| Ref | Part Number | Description |
|---|
| 1 |
237-42 |
O-RING Price: $2.78 |
| 1 |
532439822 |
SEAT.TH150.MS498.GRY.HUSQ.TEX This part replaces 532406621. Price: $159.99 |
| 1 |
611-3033P |
AXLE SHAFT (RH) Not Available This part replaces 611-3033. Price: |
| 2 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $11.99 |
| 2 |
911-3034 |
AXLE SHAFT (LH) Not Available This part replaces 611-3034. Price: |
| 3 |
237-22 |
O-RING Price: $2.43 |
| 3 |
532140675 |
STRAP Price: $5.99 |
| 3 |
618-0226 |
Collar Assembly, Hi-Lo Price: $110.25 |
| 4 |
918-3183 |
DIFF LOCK COLLAR ASSEMBLY Not Available This part replaces 618-3183. Price: |
| 4 |
98-7413 |
HOSE ASM Price: $110.10 |
| 5 |
58-4750 |
TUBE-STEEL Price: $198.58 |
| 5 |
903-05045 |
DIFF LOCK BRACKET Not Available This part replaces 703-05045. Price: |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
710-0176 |
Screw, Hex Cap, 5/16-18 x 2.75 GR5 Price: $3.89 |
| 6 |
93-1410 |
HYD TUBE KIT-RM4500D Price: $421.12 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 7 |
710-0378 |
Screw, Hex Cap, 5/16-18 x 2.5 GR5 Price: $4.09 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 8 |
710-0602 |
Screw, Hex Wash. Hd. Tapp, 5/16-18 x 1.0 Price: $4.05 |
| 9 |
58-4780 |
TUBE-STEEL Price: $106.87 |
| 9 |
710-0817 |
Screw, Hex Wash. Hd. Tapp, 5/16-18 x 1.25 Price: $5.77 |
| 10 |
596768801 |
KIT.PLATE.SEAT This part replaces 532196977. Price: $49.99 |
| 10 |
710-1880 |
Screw, Hex Cap, w/Patch 5/16-18 x .75GR5 Price: $4.02 |
| 11 |
58-5710 |
HOSE ASM Price: $118.59 |
| 11 |
710-1633 |
Screw, Plug, M14 x 1.5 x .827 Price: $13.06 |
| 12 |
340-89 |
FITTING-HYD, 45 DEG Price: $40.22 |
| 12 |
710-3006 |
SCREW .375 x 5/16-18 Not Available Price: |
| 13 |
68-6370 |
HYD TUBE KIT Price: $324.47 |
| 13 |
710-04035 |
SCREW .309 x .375 x 1/4-20 Not Available Price: |
| 14 |
237-80 |
O-RING Price: $6.10 |
| 14 |
911-1675 |
OUTPUT SHAFT 11T Not Available This part replaces 711-1675. Price: |
| 15 |
58-3880 |
CLAMP-DOUBLE Price: $7.34 |
| 15 |
911-1676 |
DIFF CROSS SHAFT Not Available This part replaces 711-1676. Price: |
| 16 |
33113-050 |
SCREW-HH Price: $0.62 |
| 16 |
911-04302 |
DIFF LOCK ACTUATOR SHAFT Not Available This part replaces 711-04302. Price: |
| 17 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 17 |
911-04300 |
HI LO ACTUATOR SHAFT Not Available This part replaces 711-04300. Price: |
| 18 |
711-04137 |
DRIVE SHAFT Not Available Price: |
| 19 |
912-0273 |
Nut. Castle 5/16-24 This part replaces 712-0273. Price: $4.02 |
| 19 |
98-7408 |
HOSE ASM Price: $114.75 |
| 20 |
58-4850 |
TUBE-STEEL Price: $194.71 |
| 20 |
714-0135 |
Key, Woodruff, 1/4 x 3/4 Price: $4.05 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 21 |
68-6270 |
HYD TUBE KIT Price: $403.92 |
| 21 |
715-3010 |
DOWEL PIN-1/4 x 3/4 Not Available Price: |
| 22 |
60-2180 |
ADAPTOR Price: $132.52 |
| 22 |
916-0114 |
Retainer Ring This part replaces 716-0114. Price: $5.99 |
| 23 |
716-0127 |
Ring, Snap Price: $10.97 |
