| Ref | Part Number | Description |
|---|
| 1 |
683-05167-0637 |
STEER PEDESTAL ASSEMBLY (POWDER BLACK) Price: $48.42 |
| 1 |
73510500 |
Nut, Keps 5/16-18 Price: Call Us |
| 2 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 3 |
710-06194 |
SCREW 5/16-18 x .750 GR8 Price: $3.70 |
| 3 |
73220600 |
Nut, Hex 3/8-16 Price: Call Us |
| 4 |
170127 |
Shield Inner Belt Guard Price: Call Us |
| 4 |
710-1652 |
SCREW 1/4-20X.625 Price: $3.86 |
| 5 |
154734 |
Screw Shift Lever Price: Call Us |
| 5 |
712-0429 |
Hex L-Nut 5/16-18 Thd. This part replaces 912-0429. Price: $3.56 |
| 6 |
110111X |
Lever, Shift Price: Call Us |
| 6 |
783-13996-0637 |
SEAT PIVOT BRACKET (POWDER BLACK) This part replaces 783-07168-0637. Price: $5.59 |
| 7 |
72110404 |
Bolt, Carriage 1/4-20 x 1/2 Gr. 5 Price: Call Us |
| 7 |
783-13995-0637 |
SEAT PAN (POWDER BLACK) This part replaces 783-08197-0637. Price: $36.55 |
| 8 |
8700J |
Plate, Shift Indicator Price: Call Us |
| 9 |
86777 |
Screw, Hex, Washer Head, Slotted #10-24 x 1/2 Price: Call Us |
| 10 |
9484R |
Clip Price: Call Us |
| 11 |
10040400 |
Washer, Lock 1/4 Price: Call Us |
| 12 |
73220400 |
Nut, Hex 1/4-20 Price: Call Us |
| 13 |
23230506 |
Screw, Set, Hex 5/16-18 x 3/8 Price: Call Us |
| 14 |
156117 |
Spacer, Split 0.327 x 0.42 x 1.220 Price: Call Us |
| 15 |
19111116 |
Washer 11/32 x 11/16 x 16 Ga. Price: Call Us |
| 16 |
145102 |
Sheave, Transmission Price: Call Us |
| 19 |
12000028 |
Ring, Retainer Price: Call Us |
| 21 |
110652X |
Spacer, Split 0.327 x 0.42 x 2.09 Price: Call Us |
| 22 |
74770508 |
Bolt Fin Hex 5/16-24 x 1/2 Price: Call Us |
| 23 |
127259X |
Rim Price: Call Us |
| 23 |
5015J |
Tire Price: Call Us |
| 23 |
795R |
Tire Valve Price: Call Us |
| 24 |
126875X |
Rivet, Drilled Price: Call Us |
| 25 |
4497H |
Clip, Hairpin Price: Call Us |
| 26 |
165501X428 |
Guard, Belt Price: Call Us |
| 27 |
132801 |
Belt, V Price: Call Us |
| 28 |
104679X |
Pulley, Idler Price: Call Us |
| 29 |
12000032 |
Ring, Klip Price: Call Us |
| 30 |
159229 |
Bracket, Idler Price: Call Us |
| 31 |
102384X |
Bolt, Hex 5/16-16 x 12 Price: Call Us |
| 32 |
102141X |
Shaft, Idler Arm Price: Call Us |
| 33 |
74760616 |
Bolt, Hex 3/8-16 x 1 Price: Call Us |
| 34 |
102383X |
Counterweight, L. H. Price: Call Us |
| 35 |
74760532 |
Bolt, Hex 5/16-18 x 1-1/2 Price: Call Us |
| 36 |
102331X |
Bracket, Reinforcement, L. H. Price: Call Us |
| 37 |
130812 |
Sheave, Engine Price: Call Us |
| 38 |
74760544 |
Bolt Fin Hex 5/16-18 x 2-3/4 Price: Call Us |
| 39 |
140062 |
Cap, Plunger Blk Price: Call Us |
| 40 |
170488 |
Screw Hex Wsh. SLT #10-24 x .50 Price: Call Us |
| 43 |
69180 |
Nut Lock #10-24 Price: Call Us |
| 44 |
73800500 |
Nut Lock Hx W/Ins 5/16-18 Price: Call Us |
