| Ref | Part Number | Description |
|---|
| 1 |
76-1940 |
SPRING-EXTENSION Price: $66.03 |
| 2 |
580434401 |
DRAWBAR.STGT This part replaces 532401140. Price: $99.99 |
| 2 |
66-8560 |
NUT-PUSH Price: $5.97 |
| 3 |
76-1910 |
DISCONTINUED Price: Call Us |
| 4 |
92-6533 |
SEAT CUSHION KIT Price: $290.43 |
| 5 |
104-4620 |
SEAT This part replaces 92-1180. Price: $273.15 |
| 5 |
532403205 |
DASH.HUSQ.UPR.ELE.SVMD Price: $49.99 |
| 6 |
351-78 |
EDGING Price: $60.98 |
| 7 |
92-6534 |
ORDER COMPLETE SEAT Price: Call Us |
| 8 |
351-80 |
CLIP Price: $8.87 |
| 9 |
76-2940 |
BUMPER Price: $9.73 |
| 10 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 11 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 12 |
322-3 |
SCREW-HH Price: $0.79 |
| 13 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 14 |
532442396 |
HOOD.ASM.HUSQVARNA.GT.TEX.ORAN This part replaces 532401824. Price: $149.99 |
| 14 |
76-1920 |
SLEEVE-BEARING Price: $22.50 |
| 15 |
532198907 |
LENS.LH.TEX.GT.HUSQ.CL Price: $22.99 |
| 15 |
66-8610 |
DISCONTINUED Price: Call Us |
| 16 |
108-6702 |
ADJUSTER-SEAT, W/HANDLE This part replaces 66-8510. Price: $239.09 |
| 17 |
3217-6 |
NUT-HEX Price: $1.19 |
| 17 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 18 |
3253-33 |
WASHER-LOCK Price: $1.19 |
| 18 |
532408607 |
GRILL.ASM.HUSQ.TG/CRD.W/TRIM This part replaces 532400297. Price: $129.99 |
| 19 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 20 |
3218-2 |
NUT-JAM Price: $0.25 |
| 21 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 22 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 23 |
32128-25 |
NUT-HF Price: $3.19 |
| 24 |
76-1960 |
KNOB KIT This part replaces 77-2870. Price: $357.33 |
| 25 |
532198906 |
LENS.RH.TEX.GT.HUSQ.CL Price: $32.99 |
| 25 |
66-8600 |
FRAME-UPPER Price: $327.08 |
| 26 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 27 |
106-1031 |
TENSION ADJUSTER KNOB ASM This part replaces 76-1930. Price: $68.93 |
| 28 |
322-6 |
SCREW-HH Price: $0.45 |
| 29 |
93-3165 |
BRACKET Price: $37.47 |
| 30 |
93-3163 |
SPRING Price: $26.01 |
| 31 |
93-3164 |
CAP Price: $11.64 |
| 32 |
69-1180 |
ARMREST Price: $166.08 |
| 33 |
32128-19 |
NUT-HF Price: $0.99 |
| 34 |
323-9 |
SCREW-HH Price: $1.29 |
| 35 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 36 |
69-0770 |
BRACKET-ARM, RH Price: $117.82 |
| 37 |
532441208 |
FENDER.PNT.TX.GT.CH/FW/DL.HUSQ This part replaces 532401825. Price: $219.99 |
| 58 |
532194314 |
BRKT.SUPPORT.FNDR/TANK Price: $17.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 99 |
532406642 |
ROD.BYPASS.HYDRO.0510/0610.GT This part replaces 532198253. Price: $14.99 |
| 130 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 150 |
532198513 |
AIR.DUCT.TEXGT.HUSQ.SV Price: $37.99 |
| 161 |
532401801 |
FUEL WINDOW This part replaces 532401826. Price: $5.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 165 |
532194330 |
SUPPORT.TANK.REAR.B/TE Price: $17.99 |
| 175 |
590607702 |
PLATE.PNT.CROSSMEMBER.HUSQ/PRE This part replaces 532196304. Price: $32.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU This part replaces 532193232. Price: $4.99 |
| 177 |
532195227 |
BUSHING, STEERING Price: $5.99 |
| 178 |
532199782 |
CARGO.ASM.NET.TXGT.W/C Price: $29.99 |
| 180 |
582033101 |
KITS.TEX.BOLTED.CHASSIS.445559 This part replaces 532194260. Price: $229.99 |
| 181 |
532403025 |
BUSHING.MNT.FEND.CRGO. Price: $4.99 |
| 182 |
532406859 |
DASH.LOWER.COMMON.12V.ADAPTOR This part replaces 532194787. Price: $84.99 |
| 183 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 184 |
532195780 |
SPACER.FENDER Price: $5.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 196 |
532400299 |
RP CONSOLE.ASM.DECKLFT.W/ Price: $69.99 |
| 199 |
532198259 |
PLATE.DECK.LIFT.HUSQVARNA.GT Price: $17.99 |
| 202 |
532403048 |
VENT.SIDE.HOOD.HUSQ.RH.GREY Price: $7.99 |
| 203 |
532403076 |
VENT.SIDE.HOOD.HUSQ.LH.GRAY Price: $7.99 |
| 204 |
532416615 |
VENT.ASM.TORPHD.HUSQGT.LOGO.CL This part replaces 532198904. Price: $16.99 |
| 205 |
532401709 |
SKIRT.HOOD.SIDE.HUSQ.RH.GREY Price: $6.99 |
| 206 |
532401711 |
SKIRT.HOOD.SIDE.HUSQ.LH.GREY Price: $5.99 |
| 207 |
532197198 |
BEZEL.RH.TEX.GT.HUSQ Price: $19.99 |
| 208 |
532197199 |
BEZEL.LH.TEX.GT.HUSQ Price: $17.99 |
| 209 |
532199130 |
INSERT.HEX.GRILL.HUSQ.GREY Price: $4.99 |
| 210 |
532199131 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 211 |
532199132 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 212 |
532199133 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 221 |
532198909 |
REFLECTOR.LH.TEX GT HU Price: $14.99 |
| 222 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