| 23 |
98-7406 |
HOSE ASM Price: $119.86 |
| 24 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 24 |
716-0180 |
Ring, Retaining Price: $10.38 |
| 25 |
716-0194 |
Clip, Rotor Price: $3.48 |
| 25 |
98-7411 |
HYD HOSE ASM Price: $96.07 |
| 26 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 26 |
916-04005 |
RETAINING RING .8 This part replaces 716-04005. Price: $4.19 |
| 27 |
916-04030 |
RETAINER WIRE RING Not Available This part replaces 716-04030. Price: |
| 27 |
98-7410 |
HOSE ASM Price: $111.58 |
| 28 |
340-87 |
FITTING-ELBOW, 45 DEG Price: $18.39 |
| 28 |
917-0678 |
Puck. Brake This part replaces 717-0678. Price: $6.87 |
| 29 |
917-0682 |
Plate. Puck This part replaces 717-0682. Price: $8.68 |
| 29 |
98-7409 |
HOSE ASM Price: $107.43 |
| 30 |
717-3534 |
SPUR GEAR 12T Not Available Price: |
| 30 |
98-7407 |
HOSE ASM Price: $115.22 |
| 31 |
58-4760 |
TUBE-STEEL Price: $131.21 |
| 31 |
917-3535 |
SPUR GEAR 34T Not Available This part replaces 717-3535. Price: |
| 32 |
58-4880 |
TUBE-STEEL Price: $236.51 |
| 32 |
717-3536 |
SPUR GEAR 19T Not Available Price: |
| 33 |
917-3537 |
SPUR GEAR 27T Not Available This part replaces 717-3537. Price: |
| 33 |
98-7412 |
HOSE ASM Price: $105.37 |
| 34 |
58-4870 |
TUBE-STEEL Price: $136.43 |
| 34 |
917-3538 |
DIFF SPUR GEAR 56T Not Available This part replaces 717-3538. Price: |
| 35 |
917-3541A |
BEVEL GEAR 16T Not Available This part replaces 717-3541. Price: |
| 35 |
98-7405 |
HOSE ASM Price: $114.18 |
| 36 |
60-1360 |
CLAMP-SINGLE Price: $5.97 |
| 36 |
917-3542A |
BEVEL GEAR 16T Not Available This part replaces 717-3542. Price: |
| 37 |
33113-025 |
SCREW-HH Price: $1.97 |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 37 |
917-3545A |
BEVEL GEAR 10T Not Available This part replaces 717-3545. Price: |
| 38 |
340-70 |
NUT-LOCK Price: $2.10 |
| 38 |
917-04132 |
BEVEL GEAR 13T Not Available This part replaces 717-04132. Price: |
| 39 |
237-30 |
O-RING Price: $2.50 |
| 39 |
917-04133 |
BEVEL GEAR 54T Not Available This part replaces 717-04133. Price: |
| 40 |
595088102 |
Handles This part replaces 532197661. Price: $4.99 |
| 40 |
718-3148A |
DIFF COVER Not Available Price: |
| 41 |
532198200 |
SPRING.LATCH.SEAT.TEX Price: $3.99 |
| 41 |
918-3149A |
DIFF LOCK PLATE This part replaces 718-3149A. Price: $72.33 |
| 42 |
918-3150 |
THRUST BLOCK Not Available This part replaces 718-3150. Price: |
| 43 |
718-04080P |
DIFF LOCK ACTUATOR YOKE Not Available This part replaces 718-04080. Price: |
| 43 |
874760612 |
BOLT Price: $3.99 |
| 44 |
918-04081A |
HI LO SHIFT YOKE Not Available This part replaces 718-04081. Price: |
| 45 |
919-04001 |
OUTER AXLE HOUSING (LH) Not Available This part replaces 719-04001. Price: |
| 46 |
719-04002 |
COVER, TRANS. SMALL Not Available Price: |
| 47 |
719-04153 |
TRANSMISSION HOUSING Not Available Price: |
| 48 |
919-04004 |
INNER AXLE HOUSING (RH) Not Available This part replaces 719-04004. Price: |
| 49 |
919-04005 |
