| Ref | Part Number | Description |
|---|
| 1 |
532406623 |
SEAT.TP150.BLK.PPRO.KB/SL Price: $169.99 |
| 1 |
631776A |
SHAFT & LEV This part replaces 631776. Price: $12.00 |
| 2 |
256-268 |
BUSHING Price: $18.24 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $5.99 |
| 2 |
631970 |
RET SPRING Price: $3.00 |
| 3 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 3 |
532140675 |
STRAP Price: $3.99 |
| 3 |
631778 |
SHUTTER Price: $1.20 |
| 4 |
105-7441 |
BEARING-SPHERICAL Price: $56.85 |
| 4 |
650506 |
SCREW Price: $0.87 |
| 5 |
32151-34 |
RING-RETAINING Price: $0.67 |
| 5 |
630766 |
SPRING Price: $1.25 |
| 5A |
630738 |
SPRING Price: $1.25 |
| 5B |
630766 |
SPRING Price: $1.25 |
| 6 |
119-2200 |
PAD-RUBBER, REAR HOC Price: $10.33 |
| 6 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 6 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 7 |
119-2230 |
PAD-PLASTIC, REAR HOC Price: $7.14 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $2.99 |
| 7D |
632217 |
SHAFT & LEV Price: $7.49 |
| 8 |
110-0606 |
RIVET-BLIND Price: $1.15 |
| 8 |
532171877 |
BOLT, 5/16-18 X 1 3/4 Price: $3.99 |
| 8 |
632043 |
SPRING Price: $1.25 |
| 8A |
630735 |
SPRING Price: $1.25 |
| 9 |
631753 |
SHUTTER Price: $1.25 |
| 10 |
532196977 |
PAN.ASM.SEAT.3PT Price: $32.99 |
| 10 |
630748 |
WELCH PLUG Price: $1.17 |
| 11 |
631027 |
WELCH PLUG Price: $1.17 |
| 12 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 13 |
631022 |
CLIP Price: $1.25 |
| 14 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 15 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 16 |
631867 |
FLOAT BOWL Price: $2.34 |
| 21 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $1.99 |
| 22 |
631583 |
POWER SCREW Price: $10.18 |
| 23 |
630740 |
O RING Price: $1.49 |
| 23A |
630740 |
O RING Price: $1.49 |
| 24 |
630898 |
ADJ SCREW Price: $1.69 |
| 25 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 27 |
631184 |
WASHER Price: $1.25 |
| 27A |
631184 |
WASHER Price: $1.25 |
| 29 |
631183 |
WASHER This part replaces 631971. Price: $1.25 |
| 29A |
631183 |
WASHER Price: $1.25 |
| 30 |
630739 |
WASHER Price: $1.25 |
| 30A |
630739 |
WASHER Price: $1.25 |
| 31 |
632164 |
FUEL FITTING Price: $5.95 |
| 37 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.99 |
| 40 |
532197661 |
HANDLE.SLIDE.SEAT.TEX.BLACK Price: $12.99 |
| 41 |
532198200 |
SPRING.LATCH.SEAT.TEX Price: $2.99 |
| 43 |
874760612 |
BOLT Price: $1.99 |
