| Ref | Part Number | Description |
|---|
| 1 |
20-4840 |
CLAMP-MUFFLER Price: $15.06 |
| 1 |
532176026 |
DECK SVC 46"3 BLADE 156948X431 This part replaces 532182220. Price: $249.99 |
| 2 |
3217-6 |
NUT-HEX Price: $1.19 |
| 3 |
532138457 |
BRACKET SWAY BAR Price: $9.99 |
| 4 |
108-3833 |
FILTER-AIR This part replaces 27-7110. Price: $26.73 |
| 5 |
27-7120 |
NUT AND GASKET ASM Price: $15.55 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 6 |
27-7140 |
SKIRT-BAFFLE Price: $85.92 |
| 6 |
531149301 |
SERVICE KIT BAR BAR SWAY DECK. This part replaces 532178024. Price: $9.99 |
| 7 |
27-7130 |
CLAMP ASM Price: $49.80 |
| 8 |
27-7150 |
A/C CUP ASM Price: $82.89 |
| 8 |
532850857 |
BLADE BOLT Price: $3.99 |
| 9 |
2412-3 |
CLAMP-HOSE Price: $3.49 |
| 9 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 10 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 10 |
95-1836 |
AIR CLEANER HOSE Price: $43.61 |
| 11 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 11 |
532152443 |
MULCH BLADE 46" Price: $17.99 |
| 11 |
532176084 |
BLADE.46".HI-LIFT.PREMIUM Price: $22.99 |
| 12 |
80-3330 |
GASKET Price: $18.48 |
| 13 |
322-10 |
SCREW-HH Price: $0.70 |
| 13 |
532137553 |
SHAFT.ASM.W/BEARING Price: $32.99 |
| 14 |
32107-11 |
NUT-SQUARE Price: $0.22 |
| 14 |
532137152 |
HOUSING.MANDREL.44/46" VENT Price: $34.99 |
| 15 |
27-7170 |
MOUNTING BAND ASM Price: $48.11 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
3258-19 |
SCREW Price: $0.42 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532174493. Price: $6.99 |
| 17 |
27-7100 |
AIR CLEANER ASM Price: $323.10 |
| 18 |
44-8950-03 |
AIR CLEANER TUBE This part replaces 44-8950. Price: $53.15 |
| 18 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 19 |
115-8155 |
DECAL-WARNING This part replaces 93-7275. Price: $5.90 |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $4.99 |
| 20 |
27-7180 |
CAP Price: $70.51 |
| 20 |
531154201 |
SERVICE KIT BAFFLE BAFFLE This part replaces 532145055. Price: $6.99 |
| 21 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
532134753 |
STIFFENER BRACKET Price: $5.99 |
| 22 |
77-3180 |
SPACER Price: $9.09 |
| 23 |
529845901 |
SERVICE KIT BRKT This part replaces 532131267. Price: $4.99 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
532123713 |
SPRING TORSION This part replaces 532149287. Price: $6.99 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
532166883 |
DEFLECTOR.CLIPPING.46" This part replaces 532172514. Price: $38.99 |
| 28 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga. Price: $5.99 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $3.99 |
| 32 |
532173434 |
MANDREL PULLEY Price: $14.99 |
| 33 |
596134801 |
Nuts This part replaces 532178342. Price: $1.00 |
| 34 |
532144945 |
ANCHOR, SPRING DECK 46" Price: $4.99 |
| 35 |
599972501 |
BOLT This part replaces 817490628. Price: $2.99 |
| 36 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 37 |
597025001 |
CLG This part replaces 532173438. Price: $22.99 |
| 38 |
532156086 |
KEEPER.BELT.IDLER This part replaces 532173900. Price: $5.99 |
| 39 |
532144917 |
PULLEY.DRIVEN.DECK.46" This part replaces 532173899. Price: $27.99 |
| 40 |
532137273 |
SPRING.SEC.44"VEN Price: $6.99 |
| 41 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 42 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 43 |
532144949 |
ARM IDLER DECK 46" Price: $4.99 |
| 44 |
532178515 |
WASHER This part replaces 532133943. Price: $5.99 |
| 45 |
532145059 |
COVER MANDREL 46 Price: $14.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
532144959 |
BELT V SECONDARY Price: $37.99 |
| 48 |
532148763 |
V-BELT PRIMARY 50" Price: $54.99 |
| 49 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 50 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 52 |
532173901 |
PULLEY.IDLER.FLAT.46".PRIMARY Price: $27.99 |
| 72 |
596140201 |
Washers This part replaces 819131616. Price: $2.99 |
| 91 |
531151201 |
SERVICE KIT BRACKET BRACKET AS This part replaces 532180532. Price: $4.99 |
| 94 |
532132264 |
NOSE ROLLER Price: $29.99 |
| 95 |
531150601 |
SERVICE KIT BRACKET BRACKET AS This part replaces 532180533. Price: $4.99 |
| 116 |
596434404 |
Bolts This part replaces 532137644. Price: $4.99 |
| 117 |
532133957 |
WHEEL GAGE DONUT Price: $11.99 |
| 118 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 119 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 126 |
532144948 |
ARM IDLER PRIM 46 Price: $4.99 |
| 127 |
593787801 |
PULLEYS This part replaces 532173902. Price: $27.99 |
| 132 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 182 |
532179126 |
ROD ROLLER NOSE STANDARD Price: $7.99 |
| 183 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
