grade 8 Black Price: Call Us |
| 83 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 84 |
04001-18 |
Bolt, Hex Head, 3/8-16 x 3/4" Price: Call Us |
| 483280 |
Tubing, |
Oil Drain (order by inch) Price: Call Us 483280 |
