| Ref | Part Number | Description |
|---|
| 1 |
233-35 |
KNOB Price: $8.06 |
| 1 |
48811 |
Hose, 3/8" ID - 10-1/4" Long (Order By The Inch) Price: Call Us |
| 2 |
120-2244 |
HOURMETER This part replaces 12-9990. Price: $48.06 |
| 2 |
48136-13 |
Clamp, .69" Max. / .25" Min. Dia. Price: Call Us |
| 3 |
3219-14 |
NUT-HEX Price: $0.25 |
| 3 |
482266-01 |
Elbow, 90 Degree - 9/16" O-Ring x 3/8" Hose Price: Call Us |
| 4 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 5 |
38-1670 |
MTNG BRKT W/38-1660 This part replaces 26-4390. Price: $16.06 |
| 5 |
481164 |
CAP, HYDRAULIC TANK Price: Call Us |
| 6 |
27-2360 |
SWITCH Price: $46.56 |
| 6 |
481507 |
Insert, Filler Neck Price: Call Us |
| 7 |
482572 |
Elbow, 90 Degree, 9/16-18 JIC x 9/16 O-Ring Price: Call Us |
| 7 |
62-7770 |
KEY-IGNITION This part replaces 218-412. Price: $4.39 |
| 8 |
482571 |
Bushing, 0.56" Dia. Viton Price: Call Us |
| 8 |
83-0820 |
GAUGE - AMMETER This part replaces 38-1660. Price: $76.09 |
| 9 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 9 |
482572 |
Elbow, 90 Degree, 9/16-18 JIC x 9/16 O-Ring Price: Call Us |
| 10 |
3217-29 |
NUT-HEX Price: $0.25 |
| 10 |
48059-01 |
Clamp, Fuel Hose 1/4" Hose I.D. Price: Call Us |
| 11 |
26-6740 |
TEMP RESET RELAY Price: $165.84 |
| 11 |
484352-03 |
Cap Plug, .375 x 1.50 Price: Call Us |
| 12 |
26-6750 |
ENG TEMP SWITCH GAGE Price: $332.79 |
| 12 |
484317 |
Cooler, Transmission (52V/61V) Price: Call Us |
| 13 |
04001-01 |
BOLT, HEX HEAD, 1/4-20 X 3/4 GR.5 Price: Call Us |
| 13 |
322-3 |
SCREW-HH Price: $0.79 |
| 14 |
04003-02 |
Serr. Fl. Hex Head CPSCR, 1/4-20 x 3/4" Price: Call Us |
| 14 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 15 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 15 |
428492 |
Mounting Bracket, Oil Cooler (air cooled) Price: Call Us |
| 16 |
04019-02 |
NUT, 1/4-20 SERRATED FLANGE HEX HEAD Price: Call Us |
| 16 |
3217-6 |
NUT-HEX Price: $1.19 |
| 17 |
428196 |
Mounting Bracket, Cooler - LH Price: Call Us |
| 18 |
32128-17 |
NUT-LOCK, FLANGE Price: $0.25 |
| 18 |
428197 |
Mounting Bracket, Cooler - RH Price: Call Us |
| 19 |
3290-134 |
SCREW Price: $0.27 |
| 20 |
3254-1 |
WASHER-LOCK, INT Price: $0.49 |
| 22 |
28-1590 |
THROTTLE CONTROL Price: $35.36 |
| 23 |
3290-360 |
SCREW-HH Price: $4.34 |
| 24 |
22-7810 |
SPACER Price: $16.90 |
| 25 |
119-2865 |
KIT-GM300 BUZZER, LOW OIL PRESSURE This part replaces 22-7820. Price: $135.43 |
| 26 |
44-2220 |
LEAD WIRE ASM Price: $9.24 |
| 27 |
28-1600 |
CHOKE CONTROL Price: $42.26 |
| 28 |
70-2030 |
INST PANEL DECAL This part replaces 40-4400. Price: $18.52 |
| 29 |
218-516 |
LENS Price: $11.36 |
| 30 |
28-1580 |
INST PANEL Price: $130.00 |
| 428524 |
Mounting |
Bracket, Oil Cooler (liquid cooled) Price: Call Us 428524 |
