| Ref | Part Number | Description |
|---|
| 1 |
532175465 |
RAIL, FRAME RH Price: $78.23 |
| 1 |
75-4060 |
SCREEN FRAME ASM Price: $321.64 |
| 2 |
532175282 |
DRAWBAR, GT Price: $59.99 |
| 2 |
75-1040 |
COOLER-OIL Price: $761.60 |
| 3 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 4 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 4 |
873800700 |
Nut, Lock Hex 7/16 Unc Price: $3.99 |
| 5 |
583716201 |
DASH.STEALTH YTGT.2CYL.BLK 428 This part replaces 532163976. Price: $34.99 |
| 5 |
75-4260-03 |
RADIATOR SUPPORT ASM This part replaces 75-4260. Price: $271.55 |
| 6 |
532157882 |
DASH VGT, LOWER Price: $29.99 |
| 7 |
119-2241 |
COOLING ASM This part replaces 75-6290. Price: $1,497.64 |
| 7 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 8 |
532145166 |
SUPPORT, BATTERY Price: $4.69 |
| 8 |
66-3240 |
CAP-RADIATOR Price: $25.30 |
| 9 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 10 |
110-6186 |
HOSE-FUEL This part replaces 75-2850. Price: $15.70 |
| 11 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 12 |
75-4350 |
FAN SHROUD Price: $192.50 |
| 13 |
3290-271 |
RIVET-POP Price: $0.25 |
| 14 |
532189903 |
HOOD.ASM.PNT.STEALTH This part replaces 532175259. Price: $121.99 |
| 14 |
76-8750 |
PLATE-WARNING Price: $9.67 |
| 15 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 15 |
583125201 |
KIT.HARNESS/LIGHT ASM DUAL This part replaces 532161841. Price: $109.99 |
| 16 |
321-4 |
SCREW-HH Price: $0.99 |
| 16 |
532121794 |
COVER ACCESS Price: $3.99 |
| 17 |
75-6170 |
DISCONTINUED Price: Call Us |
| 17 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 18 |
532182873 |
GRILLE.STEALTH P/L.YTGT.GREY This part replaces 532169846. Price: $169.99 |
| 18 |
75-2240 |
DISCONTINUED Price: Call Us |
| 19 |
2412-3 |
CLAMP-HOSE Price: $3.49 |
| 19 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 20 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 20 |
75-6150 |
HOSE Price: $117.73 |
| 21 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 21 |
75-2260 |
HOSE - RADIATOR LOWER Price: $66.30 |
| 22 |
66-3180 |
TUBE-VENT Price: $18.60 |
| 24 |
532145243 |
FOOTREST LT/YT/GT RH Price: $9.15 |
| 24 |
75-4701 |
HOSE-FUEL Price: $8.20 |
| 25 |
2412-103 |
CLAMP Price: $2.51 |
| 25 |
583125201 |
KIT.HARNESS/LIGHT ASM DUAL This part replaces 532161842. Price: $109.99 |
| 26 |
32149-7 |
NUT-KEPS Price: $0.27 |
| 27 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 28 |
532147203 |
FOOT REST LH This part replaces 532145244. Price: $9.15 |
| 29 |
3269-13 |
RIVET-POP Price: $0.25 |
| 30 |
532145052 |
SADDLE.HYDRO.95 Price: $4.99 |
| 30 |
75-4310-03 |
RADIATOR SHIELD ASM This part replaces 75-4310. Price: $210.73 |
| 31 |
532161419 |
BRACKET SUPT 1-PC VGT STEERING Price: $3.99 |
| 31 |
75-2860 |
DISCONTINUED Price: Call Us |
| 32 |
322-4 |
SCREW-HH Price: $0.35 |
| 32 |
532161327 |
BRACKET Price: $5.99 |
| 33 |
532161326 |
BRACKET. Price: $3.99 |
| 34 |
532177018 |
PLATE ASM ENG CHASSIS Price: $32.99 |
| 34 |
56-7974 |
CLAMP-TUBE Price: $2.17 |
| 35 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 35 |
63-7590 |
RELAY Price: $78.15 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
532167287 |
FENDER Price: $109.23 |
| 37 |
66-8800 |
RELAY Price: $87.56 |
| 38 |
75-1020 |
DISCONTINUED Price: Call Us |
| 39 |
532175278 |
