| Ref | Part Number | Description |
|---|
| 2 |
753-05802 |
AIR FILTER Not Available Price: |
| 3 |
710-04517 |
Screw Price: $4.71 |
| 4 |
791-181751 |
Carburetor O-Ring Price: $3.92 |
| 5 |
753-08025A |
CARBURETOR W/GASKET AND INSULATOR Not Available This part replaces 753-05676A. Price: |
| 6 |
753-05803 |
GASKET CARB Not Available Price: |
| 7 |
9052-1 |
SCREW, M5 X18 This part replaces 791-181003. Price: $3.78 |
| 8 |
753-05804 |
INSULATOR Not Available Price: |
| 9 |
712-04099 |
Nut Price: $5.94 |
| 10 |
753-05673 |
Insulator Gasket Price: $9.07 |
| 11 |
794-00082 |
Spark Plug This part replaces 753-05255. Price: $6.35 |
| 12 |
753-05266 |
Throttle Cable Price: $17.98 |
| 13 |
710-04742A |
Screw Price: $2.98 |
| 14 |
753-05671 |
Valve Cover Price: $11.73 |
| 15 |
753-05672 |
Valve O-Ring Price: $8.99 |
| 16 |
753-05681 |
Cylinder Gasket Price: $8.93 |
| 17 |
710-04604A |
SCREW M5X0.8 This part replaces 710-04604. Price: $3.63 |
| 18 |
753-05408 |
Oil Plug (Incl. 5) This part replaces 753-05400. Price: $25.95 |
| 20 |
753-05635 |
PAWL ASSEMBLY 26CC Not Available Price: |
| 21 |
753-05808 |
REAR COVER ASSEMBLY Not Available Price: |
| 22 |
710-04194 |
Screw Price: $3.66 |
| 23 |
753-05809 |
TOP ENGINE CVR Not Available Price: |
| 24 |
753-05670 |
Muffler Gasket Price: $8.99 |
| 25 |
753-05810 |
MUFFLER W/HDW Not Available Price: |
| 26 |
753-05301 |
Module Assembly Price: $99.77 |
| 27 |
753-05264 |
Lead Wires Price: $14.70 |
| 28 |
753-05811 |
CLUTCH HOUSING W/BEARING Not Available Price: |
| 29 |
753-05812 |
CLUTCH Not Available Price: |
| 30 |
690-120-0086 |
BLADE - 18" x 5/8" Not Available This part replaces 91-623. Price: |
| 31 |
753-05814 |
Spacer Price: $3.58 |
| 32 |
753-05815 |
FLYWHEEL AC4 Not Available Price: |
| 34 |
753-05289 |
Fuel Cap Price: $20.00 |
| 35 |
710-04394 |
SCREW 10-24X.50 Not Available Price: |