INNER AXLE HOUSING (LH) Not Available This part replaces 719-04005. Price: |
| 50 |
921-0381 |
Oil Seal This part replaces 721-0381. Price: $17.77 |
| 51 |
721-0496 |
Seal, Oil Price: $9.52 |
| 52 |
721-0519 |
Seal, Gland Price: $32.98 |
| 53 |
921-3020A |
Seal, Oil, 1.18 ID This part replaces 721-3020A. Price: $10.75 |
| 54 |
921-04004 |
OIL SEAL This part replaces 721-04004. Price: $36.78 |
| 55 |
911-1680 |
TRANSMISSION SHAFT Not Available This part replaces 711-1680. Price: |
| 56 |
932-04003 |
TORSION SPRING Not Available This part replaces 732-04003. Price: |
| 57 |
932-04010 |
COMPRESSION SPRING Not Available This part replaces 732-04010. Price: |
| 58 |
932-04101 |
COMPRESSION SPRING .2240X .563 7000 Not Available This part replaces 732-04101. Price: |
| 59 |
936-0119 |
Washer, Lock, 5/16 This part replaces 736-0119. Price: $4.29 |
| 60 |
736-04126 |
SHIM WASHER .597x1.000x.040 Not Available Price: |
| 61 |
736-0371 |
Washer, Flat, .343 x .88 x .062 Price: $3.94 |
| 62 |
736-0615 |
Washer, Thrust Price: $8.02 |
| 63 |
736-0266 |
FLAT WASHER Not Available Price: |
| 64 |
741-0343 |
Pin, Brake Actuating Price: $8.93 |
| 65 |
941-0363 |
Flange Bearing, .503 ID x .75 OD This part replaces 741-0363. Price: $22.73 |
| 66 |
741-0862 |
DETENT BALL .250 Price: $3.90 |
| 67 |
741-1104 |
BEARING BALL Not Available Price: |
| 68 |
941-3033A |
Bearing, Ball This part replaces 741-3033A. Price: $50.07 |
| 69 |
941-3057 |
Bearing, Ball, 20x47x14, 6204 This part replaces 741-3057. Price: $35.46 |
| 70 |
741-3083 |
Bearing, Needle Thrust Price: $14.74 |
| 71 |
941-04014 |
BALL BEARING 6007 Not Available This part replaces 741-04014. Price: |
| 72 |
941-04066 |
BALL BEARING Not Available This part replaces 741-04066. Price: |
| 73 |
950-3364 |
SPACER Not Available This part replaces 750-3364. Price: |
| 74 |
950-04024 |
SPACER Not Available This part replaces 750-04024. Price: |
| 75 |
917-04043 |
BEVEL GEAR 36T Not Available This part replaces 717-04043. Price: |
| 76 |
761-0215 |
Disc, Brake Price: $19.46 |
| 77 |
961-04000 |
BRAKE YOKE ASSEMBLY This part replaces 761-04000. Price: $102.66 |
| 78 |
961-04001 |
ANTI ROTATION PLATE Not Available This part replaces 761-04001. Price: |
| 79 |
961-04002 |
PUCK RETAINING PLATE Not Available This part replaces 761-04002. Price: |
| 80 |
961-04003 |
BRAKE ACTRUATOR ARM (LH) Not Available This part replaces 761-04003. Price: |
| 81 |
961-04004A |
BRAKE ACTRUATOR ARM (RH) Not Available This part replaces 761-04004A. Price: |
| 82 |
750-04413 |
Spacer, .573 x .938 x .832 Price: $13.25 |
| 83 |
750-04416 |
PLUG Not Available Price: |
| 84 |
917-04004 |
BEVEL GEAR ASSEMBLY 15T Not Available This part replaces 617-04004. Price: |
| 86 |
716-0185 |
Ring, Retaining Price: $3.22 |
| 87 |
716-0204 |
Ring, Retaining Price: $5.94 |
| 88 |
718-04079B |
Yoke Actr, Lo This part replaces 718-04079. Price: $74.91 |
| 89 |
718-0668 |
SPLINE GEAR COUPLING Not Available Price: |
| 90 |
718-3116 |
Collar, Shift Price: $77.88 |