BRACKET AXLE, FRONT Price: $9.99 |
| 39 |
75-3390-03 |
BRACKET-BACKLAP This part replaces 75-3390. Price: $11.98 |
| 40 |
322-2 |
SCREW-HH Price: $0.69 |
| 42 |
218-498 |
NUT-LOCK Price: $0.68 |
| 42 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 43 |
32105-8 |
SCREW-SHH Price: $1.99 |
| 43 |
532136939 |
FRONT SUSPENSION BRKT LH Price: $12.99 |
| 44 |
532136940 |
FRONT SUSPENSION BRKT RH Price: $12.99 |
| 44 |
67-4700 |
GLOW LAMP Price: $117.35 |
| 45 |
532154913 |
BRACKET SUSP RH Price: $6.99 |
| 45 |
70-8560 |
DISCONTINUED Price: Call Us |
| 46 |
75-6140 |
HOSE Price: $85.40 |
| 47 |
237-65 |
O-RING Price: $2.50 |
| 47 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 48 |
340-108 |
FITTING-HYD Price: $42.30 |
| 49 |
3269-15 |
RIVET-POP Price: $0.54 |
| 50 |
532175476 |
BRACKET, CHASSIS FRONT Price: $14.99 |
| 50 |
75-0930 |
HOOK-MOUNT, COOLER Price: $22.00 |
| 51 |
240-3 |
GROMMET-RUBBER Price: $17.44 |
| 52 |
304-46 |
DRAINCOCK Price: $7.55 |
| 53 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 55 |
3269-10 |
WASHER-BACK Price: $0.61 |
| 56 |
532154914 |
BRACKET ASM, SUSP CHASSIS Price: $6.99 |
| 56 |
75-5180 |
DISCONTINUED Price: Call Us |
| 57 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 58 |
3334-945 |
TIE-CABLE This part replaces 3333-975. Price: $0.43 |
| 58 |
532183569 |
BRACKET ASM., FENDER This part replaces 532175315. Price: $9.99 |
| 59 |
322-6 |
SCREW-HH Price: $0.45 |
| 60 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 61 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 62 |
32128-20 |
NUT-HF Price: $0.99 |
| 63 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 70 |
532177679 |
KEEPER, BELT VGT GROUND Price: $4.99 |
| 84 |
532142992 |
MOWER STOP Price: $4.99 |
| 86 |
596238601 |
Bolts This part replaces 874760716. Price: $2.99 |
| 90 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 91 |
532175464 |
RAIL, FRAME LH Price: $78.23 |
| 98 |
532175847 |
BRKT, CHASSIS SKID Price: $10.95 |
| 99 |
532140871 |
ROD ASMBLY BYPASS Price: $15.99 |
| 100 |
532071673 |
PLUNGER CAP Price: $4.99 |
| 101 |
599972501 |
BOLT This part replaces 817490628. Price: $2.99 |
| 102 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 103 |
532142273 |
BRACKET LOCK BYPASS Price: $2.99 |
| 106 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532138776. Price: $3.99 |
| 122 |
532161464 |
SCREW.HEX.WS.HD.8-18 X 7/8 Price: $3.99 |
| 130 |
532189747 |
SCREW.HI-LO#13-16X5/8 This part replaces 532164863. Price: $14.99 |
| 138 |
583710501 |
CUPHOLDER.YTGT.TWIST LOCK.418 This part replaces 532163975. Price: $9.99 |
| 139 |
532171873 |
BOLT, SHOULDER 5/16-18 Price: $4.99 |
| 140 |
532163806 |
MAGNET STEALTH Price: $7.27 |
| 141 |
532163805 |
STRIKER PLATE Price: $4.99 |
| 142 |
532161897 |
BRACKET DASH STEALTH(R) Price: $5.99 |
| 143 |
532169847 |
SKIRT, GRILLE RH Price: $21.99 |
| 144 |
532161900 |
BRACKET DASH STEALTH LH Price: $5.99 |
| 146 |
532169848 |
SKIRT, GRILLE LH Price: $22.99 |
| 147 |
532189747 |
SCREW.HI-LO#13-16X5/8 This part replaces 532164863. Price: $14.99 |
| 148 |
532164655 |
EXTRUSION BUMPER (3 2) (2 2) Price: $5.99 |
| 150 |
532190309 |
DUCT.HEAT.HOOD.STEALTH.GT This part replaces 532161237. Price: $39.99 |
| 152 |
532177956 |
BROWNING SHIELD Price: $29.99 |
| 153 |
532174885 |
LENS ASM HEADLITE DUAL Price: $84.10 |
