| Ref | Part Number | Description |
|---|
| 1 |
127-3011 |
STUD Price: $8.87 |
| 1 |
532159461 |
WIRE.ASM.INNER.SP Price: $12.99 |
| 2 |
127-3001 |
GENERATOR Price: $1,526.12 |
| 2 |
532159476 |
SHAFT.ASM.LIFT.RH.INF Price: $54.99 |
| 3 |
127-3190 |
NUT Price: $4.86 |
| 3 |
583172901 |
PIN.GROOVE.5/16 This part replaces 532188822. Price: $4.99 |
| 4 |
127-2951 |
ROTOR ASM Price: $326.08 |
| 4 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 5 |
127-2983 |
BEARING-BALL Price: $23.48 |
| 5 |
819211621 |
WASHER Price: $4.99 |
| 6 |
127-2962 |
COVER Price: Call Us |
| 6 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 7 |
127-2952 |
FRAME ASM Price: Call Us |
| 8 |
127-2958 |
BEARING-BALL Price: $25.78 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 9 |
127-2959 |
PLATE-RETAINER Price: Call Us |
| 10 |
127-2960 |
SCREW Price: Call Us |
| 11 |
127-2961 |
STUD Price: Call Us |
| 11 |
532165828 |
LIFT LINK, LH This part replaces 532165829. Price: $17.99 |
| 12 |
127-2953 |
FRAME ASM Price: $57.52 |
| 12 |
532165830 |
LINK ASSY. This part replaces 532165831. Price: $9.99 |
| 13 |
127-2954 |
PULLEY Price: $69.59 |
| 13 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 14 |
127-2955 |
NUT Price: Call Us |
| 15 |
127-2957 |
COLLAR Price: $16.32 |
| 15 |
532173288 |
LINK.SUSPENSION.FRONT Price: $11.99 |
| 16 |
127-3002 |
REGULATOR ASM Price: $643.65 |
| 16 |
596433401 |
Nuts This part replaces 873350800. Price: $2.99 |
| 17 |
127-2963 |
HOLDER Price: $253.39 |
| 17 |
532175689 |
TRUNNION Price: $3.99 |
| 18 |
127-2993 |
HOLDER Price: $95.21 |
| 18 |
596135601 |
GSPW NUTS This part replaces 873800800. Price: $3.99 |
| 19 |
127-2956 |
BRUSH ASM Price: $8.83 |
| 19 |
531165801 |
SERVICE KIT ARM ARM.REAR.SUSPE This part replaces 532139868. Price: $11.99 |
| 20 |
127-2964 |
SPRING Price: $3.16 |
| 20 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 21 |
127-2965 |
SCREW Price: Call Us |
| 22 |
127-2966 |
SCREW Price: Call Us |
| 23 |
127-2999 |
COVER Price: $22.03 |
| 23 |
532110807 |
NUT T Price: $3.99 |
| 24 |
127-2967 |
BOLT Price: $9.43 |
| 24 |
819131016 |
WASHER Price: $2.99 |
| 25 |
127-2968 |
SCREW Price: $4.72 |
| 25 |
532137150 |
SPRING.COMP.INF.H Price: $4.99 |
| 26 |
127-2969 |
BOLT Price: Call Us |
| 26 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 27 |
127-2970 |
BUSHING-INSULATION Price: Call Us |
| 27 |
532137167 |
ROD.LIFT.ADJUSTABLE Price: $5.99 |
| 28 |
127-2971 |
NUT Price: Call Us |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
127-2972 |
WASHER Price: Call Us |
| 29 |
532138057 |
KNOB INF 3/8-16 Price: $6.99 |
| 30 |
125-7230 |
NUT Price: $2.81 |
| 30 |
532150233 |
TRUNNION Price: $9.99 |
| 31 |
125-6947 |
SPACER Price: $21.65 |
| 31 |
532169865 |
BEARING.PIVOT.LIFT Price: $5.99 |
| 32 |
127-2977 |
ADJUSTER Price: $113.82 |
| 32 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 33 |
125-7134 |
BOLT Price: $25.74 |
| 36 |
532155097 |
POINTER, HEIGHT INDICATOR(2 2) Price: $4.99 |
| 37 |
532123935 |
PLUG,HOLE Price: $4.99 |
| 38 |
593337601 |
Screws This part replaces 817060516. Price: $3.99 |
| 40 |
819112410 |
WASHER Price: $3.99 |
| 41 |
532123934 |
HEIGHT INDICATOR Price: $2.99 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 50 |
532110452 |
NUT PUSH M Price: $2.99 |
