| Ref | Part Number | Description |
|---|
| 1 |
110-4100 |
HOSE-FUEL This part replaces 23-2140. Price: $28.86 |
| 1 |
532170863 |
CONTROL,TH/CH FLAG This part replaces 532155274. Price: $27.99 |
| 2 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 2 |
596582501 |
Bolts This part replaces 817720410. Price: $2.99 |
| 2 |
BS-821299 |
CAMSHAFT BUSHING Not Available This part replaces BS-820129. Price: |
| 3 |
32128-44 |
NUT Price: $2.69 |
| 3 |
BS-821328 |
OIL SEAL Not Available This part replaces BS-820056. Price: |
| 4 |
110-9662 |
HOSE-FUEL This part replaces 51-0670. Price: $31.52 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 4 |
BS-820031 |
HEX SCREW Not Available Price: |
| 5 |
132-8621 |
BATTERY CORROSIVE This part replaces 83-9000. Price: $292.68 |
| 5 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 This part replaces 532146699. Price: $19.99 |
| 5 |
BS-820176 |
HEX SCREW Not Available Price: |
| 6 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 This part replaces 532146700. Price: $17.99 |
| 6 |
93-6775 |
CABLE-BATTERY, POS Price: $111.66 |
| 6 |
BS-820042 |
HEX SCREW Not Available Price: |
| 7 |
94-5980 |
CABLE-BATTERY, NEG Price: $92.64 |
| 7 |
BS-820016 |
METRIC STUD Not Available Price: |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 532150176. Price: $4.99 |
| 8 |
56-2520 |
FITTING-SHUT OFF, FUEL Price: $31.19 |
| 8 |
BS-820004 |
WELCH PLUG Not Available Price: |
| 9 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 9 |
BS-820151 |
WELCH CAMSHAFT PLUG Not Available Price: |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 10 |
56-2230 |
HOSE-FUEL Price: $3.66 |
| 10 |
BS-820375 |
CYLINDER BLOCK PLUG Not Available Price: |
| 11 |
93-3102 |
CAP-FUEL Price: $24.02 |
| 11 |
BS-820147 |
MOUNTING BRACKET Not Available Price: |
| 12 |
83-8720 |
TANK-FUEL Price: $576.65 |
| 12 |
BS-820063 |
LOCATING PIN Not Available Price: |
| 13 |
532163307 |
GASKET.KOHLER Price: $2.99 |
| 13 |
75-4703 |
HOSE Price: $16.06 |
| 13 |
BS-820062 |
LOCATING PIN Not Available Price: |
| 14 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 14 |
813280336 |
Nipple Pipe 3/8 Npt X 4-1/2" Price: $2.42 |
| 14 |
BS-820061 |
LOCATING PIN Not Available Price: |
| 15 |
532428287 |
VALUE.OIL.DRAIN This part replaces 813200300. Price: $14.99 |
| 15 |
63-8410 |
WASHER Price: $1.76 |
| 15 |
BS-820314 |
OIL FILTER Not Available Price: |
| 16 |
323-5 |
SCREW-HH Price: $0.41 |
| 16 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 16 |
BS-820851 |
OIL FILTER ADAPTER Not Available Price: |
| 17 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 17 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 817490624. Price: $6.99 |
| 17 |
BS-820102 |
OIL NOZZLE Not Available Price: |
| 18 |
83-9240 |
BRACKET-BATTERY Price: $32.49 |
| 18 |
BS-820145 |
GASKET-RETAINER Not Available Price: |
| 19 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 21 |
93-6668 |
DECAL-BATTERY Price: $18.99 |
| 22 |
93-7276 |
DECAL-DANGER Price: $15.13 |
| 23 |
3234-18 |
SCREW-HHF Price: $0.87 |
| 23 |
532159880 |
PROTECTOR Price: $7.99 |
| 24 |
323-101 |
Screw-Cap Hex. Hd. (Model No. 03422 Europe) Price: Call Us |
| 25 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 25 |
532145996 |
CONTROL, CHOKE Price: $19.99 |
| 26 |
873920600 |
Nut, Keps 3/8-24 Unf Price: $3.99 |
| 26 |
94-3698-01 |
WEIGHT - REAR This part replaces 94-3698. Price: $168.51 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
532157103 |
TANK.FUEL(3.5.GAL) Price: $69.99 |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532140527. Price: $22.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 34 |
532106082 |
PAD-SPACER LT Price: $3.99 |
| 35 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 37 |
587044808 |
HOSE.1/4".LOW.PERM.FUEL.LN.8" This part replaces 532124923. Price: $5.99 |
| 39 |
532109227 |
PAD IDLER TI Price: $3.99 |
| 81 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 532128861. Price: $2.99 |
