| Ref | Part Number | Description |
|---|
| 1 |
3219-2 |
NUT-HEX Price: $0.37 |
| 1 |
531301136 |
XT Wear Plate Price: $38.95 |
| 2 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 2 |
531301170 |
XT Actuator Spring Price: $14.95 |
| 3 |
21-8270 |
PIN-DOWEL Price: $6.65 |
| 3 |
531301171 |
XT Slipper Plate Price: $1.75 |
| 4 |
21-7720 |
WASHER-THRUST Price: $3.39 |
| 4 |
531301172 |
Screw, 1/4 -20 x 3/4, Flat Head Price: $0.25 |
| 5 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 24-8790. Price: $702.98 |
| 5 |
531301173 |
XT Deck Plate Price: $85.95 |
| 6 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 21-7690. Price: $702.98 |
| 6 |
531301174 |
Screw 1/4 - 20 x 1 Hex Cap Price: $0.25 |
| 7 |
21-7730 |
WASHER-THRUST, PINION Price: $2.65 |
| 7 |
531301175 |
Washer, Flat 1/4 Price: $0.25 |
| 8 |
531301176 |
Washer, Lock 1/4 Price: $0.25 |
| 9 |
43-6760 |
BEARING-ROLLER, CONE TAPER Price: $113.20 |
| 9 |
531301177 |
Hex Nut 1/4 - 20 Price: $0.25 |
| 10 |
43-6750 |
BEARING-TAPER, CUP Price: $69.64 |
| 10 |
531301178 |
Screw, 5/16 - 18 x 5/8 Hex Cap Price: $0.29 |
| 11 |
531301179 |
Washer, lock 5/16 Price: $0.25 |
| 11 |
92-1773 |
SCREW-HHF Price: $3.05 |
| 12 |
531301180 |
XT Deck Joint Pin Price: $4.95 |
| 13 |
32144-112 |
SCREW-HWH Price: $0.99 |
| 13 |
531301181 |
XT Deck Bracket Price: $29.95 |
| 14 |
531301182 |
XT Stop Bar Assembly Price: $18.95 |
| 14 |
86-7230 |
GEAR-INPUT, TRANSMISSION Price: $610.12 |
| 15 |
43-6710 |
SHIM-PINION (.003) Price: $2.17 |
| 15 |
531301183 |
XT Torsion Spring, LH Price: $3.95 |
| 16 |
43-6711 |
SHIM-PINION (.005) Price: $3.80 |
| 16 |
531301184 |
XT Mandrel Sleeve, Left Price: $1.89 |
| 17 |
43-6712 |
SHIM-PINION (.010) Price: $3.19 |
| 17 |
531301152 |
XT Guard Price: $7.95 |
| 18 |
43-6713 |
SHIM-PINION (.030) Price: $6.99 |
| 18 |
531030829 |
Bumper Stop Price: $2.29 |
| 19 |
3210-7 |
SCREW-HH Price: $0.61 |
| 19 |
531030826 |
Bronze Bearing, .5095 x 5/8 x 3/4 Price: $1.46 |
| 20 |
531301153 |
XT Mandrel Sleeve, Right Price: $1.89 |
| 20 |
71-4350 |
NUT Price: $3.46 |
| 21 |
531301154 |
XT Torsion Spring, RH Price: $4.95 |
| 21 |
83-5130 |
SPACER-PINION Price: $87.56 |
| 22 |
531301155 |
Hex Nut 5/16 - 18 Price: $0.25 |
| 22 |
72-3572 |
SHIM-BEARING, FRONT (.098) This part replaces 72-3570. Price: $23.68 |
| 22 |
72-3573 |
SHIM-BEARING, FRONT (.100) Price: $24.63 |
| 22 |
72-3598 |
SHIM-BEARING, FRONT (.149) Price: $24.63 |
| 23 |
254-91 |
CONE-BEARING Price: $18.65 |
| 23 |
531301156 |
XT Lift Arm Assembly Price: $18.95 |
| 24 |
254-90 |
BEARING-CUP This part replaces 21-8390. Price: $11.29 |
| 24 |
531030833 |
Ball Socket Price: $7.24 |
| 25 |
21-8020 |
SPACER-BEARING Price: $28.84 |
| 25 |
531030835 |
Ball Stud Price: $0.86 |
| 26 |
531030832 |
Gas Spring Price: $29.02 |
| 26 |
86-7190 |
UPPER HOUSING ASM Price: $889.26 |
| 27 |
254-66 |
CUP-BEARING, ROLLER Price: $17.92 |
| 27 |
531030834 |
Ball Joint Seal Price: $0.16 |
| 28 |
254-65 |
BEARING-ROLLER, CONE Price: $62.13 |
| 28 |
531030851 |
Gas Spring Safety Clip Price: $0.74 |
| 29 |
531301157 |
XT Center Joint Pin Price: $9.95 |
| 30 |
32121-15 |
PIN-ROLL This part replaces 21-7710. Price: $1.60 |
| 30 |
531030846 |
Hairpin Cotter Price: $1.07 |
| 31 |
21-7700 |
SHAFT-MATE, PINION Price: $54.05 |
| 31 |
531301158 |
XT Mounting Bracket Price: $9.95 |
| 32 |
21-7770 |
SCREW-GEAR, DRIVE Price: $1.97 |
| 32 |
531301159 |
XT Connecting Pin Price: $9.95 |
| 33 |
21-7670 |
CASE-DIFFERENTIAL Price: $687.90 |
| 33 |
531030843 |
Bracket Backing Plate Price: $15.61 |
| 34 |
531301160 |
Screw 3/8 - 16 x 1 1/4 Hex Cap Price: $0.25 |
| 34 |
75-0720 |
DISCONTINUED Price: Call Us |
| 35 |
21-8120 |
SHIM-BEARING, DIFFERENTIAL (.030) Price: $5.43 |
| 35 |
531301161 |
Washer, Flat 3/8 Price: $0.25 |
| 36 |
21-8110 |
SHIM-BEARING, DIFFERENTIAL (.010) Price: $3.73 |
| 36 |
531301162 |
Washer, Lock 3/8 Price: $0.25 |
| 37 |
21-8100 |
SHIM-BEARING, DIFFERENTIAL (.005) Price: $3.46 |
| 37 |
531301163 |
Hex Nut 3/8 - 16 Price: $0.25 |
| 38 |
21-8090 |
SHIM-BEARING, DIFFERENTIAL (.003) Price: $1.09 |
| 38 |
531301164 |
Decals, Proslide XT and Warning Price: $10.95 |
| 39 |
531301165 |
XT Torsion Spring Replacement Kit Price: $7.95 |
| 39 |
72-9420 |
VENT This part replaces 21-8230. Price: $6.85 |
| 40 |
531030831 |
Gas Spring Assembly Price: $43.43 |
| 40 |
83-4910 |
COUPLER-PINION Price: $223.04 |
| 41 |
531301166 |
XT Lower Arm Assembly Price: $74.95 |
| 41 |
71-4330 |
SEAL Price: $36.26 |
| 42 |
531301167 |
XT Upper Arm Assembly Price: $78.95 |
| 43 |
531301168 |
XT Mounting Bracket Kit Price: $39.95 |
