| Ref | Part Number | Description |
|---|
| 1 |
33115-045 |
SCREW-HH Price: $0.61 |
| 2 |
33095-00 |
WASHER-FLAT Price: $0.25 |
| 2 |
581627301 |
DECAL.BADGE.170MM.TEXTLOGO. This part replaces 532402832. Price: $11.99 |
| 3 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 4 |
33114-060 |
SCREW-HH Price: $0.88 |
| 4 |
532410778 |
DECAL, HOOD PANEL Price: $10.99 |
| 5 |
33094-00 |
WASHER-PLAIN Price: $0.25 |
| 5 |
532423829 |
DECAL.WARNING.CUST.RESP.E85. This part replaces 532180941. Price: $14.99 |
| 6 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 6 |
532410630 |
DECAL.REPLACEMENT.LTH1538.2007 Price: $2.99 |
| 7 |
532404484 |
DECAL.WHEEL.STRG.LGN.H Price: $7.99 |
| 7 |
98-1471 |
WHEEL-STEERING This part replaces 94-3500. Price: $145.99 |
| 8 |
532408829 |
DECAL.ENG.BS15.5HP.INTEK.GEN Price: $2.99 |
| 8 |
88-3870 |
COVER-WHEEL Price: $13.83 |
| 9 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 9 |
532145005 |
DECAL BTRY SYMBOLS Price: $3.99 |
| 10 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 11 |
581579501 |
DECAL.MOWER.WARN.KEEP.HAND.AWY This part replaces 532170563. Price: $3.99 |
| 11 |
98-5463 |
ROD - STEERING Price: $156.27 |
| 12 |
531229003 |
NEEDS DESCRIPTION This part replaces 532194302. Price: $1.99 |
| 12 |
98-5442 |
BALL JOINT Price: $107.81 |
| 13 |
532199114 |
DECAL.FEND.INS/WARN.HY Price: $8.99 |
| 13 |
532411056 |
PAD, FOOTREST, RH Price: $5.99 |
| 13 |
532439681 |
PAD.FOOT.LH.HUSQ.ERGO.LT.GREY This part replaces 532410805. Price: $8.99 |
| 13 |
581724801 |
DECAL.BYPASS.FENDER.CRD/LT/YT This part replaces 532166960. Price: $3.99 |
| 13 |
93-6768-03 |
GEAR-SECTOR This part replaces 93-6768. Price: $243.62 |
| 14 |
98-5325-03 |
STEERING SHAFT & GEAR ASM This part replaces 98-5325. Price: $274.53 |
| 15 |
256-27 |
BUSHING Price: $8.21 |
| 16 |
93-6769-03 |
COLUMN-STEERING This part replaces 93-6769. Price: $106.54 |
| 17 |
48-7960 |
NUT This part replaces 33015-00. Price: $1.40 |
| 18 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 20 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 22 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 23 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 24 |
92-3162 |
BUSHING Price: $2.78 |
| 25 |
98-5462 |
DISCONTINUED Price: Call Us |
| 26 |
52-6450 |
DISCONTINUED Price: Call Us |
| 27 |
52-6430 |
WASHER Price: $0.25 |
| 28 |
55-7120 |
SWITCH-BRAKE, PARKING Price: $40.99 |
| 29 |
3230-3 |
SCREW-CARR Price: $0.53 |
| 30 |
98-5680 |
PLATE - SWITCH Price: Call Us |
| 31 |
87-5140 |
NUT-LOCK Price: $0.25 |
| 32 |
98-5847 |
MUFFLER CLAMP Price: $13.69 |
